SanDisk CompactFlash Product Manual page 53

Word Address Default Value
3 XXXX
4 0000H
5 0240H
6 XXXX
7-8 XXXX
9 0000H
10-19 aaaa
20 0002H
21 0002H
22 0004H
23-26 aaaa
27-46 aaaa
47 0001H
48 0000H
49 0200H
50 0000H
51 0200H
52 0000H
53 0003
54 0003H
55 XXXX
56 XXXX
57-58 XXXX
59 010XH
60-61 XXXX
62-63 0000H
64 0003H
65-66 0000H
67 0078H
68 0078H
69-127 0000H
128-159 0000H
160-255 0000H
®
CompactFlash Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION
Total
Bytes
2 Default number of heads
2 Number of unformatted bytes per track
2 Number of unformatted bytes per sector
2 Default number of sectors per track
4 Number of sectors per card (Word 7 = MSW, Word 8 = LSW)
2 Reserved
20 Serial number in ASCII (Right Justified)
2 Buffer type (dual ported)
2 Buffer size in 512 byte increments
2 # of ECC bytes passed on Read/Write Long Commands
8 Firmware revision in ASCII (Rev M.ms) set by code Big Endian Byte Order in Word
40 Model number in ASCII (Left Justified) Big Endian Byte Order in Word
2 Maximum of 1 sector on Read/Write Multiple command
2 Double Word not supported
2 Capabilities: DMA NOT Supported (bit 8), LBA supported (bit 9)
2 Reserved
2 PIO data transfer cycle timing mode
2 DMA data transfer cycle timing mode Not Supported
2 Field validity
2 Current numbers of cylinders
2 Current numbers of heads
2 Current sectors per track
4 Current capacity in sectors (LBAs)(Word 57 = LSW, Word 58 = MSW)
2 Multiple sector setting is valid
4 Total number of sectors addressable in LBA Mode
4 Reserved
2 Advanced PIO modes supported
4 Reserved
2 Minimum PIO transfer without flow control
2 Minimum PIO transfer with IORDY flow control
130 Reserved
64 Reserved vendor unique bytes
192 Reserved
Data Field Type Information
ATA Command Description
5-5
