3220 SERIES ANALOG ENVIRONMENTAL CAMERA INSTALLATION MANUAL RS-232 RS-422 Figure 1. Model 3220 NTSC or PAL Camera Technical Manual 6X-1082a March 25, 2008...
Page 2
INSTALLATION MANUAL 3220 CAMERA CAUTION Do not power the 24 V ac version of this camera directly from a Variac. It will blow up the power supply. Figure 2. Camera Version with Pigtail Cable (Model 3221 or Model 3223) Also available without factory wired pigtail cable to allow for direct connections to internal terminals (Model 3222 or Model 3224) Two other manuals related to this camera are available:...
3220 CAMERA INSTALLATION MANUAL 1.0 GENERAL DESCRIPTION This introduction briefly describes the overall characteristics of the Model 3220 Camera (figure 1) related to its installation. Complete specifications can be found on the CD supplied with this camera. 1.1 Electrical Characteristics The 3220 provides a highly sensitive CCD camera in an environmental housing.
INSTALLATION MANUAL 3220 CAMERA 322 x — x 0 0 0 xxxx SERIES VIDEO Camera in IP66 Rated FORMAT Unpressurized Assigned 3 NTSC Housing 7 PAL MOUNT WALL (Wall Mount) PEDD (Pedestal Mount) POWER CEIL Ceiling Mount) POLE (Pole Mount) 1 12 V dc with interface cable HDWM (Heavy Duty Wall Mount) 2 12 V dc 3 24 V ac/dc with interface cable...
3220 CAMERA INSTALLATION MANUAL Table 1. Mounting Configurations ITEMS SUPPLIED MOUNT MOUNT 3220 WALL PEDESTAL CEILING HEAVY DUTY POLE DESIGNATION DESCRIPTION CAMERA MOUNT MOUNT MOUNT WALL MOUNT MOUNT • • Wall Mount WALL • • • Pedestal PEDD Mount • •...
Heavy Duty Wall Mount Notes: All dimensions in inches. This kit provides the hardware necessary to attach a 3220 series camera to a Heavy Duty Wall Mount, a Ceiling Mount, or a Pedestal Mount. This hardware must be used in place of the metric hardware included with these mounts.
Page 7
0.63 (16) 0.63 (16) 1.50 2.75 (69.8) (38.1) 1/4-20 Note: 1/4-20 bolts must not protrude more that (Typical two places) 5/16 inch past bottom of camera Figure 5. Dimensions, Model 3220 Series Cameras 6X-1082a...
INSTALLATION MANUAL 3220 CAMERA Table 3. System Interconnection Cable Characteristics ITEM CABLE DATA VIDEO POWER DATA TYPE TYPE CONNECTION CONNECTION CONNECTION 12 V dc CA-253A stripped leads stripped leads stripped leads RS-232 CA-253B stripped leads D9 female CA-254A stripped leads stripped leads stripped leads CA-254B...
Page 9
3220 CAMERA INSTALLATION MANUAL Figure 6. Type CA-253A System Interconnection Cable Figure 7. Type CA-253B System Interconnection Cable 6X-1082a...
Page 10
INSTALLATION MANUAL 3220 CAMERA Figure 8. Type CA-254A System Interconnection Cable Figure 9. Type CA-254B System Interconnection Cable 6X-1082a...
Page 11
3220 CAMERA INSTALLATION MANUAL Figure 10. Type CA-254M System Interconnection Cable Figure 11. Type CA-292A System Interconnection Cable 6X-1082a...
Page 12
INSTALLATION MANUAL 3220 CAMERA Figure 12. Type CA-292B System Interconnection Cable Figure 13. Type CA-293A System Interconnection Cable 6X-1082a...
Page 13
3220 CAMERA INSTALLATION MANUAL Figure 14. Type CA-293B System Interconnection Cable Figure 15. Type CA-293M System Interconnection Cable 6X-1082a...
(Or connect to the camera with an If any confusion exists it is best to contact the on-site cable.) This assumes the other end of the Customer Support department at Cohu or your local cable is properly connected to a source of power, a Cohu representative.
Page 15
3220 CAMERA INSTALLATION MANUAL CAUTION Do not power the 24 V ac version of this camera directly from a Variac. It will blow up the power supply. Model 3222 Model 3224 75-ohm Video Out 24 V ac low 12 V dc ground 24 V dc ground Video Ground 24 V ac high...
Page 16
INSTALLATION MANUAL 3220 CAMERA E1 Chassis Ground Ground Lug for Cable Overall Shield (Solder direct or use spade lug) Figure 17. Model 3222 or Model 3224 Camera Internal Wiring Ground Lug or international: 1-828-293-2222 terconnection cable that plugs into this 3220 pigtail connector.
Page 17
3220 CAMERA INSTALLATION MANUAL All cameras are shipped with this wall mount arm, 1/4-20 bolt, and lock washer Figure 18. Standard Wall (WALL) Mount 5/16 x 5/8 slot Typical 2 places Dimensions in inches and (mm) 2.94 3.88 (74.6) (98.5) 0.25 (6.35) 1.50...
Page 18
INSTALLATION MANUAL 3220 CAMERA Figure 20. Pedestal (PEDD) 9.3 (236) 0.25 x 0.56 (6.35 x 14.2) slot Dimensions in inches and (mm) Typical 4 at 90° O 4.0 Pedestal (102) Post O 1.5 (38) 0.187 (4.7) Figure 21. Mounting Dimensions, Pedestal (PEDD) Mounting Base 6X-1082a...
Page 19
3220 CAMERA INSTALLATION MANUAL Figure 22. Ceiling (CEIL) Mount (8.0) 0.312 (168) 6.62 Typical 3 O 1.125 (28.6) at 120° (144) 5.68 Threaded (15) Dimensions in inches and (mm) Figure 23. Mounting Dimensions, Ceiling (CEIL) Mount Plate 6X-1082a...
Page 20
INSTALLATION MANUAL 3220 CAMERA Figure 24. Heavy Duty Wall Mount (HDWM) 3/8 x 15/16 slot 0.69 Typical 4 places (18) 3.35 4.55 (85.1) (116) (15.2) 1.56 0.156 (39.7) (3.97) Thickness at 4.55 bolt landings (115) Dimensions in inches and (mm) Figure 25.
Page 21
3220 CAMERA INSTALLATION MANUAL Pole mount bracket can clamp to pole diameters from 2.5 to 4.3 inches (65 to 110 mm) Figure 26. Pole (POLE) Mount Assembly (Consists of Heavy Duty Wall Mount to Left and a Pole Bracket to Right) Note: Four cap screws and flat washers from this kit are not used.
For shipment, package with enough foam pad- CONNECTOR CABLE PLUG ding or other packing material to prevent damage Connector: that can occur during shipping. The original ship- Cohu P.N. 1310230-017 1310230-011 ping carton is a good container if it has not been MS P.N. MS3111F-124-18P MS3116F-14-18S Amp/Bendix P.N.
Page 23
3220 CAMERA INSTALLATION MANUAL Table 5. Pigtail Cable Connector Pin Assignments RS-232 RS-422 RS-232 RS-422 12 Vdc 12 Vdc 24 Vac/dc 24 Vac/dc TABLE Model 3221 Model 3221 Model 3223 Model 3223 FUNCTION Cable Cable Cable Cable CA-253 CA-254 CA-292 CA-293 Video Out Video Shield...
Page 24
INSTALLATION MANUAL 3220 CAMERA Connector (Plug) for the System Cable that Connects to Camera Pigtail Connector Front Side - Mating Sockets Wiring Side - Solder Cups Kit as Typically Packaged Connector Kit Contents Figure 29. Type 1310230-011 System Cable 18-pin MS Type Connector Kit 6X-1082a...
Page 25
3220 CAMERA INSTALLATION MANUAL 4.3 Ceiling (CEIL) Mount 2 The heavy duty wall mount (HDWM) shown in figure 24 The ceiling mount (figure 22) has a round plate for securing to the ceiling with three fasteners and Provided with the Pole mount are two hard- a curved tubular arm that threads into the center.
Page 26
All warranty repairs will be performed at the Cohu factory or as otherwise authorized by Cohu in writing. Purchaser shall prepay transportation charges to Cohu.
