- Page 1 User’s Guide Sistema de Calidad certificado Sistema Medioambiental certificado Nº Cert: 44 100 11 0904 Nº Cert: 44 104 11 0904 ZUMMO-INNOVACIONES MECÁNICAS, S.A. C/ CÁDIZ 4 46113 MONCADA (Valencia) España Tel.: + 34 961301246 Fax: + 34 961301250 E-mail: zummo@zummo.es 011201/03...
-
Page 2: Table Of Contents
ZUMMO - INNOVACIONES MECÁNICAS, S.A., in an ongoing effort to enhance its products, reserves the right to modify machines without prior notice; for this reason, this user’s manual may not contain the latest changes made. INDEX ............................. 1 TECHNICAL DATA ........................ 1 2 IMPORTANT SAFETY INSTRUCTIONS ................ -
Page 3: Installation
INSTALLATION • ATTENTION! The machine weighs 56Kg. When moving the machine, we suggest that this be accomplished by two persons. The best way to handle a machine is to use one hand to get a grip underneath the rear and the other placed beneath the squeezing tray. (Fig. 4) •... -
Page 4: Programmer Counter Function
PROGRAMMER COUNTER FUNCTION If you want to know the total number of operations* performed by your machine, press the STOP button while the machine is not running and this number will appear on the Programmer display for a few seconds. Keep in mind that all brand new machines show 400 – 500 operations (operations carried out at the factory for quality control). -
Page 5: Use Recommendations
TAKE EXTRA CARE WITH THE BLADE (Fig. 3) since it is very sharp and may cause injuries. • Remove the Cups unscrewing the Fastening Nuts. • The Front Cover (Ref. 2/10) and the Drip Tray (Ref. 8/1V) are manufactured with a plastic sensitive to hot temperatures over 40ºC. -
Page 6: Troubleshooting
• In the case that an orange get trapped between the Front Cover and the Cup, cut the orange using a knife in order to remove it easily. • Oranges used must fit into the cups. If oranges are bigger or smaller for the size of the Cups, the juice obtain may contain peel oil and bitter flavour. -
Page 7: Electrical Diagram
- To modify the number on the Programmer display, press ON until you visualize the wanted number. Wait for five seconds until the Programmer memorized the number. -Check that the Cups stop position is correct. If not, repeat the same steps selecting a different number. - Page 8 3/6/5A SPACER 8/1A DRIP TRAY (RED) 3/6/6C SPACER-HEAD(SHORT) WASHER 8/1V DRIP TRAY (GREEN) 3/6/8-1 COMPLETE S. STEEL HOPPER PLATE 10/1/2 SERIGRAPHY ZUMMO & ZUMMitO 3/6/8B PLATE 10/2C MICROCOUNTER HOLDER 3/6/10A HOPPER FASTENING 10/3B SIDE METAL COVER 3/6/12 HOPPER SPRING 10/4C...
-
Page 9: Guarantee
In case of damages caused during the guarantee period, we suggest you contact the Authorised Dealer who supplied the unit, or call ZUMMO: E-mail:sat@zummo.es Tel:+34.96.1301246 Fax:+34.96.1301250 Any repairs not authorized by ZUMMO during the guarantee period will cause immediate termination of the guarantee. -
Page 10: Waste And Recyclability
WASTE AND RECYCLABILITY Used equipment European Union This symbol indicates that the electrical and electronic parts in the machine must not be discarded with general domestic waste. If you wish to discard this equipment, do not use your everyday bin! There is a special collection system for these products.
