- Page 1 Products Helios Series INSTALLATION MANUAL 7510 Fixed Camera System camera is configured for DHCP The 7510 (If a DHCP server is not available, the camera IP address will need to be configured.) Technical Manual 6X-1101C www.CohuHD.com July 15, 2014 info@CohuHD.com...
-
Page 2: Table Of Contents
Contents About this document Additional information and documents related to the camera system FCC compliance Support services Returns Safety instructions 1.0 Camera Connection Overview 2.0 Audio/Trigger Pin Out 3.0 Getting Started 4.0 PC Configuration of 7510 Cameras 4.1 System Requirements 4.2 Recommended Computer Requirements 4.3 Power over Ethernet (PoE) 4.4 Accessing the Camera... -
Page 3: About This Document
About this document This manual contains information on installation and quick start for the 7510 fixed position camera sys- tem. Please read this manual carefully prior to installation to prevent any accidental damage or misuse. A CD, including this manual, is shipped with the Camera. The manual is also available from the CohuHD http://www.CohuHD.com/Files/install_manuals/7510_IM.pdf. -
Page 4: Returns
Returns This item was thoroughly tested and carefully packed at the factory prior to shipping. Upon acceptance by the carrier, the carrier assumes responsibility for the item’s safe arrival. Should you receive the item in a damaged condition, apparent or concealed, a claim for damage must be made to the carrier. If a visual inspection shows damage upon receipt of this shipment, it must be noted on the freight bill or express receipt and the notation signed by the carrier’s agent. -
Page 5: Safety Instructions
Safety instructions • Installation should be done only by qualified installers and conform to all local codes. • It is the user’s responsibility to ensure that the mounting methods are safe and adequate for the location. • Use appropriate hardware to fasten the mount to an indoor surface. •... -
Page 6: Camera Connection Overview
1.0 Camera Connection Overview 1. SDHC Card Slot - An SDHC card (not included) can be used for on-camera recording. 2. Network Connector - RJ-45 Power-over-Ethernet connector. 3. Power Connector - Captive 2-pin screw terminal for 12-24VDC or 24VAC power source. 4. -
Page 7: Audio/Trigger Pin Out
2.0 Audio/Trigger Pin Out 3.0 Getting Started camera into the network. 1. Plug the 7510 2. Power the camera using either Power-over-Ethernet or direct power. Power-over-Ethernet: Input from an IEEE802.3af Power-over-Ethernet (PoE) power injector or switch as show in Figure 1. Direct Power: Connect either a 12-24VDC or 24VAC power source to the camera. - Page 8 NOTE: Using a power source with specifications other than those defined will damage the camera, and will void the product warranty. Series camera position, field-of-view and focus adjustment can be performed using an ana- 3. The 7510 log monitor with the optional 7411550-004 BNC video cable adapter (Figure 3) or by using a browser to view the camera image.
-
Page 9: Pc Configuration Of 7510
4.0 PC Configuration of 7510 Cameras Installation and testing of the Camera can be performed with the built-in 7510 Series web interface applica- tion. 4.1 System Requirements In order to test the Camera you need the following items: • laptop or desktop computer (for recommended computer requirements see section 4.2 of this chapter) •... - Page 10 CAT5e Router/PoE Switch Router/Switch Cable Network Switch Figure 4. Interconnection Diagram with PoE-enabled switch Router/ CAT5e Router/Switch non-PoE Switch Cable PoE Injector Network 100-240 V AC Switch Power Figure 5. Interconnection Diagram with non-PoE Switch NOTE: Series specifications PoE injector can be ordered from CohuHD. Please refer to the CohuHD website in the 7510 section for ordering information.
-
Page 11: Accessing The Camera
4.4 Accessing the Camera NOTE: The default user name for 7500 Series is “Admin” and the default password is “Camera”. The 7500 cameras are configured for DHCP and will have an IP address assigned if a DHCP server is on the network. -
Page 12: Using The Cohuonvifdiscovery Software To Discover The Camera
4.4.3 Using the CohuONVIFDiscovery Software to Discover the Camera • Insert the CohuHD 7500 Series CD into the CD drive of the PC or download the software from the link: http://www.CohuHD.com/content/downloads. Under Software & Protocol Downloads see the Helios and 7500 Camera Series discovery tool. Click “download here.” •... -
Page 13: Change The Camera Ip Network Address
4.4.4 Change the camera IP network address • Open a browser (IE recommended) and enter the IP address of the 7510 camera in the address field of the browser. The “Live” page will be displayed. • If prompted, install the ActiveX control. •... -
Page 14: Assigning The Static Ip Address
4.4.5 Assigning the Static IP Address Set your computer IP address to the same subnet as the Camera IP address. • Go Start > Control Panel > Network connections > Local Area Connection (Windows XP). • Go Start > Control Panel > Network and Sharing Center > Local Area Connection (Windows 7). 1. - Page 15 3. You will see the “Internet Protocol (TCP/IP) dialog box. In the “General” tab the “Use the follow- ing IP address” button should be selected. Enter IP and subnet addresses. Click “OK” to close the “Internet Protocol (TCP/IP). “Use the following IP address” General Tab button is selected Enter an IP address which is not used...
-
Page 16: One-Touch-Focus Procedure
4.4.6 One-Touch-Focus Procedure To complete focusing using the one-touch focus method go to the Setup > Focus tab. • Set the iris on the lens to the ‘Open’ position then lock it down with the iris set screw. • If the back focus has been set before using the camera, click the “restore defaults” button on the Focus tab to reset the back focus adjustment. -
Page 17: Video Streaming
4.4.7 H.264 Video Streaming To prepare the camera to serve the H.264 stream, select “H.264” from the drop-down menu. To view the H.264 stream in full screen mode (without ‘Live’ page controls), double click on the video window. Double- click on the video window again to return back to the ‘Live’ page. NOTE: For information on the camera system operation and configuration, please see the camera system built-in help. -
Page 18: Warranty
5.0 Warranty Please refer to the CohuHD website for product warranty information: http://www.CohuHD.com/warranty/WarrantyStatement.pdf. Revision History Revision Date Comments Rev A 10/1/2012 Initial release 10/19/12 p3 - website address was changed Rev B • the manual is revised to change company name Rev C 7/15/14 6X-1101C...
