U s e r 's m a n u a l
NVIP-3000 series IP camera

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NVIP-3000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Novus NVIP-3000 Series

Summary of Contents for Novus NVIP-3000 Series

  • Page 1 U s e r ’s m a n u a l NVIP-3000 series IP camera...

  • Page 2: Important Safeguards And Warnings

    NVIP-3000 series IP camera user’s manual IMPORTANT SAFEGUARDS AND WARNINGS EMC (2004/108/EC) and LVD (2006/95/EC ) Directives CE Marking Our products are manufactured to comply with requirements of following directives and national regulations implementing the directives: • Electromagnetic compatibility EMC 2004/108/EC.
  • Page 3 NVIP-3000 series IP camera user’s manual IMPORTANT SAFEGUARDS AND WARNINGS WARNING! THE KNOWLEDGE OF THIS MANUAL IS AN INDESPENSIBLE CONDITION OF A PROPER DEVICE OPERATION. YOU ARE KINDLY REQUSTED TO FAMILIRIZE YOURSELF WITH THE MANUAL PRIOR TO INSTALLATION AND FURTHER DEVICE OPERATION.

  • Page 4: Table Of Contents

    NVIP-3000 series IP camera user’s manual TABLE OF CONTENTS TABLE OF CONTENTS ..................... 4 1. START-UP AND INITIAL IP CAMERA CONFIGURATION ......... 6 1.1. Overview ......................6 1.2. Starting the IP camera ..................6 1.3. Initial configuration via the web browser ............7 2.
  • Page 5 NVIP-3000 series IP camera user’s manual TABLE OF CONTENTS 3.9.4 IP Notify ....................22 3.9.5 DDNS Config..................... 22 3.9.6 RTSP ......................22 3.9.7 UPNP ......................23 3.9.8 Mail Config ....................23 3.9.9 FTP ......................24 3.10 Advanced Config ....................24 3.10.1 User Config ....................

  • Page 6: Start-Up And Initial Ip Camera Configuration

    1.2. Starting the IP camera To run NOVUS IP camera you have to connect ethernet cable between camera and network switch. To power it up you can connect it directly via power supply adapter with parameters compatible with camera power supply specification, or camera can be powered with PoE/PoE+ (IEEE 802.3af/802.3at)

  • Page 7: Initial Configuration Via The Web Browser

    192.168.1.2 to 192.168.1.254, for example 192.168.1.60). It is not allowed to set the same addresses for camera and PC computer You can either set a network configuration (IP address, gateway, net mask, etc.) of NOVUS IP camera yourself or select DHCP mode (DHCP server is required in this method in target network) by using web browser or by NMS software.

  • Page 8: Network Connection Utilizing Web Broswer

    NVIP-3000 series IP camera user’s manual NETWORK CONNECTION UTILIZING WEB BROWSER 2. NETWORK CONNECTION UTILIZING WEB BROSWER 2.1. Recommended PC specification for web browser connections Requirements below apply to connection with an IP camera, assuming smooth image display in 1920x1080 resolution and 25 fps speed.
  • Page 9 NVIP-3000 series IP camera user’s manual NETWORK CONNECTION UTILIZING WEB BROWSER If the installation fails, changing security settings for the IE browser is required. In order to do that, please choose: Tools > Internet options > Security tab > Custom level and: •...

  • Page 10: Using And Configuring

    NVIP-3000 series IP camera user’s manual USING AND CONFIGURING 3. USING AND CONFIGURING 3.1 The Remote Preview Interface 1. Motion detection Motion detection icon changes color from white to red when motion is detected. Alarm icon changes color from white to red when alarm situation has occured.

  • Page 11: Video Record And Playback

    NVIP-3000 series IP camera user’s manual USING AND CONFIGURING 3.2 Video Record and Playback To start recording click icon and specify file path. After selecting the record date, the record files will be displayed in the record file list box. Double click a certain record file to playback or check a certain file.

  • Page 12: Snap Pictures

    NVIP-3000 series IP camera user’s manual USING AND CONFIGURING 3.4 Snap Pictures To take a picture click “Snap” icon. User can snap multiple pictures. Select the picture number from Frame pull down list box and check “Title” and “Time” to show capture title and time on the snap pictures simultaneously.

  • Page 13: System Configuration

    NVIP-3000 series IP camera user’s manual USING AND CONFIGURING 3.5 System Configuration The “System configuration” includes two submenus: Basic Information and Date & Time. 3.5.1 Basic Information In the “Basic Information” interface, user can setup the device name and also can check the relative information of the server.

  • Page 14: Sd Card

    NVIP-3000 series IP camera user’s manual USING AND CONFIGURING 3.5.3 SD card Enter into "System Config" -> “SD Card”. 1. Click “Format SD card” to format micro SD card. 2. Click "Eject card" to stop writing data to micro SD card. Then the micro SD card can be ejected safely.

  • Page 15: Video Configuration

    NVIP-3000 series IP camera user’s manual USING AND CONFIGURING 3.6 Video Configuration 3.6.1 Camera Configuration 1. Enter into "Video Config" -> "Camera". 2. User can adjust Brightness, Contrast, Hue and saturation of the picture. 3. It is possible to select white balance mode.

  • Page 16: Video Stream

    NVIP-3000 series IP camera user’s manual USING AND CONFIGURING 3.6.2 Video Stream 1.Enter into "Video Config" -> "Video Stream". 2. Select the resolution, frame rate, bitrate type, video quality and bitrate at the pull down list. 3. User can also set I Frame Interval (25~100 range) and profile (Base Line or Main Profile).

  • Page 17: Video Mask

    NVIP-3000 series IP camera user’s manual USING AND CONFIGURING 3.6.4 Video Mask User can set up to 4 video masks. To add video mask press “Draw” button and mark mask on video preview. Chosen area will cover with green grid. To activate mask check “Enable Video Mask”. To save settings press “Save” button.

  • Page 18: Alarm Configuration

    NVIP-3000 series IP camera user’s manual USING AND CONFIGURING 3.8 Alarm Configuration 3.8.1 Motion Detection Area 1. Enter into “Alarm configuration" -> "Motion Detection Area" to see a interface. 2. Move the "Sensitivity" scroll bar to setup the motion trace sensitivity.

  • Page 19: Motion Detection Schedule

    NVIP-3000 series IP camera user’s manual USING AND CONFIGURING 3.8.3 Motion Detection Schedule Enter into “Alarm Config" -> "Motion Detection schedule" Week schedule User can set alarm time for every weekday separately in one week. Note: It is possible to choose hours from 0-24 range. Mouse clicks on the panel to set the alarm hours.

  • Page 20: Alarm Input Trigger

    NVIP-3000 series IP camera user’s manual USING AND CONFIGURING 3.8.4 Alarm Input Trigger Enter “Alarm Configuration" -> "Alarm Input Trigger". 1. Select the sensor at the "Sensor" pull down list and set the sensor name and alarm type: NO and NC.

  • Page 21: Network Configuration

    NVIP-3000 series IP camera user’s manual USING AND CONFIGURING 3.9 Network Configuration Network configuration includes ten submenus: Port, Wired, Server Configuration, IP Notify, DDNS Config, RTSP, UPNP, Mail Setting and FTP. 3.9.1 Port 1. Enter into "Network Config" -> "Port"...

  • Page 22: Ip Notify

    NVIP-3000 series IP camera user’s manual USING AND CONFIGURING 3.9.4 IP Notify 1. Enter into “Network Config” -> ”IP Notify” 2. If the “Enable notifying change of IP” is selected, when the IP address of the device is changed, a new IP address will be sent to the appointed mailbox automatically. If “FTP” is selected, when the IP address of the device was changed, a new IP address will be sent to FTP server.

  • Page 23: Upnp

    NVIP-3000 series IP camera user’s manual USING AND CONFIGURING 3.9.7 UPNP Enter into “Network Config” -> “UPNP” Select “Enable UPNP” and then input friendly name. Enable UPNP in Windows Double-click the “My Network Places” icon on the desktop in PC and select “Show icons for networked UPnP devices”...

  • Page 24: Ftp

    NVIP-3000 series IP camera user’s manual USING AND CONFIGURING 3.9.9 FTP Enter into “Network Config” -> “FTP Setting” Add: Click Add button to input FTP server’s server name, address, port number, user name, password, and upload path, click OK to confirm the setting.
  • Page 25 NVIP-3000 series IP camera user’s manual USING AND CONFIGURING Add user: 1. Click "Add" button. “Add User” dialog box will pop up. Note: After bind physical address to the IP Camera, user can access the device on this PC in network only. If the MAC address was “00:00:00:00:00:00”...

  • Page 26: Security Configuration

    NVIP-3000 series IP camera user’s manual USING AND CONFIGURING 3.10.2 Security Configuration Enter into “Advanced Config” -> "Security Config” IP address filter setting Check “Enable IP address” check box, select “Deny the following IP address”, input IP address in the IP address list box and click “Add”...

  • Page 27: Reboot

    NVIP-3000 series IP camera user’s manual USING AND CONFIGURING 3.10.4 Reboot Enter into “Advanced Config” -> “Reboot”. Click “Reboot” button to reboot the device. 3.10.5 Upgrade Enter into “Advanced Config” -> “Upgrade” 1. Click “Browse” button to select the upgrade file 2.

  • Page 28: Mobile Surveillance

    NVIP-3000 series IP camera user’s manual MOBILE SURVEILLANCE 4. MOBILE SURVEILLANCE This IP-CAM supports mobile surveillance by phones with Windows mobile, iPhone, Android and Blackberry OS. Please check the operation system version of mobile before use; and connect the IP-CAM to Internet.

  • Page 29: Install Mobile Surveillance Software Via Pc

    NVIP-3000 series IP camera user’s manual MOBILE SURVEILLANCE 4.1.2 Install Mobile Surveillance software via PC. 1. Install iTunes store on PC and login. 2. Connect iPhone with PC. 3. Search “SuperLivePro” and select it. All rights reserved © AAT Holding sp. z o.o.
  • Page 30 NVIP-3000 series IP camera user’s manual MOBILE SURVEILLANCE 4. Click “Download” button. 5. Input username and password. 6. Install SuperLivePro software to iPhone/iPad. All rights reserved © AAT Holding sp. z o.o.

  • Page 31: Superlivepro Instruction

    NVIP-3000 series IP camera user’s manual MOBILE SURVEILLANCE 4.1.3 SuperLivePro Instruction Login 1. Choose network type. There are two network connection ways: • 3G/3G +WIFI, well video quality. This network supports main stream and sub stream. The real-time image will be displayed by using sub stream.
  • Page 32 NVIP-3000 series IP camera user’s manual MOBILE SURVEILLANCE There are many buttons in the main interface, such as, screen mode, favorite channel, snap, record, open/close audio, talk, PTZ., etc. ：Image view button. The pictures snapped in the live will be checked by clicking this button.
  • Page 33 NVIP-3000 series IP camera user’s manual MOBILE SURVEILLANCE Channel indicator instruction: ：Video loss ： Schedule recording ：Others ：Sensor alarm ：Motion alarm ：Motion /sensor alarm based recording or manual recording Server list Click button to show adding new devices window. Add device: Click “Add” button in the top right corner to pop up a dialog box as shown in the following left picture.
  • Page 34 NVIP-3000 series IP camera user’s manual MOBILE SURVEILLANCE Live Preview Once you access the device, the system will automatically display the screen mode in accordance with the channel number of the device. Note: The maximum number of channels which can be connected is nine.
  • Page 35 NVIP-3000 series IP camera user’s manual MOBILE SURVEILLANCE CMS Function This function makes multi-device management. 1. Click to enable CMS function. When this icon turns green, it means this function is enabled. 2. Click to choose channel as shown in the right picture. After you choose the channel, click “ok”, the system will display the related image automatically.
  • Page 36 NVIP-3000 series IP camera user’s manual MOBILE SURVEILLANCE Playback Interface Click “Playback” button to enter the playback interface. Then click “Search” button to search the file. To play the record click required file name. Image View Click button to view the captured pictures.

  • Page 37: Mobile Surveillance Via Android Os Smartphone

    NVIP-3000 series IP camera user’s manual MOBILE SURVEILLANCE Information Interface In this interface, you can view system information. 4.2. Mobile Surveillance via Android OS smartphone. 4.2.1 Software Installation 1. Run “Play Store” (or Google market) program. 2. Search “SuperLivePro”. All rights reserved © AAT Holding sp. z o.o.
  • Page 38 NVIP-3000 series IP camera user’s manual MOBILE SURVEILLANCE 3. Press “Install” button. 4. Install the software subject to the notes. Once the downloading is done, the software will install automatically. Login 1. Configure the network of your device and mobile phone.
  • Page 39 NVIP-3000 series IP camera user’s manual MOBILE SURVEILLANCE Main Menu Live View Snap Record Talk Enable/disable audio Hide Play favorite channel Image View First picture Previous picture Next picture Last picture Zoom in Zoom out Delete All rights reserved © AAT Holding sp. z o.o.
  • Page 40 NVIP-3000 series IP camera user’s manual MOBILE SURVEILLANCE Record Playback Click “Playback” in the main menu interface to enter playback interface. Then choose the channel you want to playback. This will take you to see the record file. Click this file to play.
  • Page 41 NVIP-3000 series IP camera user’s manual MOBILE SURVEILLANCE Add Server: Click button to pop up a window as shown in the previous picture on the right hand. Enter the name, server, user and password of the device you want to add. Then click “Save”...

  • Page 42: Restoring Factory Defaults

    NVIP-3000 series IP camera user’s manual RESTORING FACTORY DEFAULTS 5. RESTORING FACTORY DEFAULTS NOVUS IP cameras allow to restore defaults via: • software (web browser level) • software (NMSiptool level) • hardware (using reset button) Restoring factory defaults by software means (web browser level) User can restore default settings of the IP camera.
  • Page 43 NVIP-3000 series IP camera user’s manual NOTES All rights reserved © AAT Holding sp. z o.o.
  • Page 44 AAT Holding sp. z o.o., ul. Puławska 431, 02-801 Warszawa, Polska tel.: 22 546 07 00, faks: 22 546 07 59 www.novuscctv.com 2014-01-30 TŁ, MK...
