CONTROL PANEL
●
The operator can easily create a sewing pattern on the spot by
inputting sewing pattern data through the control panel
according to a sewing sample or the feeding frame.
●
The control panel is very helpful to the operator to input pattern
data, to operate the sewing machine and to use the milling unit.
●
As many as 176,000 stitches or 691 patterns can be stored in
memory.
●
As many as 4,000 stitches can be input for one sewing pattern.
If the combination mode is used, as many as 20,000 stitches can
be input for a pattern.
Automatic Bobbin Changer for AMS
BK SERIES
BK-2: AMS-223C, AMS-224C
BK-5: AMS-223P, AMS-224P
● All you need to do is set a magazine packed with bobbin cases
onto the main unit of the AMS.
replace the bobbin thread whenever necessary (complete
replacement only takes five seconds).
a maximum of ten bobbin cases.
● The magazine can be easily attached/removed without any tools.
This device is designed for attaching on the existing machine.
Consequently, BK-series can be attached to your AMS in use with
ease.
● Bobbin replacement time can be set using the bobbin counter
on the operation panel.
manually.
● The main unit of the device does not require compressed air for
operation. The electrical circuit board is installed inside the
control box of the AMS.
installed on the machine, and only a small space is required for
the installation.
SPECIFICATIONS
Number of bobbins that can
be set in a magazine
Period of time required to
replace a bobbin
Power supply
AMS-223C, 224C, 223P, 224P (September, 2003) 4/4
The machine will automatically
One magazine can store
The bobbin can also be replaced
Therefore the device can be smoothly
Max. 10 pcs.
Approx. 5 sec.
Can be connected through
the main unit of AMS
WHEN YOU PLACE ORDERS
BK
Applicable models Code
AMS-223C
2
AMS-224C
AMS-223P
5
AMS-224P
AMS-223C/BK2
Application
Standard
For medium-weight materials
Code
S
H
