- Page 1 Copyright This publication, including all photographs, illustrations and software, is protected under international copy- right laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without written consent of the author. © Copyright 2011 Disclaimer The information in this document is subject to change without notice.
-
Page 2: Important Safety Information
Important: It is strongly recommended that you read this section carefully before using the projector. These safety and usage instructions will ensure that you enjoy many years of safe use of the projector. Keep this manual for future reference. Symbols Used Warning symbols are used on the unit and in this manual to alert you of hazardous situations. -
Page 3: Projector Installation Notice
Ensure that the intake vents do not recycle hot air from the exhaust vent. When operating the projector in an enclosed space, ensure that the surrounding air temperature within the enclosure does not exceed 5 – 35°C while the projector is running, and the air intake and exhaust vents are unobstructed. - Page 4 Always keep your face away from the exhaust vent so that you do not suffer from the gas and bro- ken shards of the lamp. Regulatory Warnings Before installing and using the projector, read the regulatory notices in the Regulatory Compliance on page 51. Important Recycle Instructions: Lamp(s) inside this product contain mercury.
- Page 5 Input source automatically detected. About this manual This manual is intended for end users and describes how to install and operate the DLP projector. Wher- ever possible, relevant information—such as an illustration and its description—has been kept on one page. This printer-friendly format is both for your convenience and to help save paper, thereby protecting the environment.
-
Page 6: Table Of Contents
— ’ — ’ — ’ GETTING STARTED ... 1 ... 1 ACKING HECKLIST ... 2 IEWS OF ROJECTOR ARTS D5 Series Front-right View... 2 Top view—On-screen Display (OSD) buttons and LEDs ... 3 Rear view ... 4 Bottom view... 5 ... - Page 7 ... 43 ROBLEMS ... 43 EMOTE ONTROL ROBLEMS ... 43 UDIO ROBLEMS AVING THE ROJECTOR ERVICED HDMI Q & A... 44 SPECIFICATIONS... 45 ... 45 PECIFICATIONS ROJECTION ISTANCE VS ROJECTION D5 Series Projection Distance and Size Table... 46 D5 S ERIES IMING ABLE...
-
Page 8: Getting Started
Packing Checklist Carefully unpack the projector and check that the following items are included: EMOTE CONTROL 3V CR2025 WITH ONE BATTERY CD-ROM ’ S MANUAL Contact your dealer immediately if any items are missing, appear damaged, or if the unit does not work. It is recommend that you keep the original packing material should you ever need to return the equipment for warranty service. -
Page 9: Views Of Projector Parts
Zoom ring Function keys Height adjuster Important: Ventilation openings on the projector allow for good air circulation, which keeps the projector lamp cool. Do not obstruct any of the ventilation openings. 4 5 6 7 ESCRIPTION Receive IR signal from remote control... -
Page 10: Top View-On-Screen Display (Osd) Buttons And Leds
MENU ◄ (Left cursor) / Source ESCRIPTION Lamp error Normal State Turns the projector On or Off System over temperature Normal State Navigates and changes settings in the OSD Quick Menu – For Keystone Navigates and changes settings in the OSD... -
Page 11: Rear View
— ’ — ’ — ’ Rear view 2 3 4 HDMI ABEL Kensington Lock HDMI AC IN AUDIO IN (L and R) VIDEO IN S-VIDEO IN AUDIO IN RS-232C Note: If your video equipment has both S-VIDEO and RCA jacks (composite video) connect to the S-VIDEO connector. -
Page 12: Bottom View
Adjuster drops down when adjuster button is pushed. Push to release adjustor. To fasten the lens cap cover Rotate adjuster lever to adjust angle position. Contact your dealer for information on mounting the projector on a ceiling – 5 – – ’... -
Page 13: Remote Control Parts
2. Be sure nothing obstructs the path between the remote control and the projector. If the path be- tween the remote control and the projector is obstructed, you can bounce the signal off certain reflective surfaces such as projector screens. - Page 14 Left cursor Menu ESCRIPTION Navigates and changes settings in the OSD Changes settings in the OSD Turns the projector On or Off Navigates and changes settings in the OSD Increase volume Decrease volume Mutes the built-in speaker Freeze/unfreezes the on-screen picture...
-
Page 15: Remote Control Operating Range
Provided you are not holding the remote perpendicular to the sides or the rear of the projector, the remote will function well within a radius of about 7 meters (23 feet) and 15 degrees above or below the projector level. If the projector does not respond to the remote control, move a little closer. -
Page 16: Setup And Operation
Replace the cover. Caution: 1. Only use a 3V lithium battery (CR2025). 2. Dispose of used batteries according to local ordinance regulations. 3. Remove the battery when not using the projector for prolonged periods. ETUP AND – 9 – –... -
Page 17: Connecting Input Devices
’ Connecting Input Devices A PC or notebook computer and video devices can be connected to the projector at the same time. Video devices include DVD, VCD, and VHS players, as well as movie camcorders and digital still cameras. Check the user manual of the connecting device to confirm it has the appropriate output connector. -
Page 18: Starting And Shutting Down The Projector
Starting and Shutting down the Projector Connect the power cord to the projector. Connect the other end to a wall outlet. POWER LED on the projector light. Turn on the connected devices. Ensure the LAMP LED not a flashing orange. Then press the button to turn on the projector. - Page 19 POWER button. The projector turns off. Caution: 1. Be sure to remove the lens cap before starting projector. 2. Do not unplug the power cord until the LAMP LED stops flashing–indicating the projector has cooled down. – 12 –...
-
Page 20: Setting An Access Password (Security Lock)
OSD on page 18 and Setting the OSD Language on page 19 for help on using OSD menus.) Important: Keep the password in a safe place. Without the password, you will not be able to use the projector. If you lose the password, contact your reseller for information on clearing the password. - Page 21 — ’ — ’ — ’ You can use the cursor buttons ▲▼◄► either on keypad or IR remote control for password entry. You can use any combination including the same arrow five times, but not less than five. Press the cursor buttons in any order to set the password.
-
Page 22: Adjusting The Projector Level
Position the projector so that it is perpendicular to the screen. • Ensure the cables are in a safe location. You could trip over them. To raise the level of the projector, lift the projector [A] and press the height-adjuster button [B]. The height adjuster drops down [C]. -
Page 23: Adjusting The Zoom, Focus And Keystone
’ — ’ — ’ Adjusting the Zoom, Focus and Keystone Use the Image-zoom control (on the projector only) to resize the pro- jected image and screen size Use the Image-focus control (on the projector only) to sharpen the pro-... -
Page 24: Adjusting The Volume
Adjusting the Volume Press the Volume +/- buttons on the remote control. The volume control appears on the display. Press the Left or Right Cursor buttons on the keypad to adjust Volume +/-. Press the MUTE button to turn off the volume (This feature is available only on the remote). -
Page 25: On-Screen Display (Osd) Menu Settings
The projector has an OSD that lets you make image adjustments and change various settings. Navigating the OSD You can use the remote control cursor buttons or the buttons on the top of the projector to navigate and make changes to the OSD. -
Page 26: Setting The Osd Language
– ’ – ’ – ’ Setting the OSD Language Set the OSD language to your preference before continuing. 1. Press the MENU button. Press the cursor ◄► button to navigate to Installation I. 2. Press the cursor ▲▼ button until Language is highlighted. 3. -
Page 27: Osd Menu Overview
— ’ — ’ — ’ OSD Menu Overview Use the following illustration to quickly find a setting or determine the range for a setting. – 20 –... -
Page 28: Osd Sub-Menu Overview
– ’ – ’ – ’ OSD Sub-Menu Overview – 21 –... -
Page 29: Image Menu
— ’ — ’ — ’ Image Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Image Menu. Press the cursor ▲▼ button to move up and down in the Image menu. Press ◄► to change values for settings. -
Page 30: Advanced Feature
Advanced Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Image menu. Press ▼▲ to move to the Advanced menu and then press Enter or ►. Press ▼▲ to move up and down in the Advanced menu. -
Page 31: Color Manager
— ’ — ’ — ’ Color Manager Press (Enter) / ► to enter the Color Manager sub menu. Select to enter the Red Color Manager. Press the ◄► buttons to adjust the Hue, Saturation, and Gain. Select to enter the Green Color Manager. Green Press the ◄►... -
Page 32: Computer Menu
Computer Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Com- puter menu. Press the cursor ▲▼ button to move up and down in the computer menu. Press ◄► to change values for settings. -
Page 33: Video/Audio Menu
— ’ — ’ — ’ Video/Audio Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Video/Audio menu. Press the cursor ▲▼ button to move up and down in the Video/Audio menu. Press ◄►... -
Page 34: Audio
Audio Press (Enter) / ► to enter the Audio sub menu. Volume Press the ◄► buttons to adjust the audio volume. Mute Press the ◄► buttons to turn on or off the speaker. Audio Input Press the cursor ◄► button to select audio input. ESCRIPTION –... -
Page 35: Installationi Menu
— ’ — ’ — ’ Installation I Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Installa- tion I menu. Press the cursor ▲▼ button to move up and down in the Installation I menu. Press ◄►... -
Page 36: Advanced
Advanced Press (Enter) / ► to enter the Advanced sub menu. Security Lock Press the cursor ◄► button to enable or disable security lock function. Keypad Lock Press the cursor ◄► button to enable or disable keypad lock function. Wall Color Press the cursor ◄►... -
Page 37: Installation Ii Menu
— ’ — ’ — ’ Installation II Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Installa- tion II menu. Press the cursor ▲▼ button to move up and down in the Installation II menu. Auto Source Press the cursor ◄►... -
Page 38: 2D To 3D
2D to 3D Press the Menu button to open the OSD menu. Press ◄► to move to the Installation II menu. Press ▲▼ to move to the 2D to 3D menu and then press Enter or ►. Press ▲▼ to move up and down in the 2D to 3D menu. -
Page 39: Advanced Feature
— ’ — ’ — ’ Advanced Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Installation II menu. Press ▲▼ to move to the Advanced menu and then press Enter or ►. Press ▲▼ to move up and down in the Advanced menu. -
Page 40: Osd Menu Setting
OSD Menu Setting Menu Position Press ◄► button to select different OSD location. Translucent Menu Press ◄► button to select OSD background translucent level. Menu Display Press ◄► button to select OSD timeout delay. Peripheral Test Remote Control Test Press Color Test Press Button Test... -
Page 41: Lamp Hour Reset
— ’ — ’ — ’ Lamp Hour Reset Please refer to Resetting the Lamp on page 38 to reset the lamp hour counter. Press ◄► to select Off, DLP-Link or IR. 3D Sync Invert Press ◄► to turn 3D Sync Invert On or Off. ESCRIPTION –... -
Page 42: Factory Reset
Factory Reset Press the cursor ▲▼ button to move up and down in the Installation II menu. Select the Factory Reset sub menu and press (expect Language and Security Lock). Status Press the cursor ▲▼ button to move up and down in the Installation II menu. Select the Installation II sub menu and press Active Source Display the activated source. -
Page 43: Maintenance And Security
Disposal of this product must be carried out in accordance with the regulations of your local authority. Warning: Be sure to turn off and unplug the projector at least 30 minutes before replacing the lamp. Failure to do so could result in a severe burn. Caution: In rare cases the lamp bulb may burn out during normal operation and cause glass dust or shards to be discharged outward from the rear exhaust vent. - Page 44 Lamp Connector must be installed flush with the connector base as shown in the image below. A gap between the Lamp Connector and the connector base will cause damage to the projector. The following images illustrate correct and incorrect Lamp Connector installations.
-
Page 45: Resetting The Lamp
— ’ — ’ — ’ Resetting the Lamp After replacing the lamp, you should reset the lamp hour counter to zero. Refer to the following: Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Installation II menu. -
Page 46: Cleaning The Projector
Cleaning the projector to remove dust and grime will help ensure trouble-free operation. Warning: 1. Be sure to turn off and unplug the projector at least 30 minutes before cleaning. Failure to do so could result in a severe burn. -
Page 47: Using The Kensington ® Lock
— ’ ® Using the Kensington If you are concerned about security, attach the projector to a permanent object with the Kensington slot and a security cable. HDMI Note: Contact your vendor for details on purchasing a suitable Kensington security cable. -
Page 48: Troubleshooting
Common problems and solutions These guidelines provide tips to deal with problems you may encounter while using the projector. If the problem remains unsolved, contact your dealer for assistance. Often after time spent troubleshooting, the problem is traced to something as simple as a loose con- nection. -
Page 49: Led Error Messages
In the event of an error, please disconnect the AC power cord and wait for one (1) minute before re- starting the projector. If the Power or Lamp LEDs are still blinking or the Over Temp LED is lit, or any other situation that isn't listed in the chart above , please contact your service center. -
Page 50: Lamp Problems
Having the Projector Serviced If you are unable to solve the problem, you should have the projector serviced. Pack the projector in the original carton. Include a description of the problem and a checklist of the steps you took when trying to fix the problem: The information may be useful to service personnel. -
Page 51: Hdmi Tmq & A
— ’ — ’ — ’ HDMI Q & A Q. What is the difference between a “Standard” HDMI HDMI cable? Recently, HDMI High-Speed cables. ․Standard (or “category 1”) HDMI or up to 2.25Gbps, which is the equivalent of a 720p/1080i signal. ․High Speed (or “category 2”) HDMI 340Mhz or up to 10.2Gbps, which is the highest bandwidth currently available over an HDMI... -
Page 52: Specifications
Lamp Audio speaker Input Terminals Control Terminals Security For questions regarding product specifications, please contact your local distributor. Note: D512-3D TI DMD SVGA 0.55” TI DMD XGA 0.55” 800x600 Native 1024x768 Native 1 - 10 m 40” ~ 300” Manual Focus/Zoom 1.93 ~ 2.16... -
Page 53: Projection Distance Vs. Projection Size
’ — ’ Projection Distance vs. Projection Size D5 Series Projection Distance and Size Table MAGE IAGONAL MAGE IDTH （ ） INCH INCH D512-3D / D536-3D ROJECTION MAGE IGHT （MM） INCH 56.7 43.2 67.2 50.4 76.8 57.6 – 46 –... - Page 54 MAGE IAGONAL MAGE IDTH （ ） INCH INCH D538W-3D ROJECTION ISTANCE MAGE IGHT （MM） INCH – 47 – – – – ROJECTION ISTANCE （MM） 1310 1520 1960 2270 2290 2650 2360 2730 2620 3030 2750 3180 2950 3410 3140 3640 3270 3790 3930...
-
Page 55: D5 Series Timing Mode Table
— ’ — ’ — ’ D5 Series Timing Mode Table IGNAL ESOLUTION NTSC － PAL/SECAM － VESA 720 x 400 640 x 480 640 x 480 640 x 480 640 x 480 800 x 600 800 x 600 800 x 600 800 x 600 800 x 600 1024 x 768... - Page 56 IGNAL ESOLUTION 1600 x 1200 640 x 480 832 x 624 Apple Mac 1024 x 768 1152 x 870 480i SDTV 576i 480p EDTV 576p 720p 720p 1080i HDTV 1080i 1080p 1080p O: Frequency supported —: Frequency not supported *: Displayable level Caution: .
-
Page 57: Projector Dimensions
— ’ — ’ — ’ Projector Dimensions – 50 –... -
Page 58: Regulatory Compliance
FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device pur- suant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communica- tions. -
Page 59: Rs-232C Protocol
ASCII ‘~’ Control Sequence The projector may send a return code after it received a command. If the command isn’t received correctly, the projector will not send the return code Operation Command The operation commands execute the basic operation setting of this projector. - Page 60 Remote Command The remote commands simulate the code send from IR remote handset. Button’s name UP arrow DOWN arrow LEFT arrow RIGHT arrow POWER EXIT INPUT AUTO KEYSTONE+ KEYSTONE- MENU STATUS MUTE ZOOM+ ZOOM- BLANK FREEZE VOLUME+ VOLUME- Enter Set Value Command ITEM Brightness Contrast...
- Page 61 — ’ — ’ — ’ Query Command ITEM Software Version Power State Input Select Lamp Hours Brightness Contrast Color (Video) Tint (Video) Scaling Color Temperature Projection Mode Response message ITEM Software Version Power State Input Select Lamp Hours Brightness Contrast Color (Video) Tint (Video)
