SanDisk CompactFlash Product Manual page 78

CIS Description
Data 7 6
Attribute
Offset
0A8h 21h X R
0 0
0AAh 1Bh
0ACh 06h
0AEh 00h I D
0 0
0B0h 01h M
0
0B2h 21h R DI
0 0
0B4h B5h X
1
0B6h 1Eh X
0
0B8h 4Dh X
0
0BAh 1Bh
0BCh 0Dh
0BEh C1h I D
1 1
0C0h 41h W R
0 1
6-6
5 4 3 2 1 0
P RO A T
1 0 0 1
CISTPL_CE
Configuration Index
0
MS IR IO T P
0 0 0 0 1
PI AI SI H LV NV
1 0 0 0 0 1
Mantissa Exponent
6h = 3.0 5h = 1
1Eh
Mantissa Exponent
9h = 4.5 5h = 10
CISTPL_CE
Configuration Index
1
P B Interface Type
0 0 1
®
CompactFlash Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION
Description of Contents
Power-Down, and Twin Card.
T:Twin Cards Allowed
A:Audio Supported
RO:Read Only Mode
P:Power Down Supported
R:Reserved
X:More Misc Fields Bytes
Configuration Entry Tuple
Link to next tuple is 6 bytes. Also
limits size of this tuple to 8 bytes.
Memory mapped I/O 3.3V
configuration.
P:Power info type
PI:Peak Current
NV:Nominal Operation Supply
Voltage
Nominal Operation Supply Voltage
= 3.0V
+.30
Max Average Current over 10 msec
is 45mA
Configuration Entry Tuple
Link to next tuple is 13 bytes. Also
limits size of this tuple to 15 bytes.
I/O Mapped Contiguous 16
registers configuration
Configuration Index for this entry is
1. Interface Byte follows this byte.
Default Configuration, so is not
dependent on previous Default
Configuration.
D:Default Configuration
I:Interface Byte Follows
I/O Interface(1), Bvd's and wProt
not used; Ready/-Busy active but
Wait not used for memory cycles.
B:Battery Volt Detects Used
P:Write Protect Used
R:Ready/-Busy Used
W:Wait Used for Memory Cycles
CIS Function
TPCE_MI
Tuple Code
Link to next tuple
TPCE_INDX
TPCE_FS
TPCE_PD
Nominal Operation Supply Voltage
Nominal Operation Supply Voltage
Extension Byte
Max Average Current
Tuple Code
Link to next tuple
TPCE_INDX
TPCE_IF
