- Page 1 WH-9100MESH Advanced Dual-Band MESH AP/Bridge Quick Setup Guide English ● ● ● Deutsch ● ● ● Polski ● ● ● Česky ● ● ● Русский ● ● ● Português ● ● ● Españoll ● ● ● 日本語 ● ● ●...
-
Page 2: Package Contents
1. Introduction 1.1 Preface The WH-9100MESH product is ruggedized and wall-mountable IEEE 802.11 Wireless Access Point (AP) and Bridge device. The AP and Bridge mode can work simultaneously by dual radio interfaces. 1.2 Package Contents Access Point 2 attachable 5dBi omni-directional antennas... - Page 3 1.3.2 LED indicator 1.3.3 Hardware Installation To Power Injector To PC (Cat5 Cable) (Initial Configuration and Lan function when set up as Gateway mode) Dual-Band MESH AP/Bridge English H-9100MESH...
-
Page 4: Power Injector
Power Injector To WAN Port To Wired LAN (Cat5 Cable) 2. Enter Configuration Screen The default IP of LAN port is https://192.168.15.1 (AP mode) and https://192.168.16.1 (Gateway mode). For the first time, you have to put the URL (https://192.168.15.1) for login and then you can set up 9100MESH as gateway mode. -
Page 5: System Configuration
You will be asked for your user name and password. Enter the default username airlive “ ”, and the default airlive password “ ” to give full access for setup configuration. (This password is case-sensitive) 3. System Configuration 3.1 Operation Mode You can set up 9100MESH as standard Access Point function, or Gateway. -
Page 6: Wan Configuration
3.2 WAN Configuration You can choose “Using DHCP to get an IP address”. By this way, the 9000MESH will get an IP address from DHCP server. If your network environment is without DHCP function, then you need to use static IP for WAN port. Then, the 9100MESH network administrator may need the following information: IP address -a list of IP addresses available on the organization's LAN there are available to be used for assignment to the AP(s) -
Page 7: Lan Configuration
3.3 LAN Configuration Click the entry on the left hand navigation panel for System Configuration – LAN. This directs you to the System Configuration – LAN page. This set up the default numbers for the four octets for a possible private LAN function for the AP. -
Page 8: Mac Address
Channel Number The channel number is a means of assigning frequencies to a series of access points. If you are using the WH-9100MESH as both an AP and bridge, the channel number set for the AP and the one for bridge should be sufficiently different to avoid interference. - Page 9 OvisLink Corporation declares that this device is in OvisLink Corporation declara que el dispositivo compliance with the essential requirements and cumple con los requerimientos básicos y otras other relevant provisions of directive 1999/5/EC facilidades relevantes de la directriz 1999/5/EC Компания OvisLink Corporation заявляет, что это A OvisLink Corporation declara que este dispositivo устройство...
