Emblaze-VCON VCB5 User Manual page 27

Reserve Ports
Ad-hoc
Use this
service
exclusively for
ad-hoc
conferences
Multicast
Defaults
Session Name
Session
Description
Broadcast to
Address
Video Refresh
Rate
Media Packets
TTL
SDP Rate
SDP TTL
Emblaze-VCON VCB5 User's Guide
If selected, the VCB reserves an equal number of ports as
the number of maximum users in this session, in
accordance with your VCB license terms.
For example, if the session is limited to a maximum of 8
participants, the VCB will reserve 8 ports. None of those
ports will be available for other sessions.
Select to enable expansion to an ad-hoc conference.
This service is only available for inviting additional users
into ad-hoc videoconferences, but not available for
initiating multipoint sessions.
Select to enable streaming sessions.
Click to restore the default multicast streaming
configuration.
Type a name to identify this service's multicast session.
Type a name or description of the multicast session.
The destination IP address for the multicast session. All
participants in the session transmit and receive from this
common IP address. This address must be a class D
address in the range of 224.0.0.0 to
239.255.255.255.
Define the interval at which the end point broadcasting
the multicast synchronizes the video display at the
receiving ends.
The maximum number of routers (hops) that the
multicast session's packets may pass through.
Session Description Protocol Rate - The interval at which
announcements and descriptions of the multicast
session are sent out on the Internet Multicast backbone
(Mbone), for Participants and passive third-party
viewers.
The maximum number of routers (hops) that the SDP
announcement for this session may pass through.
4 Setting Up the VCB
19
