CompactFlash

Memory Card

Product Manual
C
H
ORPORATE
EADQUARTERS
140 Caspian Court
Sunnyvale, CA 94089-1000
408-542-0500
FAX: 408-542-0503
URL: http://www.sandisk.com

Advertisement

Table of Contents
loading

Related Manuals for SanDisk CompactFlash

Summary of Contents for SanDisk CompactFlash

  • Page 1: Memory Card

    ® CompactFlash Memory Card Product Manual ORPORATE EADQUARTERS 140 Caspian Court Sunnyvale, CA 94089-1000 408-542-0500 FAX: 408-542-0503 URL: http://www.sandisk.com...
  • Page 2 Corporation general policy does not recommend the use of its products in life support applications where in a failure or malfunction of the product may directly threaten life or injury. Per SanDisk Terms and Conditions of Sale, the user of SanDisk products in life support applications assumes all risk of such use and indemnifies SanDisk against all damages.

  • Page 3: Table Of Contents

    3.4.4. Pin Replacement Register (Address 204h in Attribute Memory) .........3-21 3.4.5. Socket and Copy Register (Address 206h in Attribute Memory...........3-22 3.5. I/O Transfer Function ........................3-22 3.5.1. I/O Function........................3-23 ® CompactFlash Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION...
  • Page 4 5.1.5.23. Words 60-61: Total Sectors Addressable in LBA Mode........5-8 5.1.5.24. Word 64: Advanced PIO Transfer Modes Supported ........5-8 5.1.5.25. Word 67: Minimum PIO Transfer Cycle Time Without Flow Control .....5-8 ® CompactFlash Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION...
  • Page 5 5.2. Error Posting ..........................5-23 6. CIS Description ............................6-1 Appendix A. Ordering Information ........................A-1 Appendix B. Technical Support Services ......................B-1 Appendix C. SanDisk Worldwide Sales Offices ....................C-1 Appendix D. Limited Warranty........................D-1 ® CompactFlash Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION...
  • Page 6 Table of Contents This page intentionally left blank. ® CompactFlash Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION...

  • Page 7: Introduction To The Compactflash Memory Card

    Additional ATA commands have been provided to enhance system performance. The host system can support as many cards as there are CompactFlash and PCMCIA Type II or III card slots. The original form factor CompactFlash Memory Cards require a PCMCIA Type II Adapter to be used in a PCMCIA Type II or Type III socket.

  • Page 8: Scope

    Introduction to the CompactFlash Memory Card 1.1. Scope This document describes the key features and specifications of CompactFlash Memory Cards, as well as the information required to interface this product to a host system. Retail CompactFlash specifications are not covered in this manual.

  • Page 9: Compactflash Specification

    1-800-854-7179 1.6. Functional Description CompactFlash Memory Cards contain a high level, intelligent subsystem as shown in the block diagram, Figure 1-1. This intelligent (microprocessor) subsystem provides many capabilities not found in other types of memory cards. These capabilities include the following: •...

  • Page 10: Technology Independence

    1.6.1. Technology Independence The 512-byte sector size of the CompactFlash Memory Card is the same as that in an IDE magnetic disk drive. To write or read a sector (or multiple sectors), the host computer software simply issues a Read or Write command to the CompactFlash Memory Card.

  • Page 11: Automatic Sleep Mode

    Note that the delay from command completion to entering sleep mode can be adjusted. When the host is ready to access the CompactFlash Memory Card and it is in sleep mode, any command is sued to the CompactFlash Card will cause it to exit sleep and respond.
  • Page 12 Introduction to the CompactFlash Memory Card This page intentionally left blank. ® CompactFlash Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION...

  • Page 13: Product Specifications

    Sleep mode currently is specified under the condition that all card inputs are static CMOS levels and in a “Not Busy“ operating state. The currents specified show the bounds of programmability of the product. ® CompactFlash Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION...

  • Page 14: System Performance

    Command to DRQ 50 msec maximum NOTE: The Sleep to Write and Sleep to Read times are the times it takes the CompactFlash Memory Card to exit sleep mode when any command is issued by the host to when the card is reading or writing. CompactFlash Memory Cards do not require a reset to exit sleep mode (see Section 1.7.5).

  • Page 15: Capacity Specifications

    16,056,320 bytes 31,360 32MB 32,112,640 bytes 62,720 64MB 64,225,280 bytes 125,440 128MB 128,450,560 bytes 250,880 256MB 256,901,120 bytes 501,760 512MB 512,483,328 bytes 1,000,944 1024MB 1,024.97 bytes 2,001,888 1,986 ® CompactFlash Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION...
  • Page 16 Product Specifications This page intentionally left blank. ® CompactFlash Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION...

  • Page 17: Compactflash Memory Card Interface Description

    3. CompactFlash Memory Card Interface Description 3.1. Physical Description The host is connected to the CompactFlash Memory Card using a standard 50-pin connector consisting of two rows of 25 female contacts each on 50 mil (1.27 mm) centers. 3.1.1. Pin Assignments and Pin Type The signal/pin assignments are listed in Table 3-1.
  • Page 18 2. Should be grounded by the host. 3. Should be tied to VCC by the host. 4. Please refer to Section 3.3 for definitions of In, Out type. ® CompactFlash Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION...

  • Page 19: Electrical Description

    CompactFlash Memory Card Interface Description 3.2. Electrical Description The CompactFlash Memory Card Series is optimized for operation with hosts, which support the PCMCIA I/O interface standard conforming to the PC Card ATA specification. However, the CompactFlash Card may also be configured to operate in systems that support only the memory interface standard.
  • Page 20 This is an I/O Read strobe generated by the host. This signal gates I/O data onto the (PC Card I/O Mode) bus from the CompactFlash Card when the card is configured to use the I/O interface. -IORD In True IDE Mode, this signal has the same function as in PC Card I/O Mode.
  • Page 21 RESET When the pin is high, this signal resets the CompactFlash Card. The card is Rese t (PC Card Memory Mode) only at power up if this pin is left high or open from power-up. The card is also reset when the Soft Reset bit in the Card Configuration Option Register is set.

  • Page 22: Electrical Specification

    Signal Name Dir. Description -VS1 Voltage Sense Signals. -VS1 is grounded so that the CompactFlash Card CIS can be -VS2 read at 3.3 volts and -VS2 is open and reserved by PCMCIA for a secondary voltage. (PC Card Memory Mode) -VS1 This signal is the same for all modes.

  • Page 23: Input Leakage Control

    Vcc = 5.0V 500k NOTE: The minimum pullup resistor leakage current meets the PCMCIA specification of 10k ohms but is intentionally higher in the CompactFlash Memory Card Series product to reduce power use. 3.3.2. Input Characteristics Table 3-4. Input Characteristics...

  • Page 24: Output Drive Characteristics

    1. The -REG signal timing is identical to address signal timing. 2. SanDisk CompactFlash Memory Cards do not assert the -WAIT Signal. NOTE: All timings measured at the CompactFlash Memory Card. Skews and delays from the system driver/receiver to the CompactFlash Memory Card must be accounted for by the system.

  • Page 25: Common And Attribute Memory Write Timing

    1. The -REG signal timing is identical to address signal timing. 2. SanDisk CompactFlash Memory Cards do not assert the -WAIT signal. NOTE: All timings measured at the CompactFlash Memory Card. Skews and delays from the system driver/receiver to the CompactFlash Memory Card must be accounted for by the system.

  • Page 26: Attribute Memory Read Timing Specification

    Card Enable Setup Time (CE) tELGL Card Enable Hold Time (CE) tGHEH 1. SanDisk CompactFlash Memory Cards do not assert the -WAIT signal. 3.3.8. Memory Timing Diagrams t c (R) t h (A) t a (A) A[10:0], -REG t a (CE)
  • Page 27 3. May be high or low for write timing, but restrictions on -OE from previous figures apply. 4. SanDisk CompactFlash Memory Cards do not assert the -WAIT signal. Figure 3-2. Common and Attribute Memory Write Timing Diagram ®...

  • Page 28: I/O Read (Input) Timing Specification

    D[15::0] All timings are measured at the CompactFlash Memory Card. Skews and delays from the host system driver/receiver to the CompactFlash Memory Card must be accounted for by the system design. D[15::0] signifies data provided by the CompactFlash Memory Card to the host system.
  • Page 29 All timings in ns. The maximum load on -INPACK and -IOIS16 is 1 LSTTL with 50 pF total load. 3. SanDisk CompactFlash Memory Cards do not assert a -WAIT Signal. ® CompactFlash Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION...

  • Page 30: I/O Write (Output) Timing Specification

    (IOWR) All timings are measured at the CompactFlash Memory Card. Skews and delays from the host system driver/receiver to the CompactFlash Memory Card must be accounted for by the system design. D[15::0] signifies data provided by the host system to the CompactFlash Memory Card.

  • Page 31: True Ide Mode

    For PIO modes 3 and above, the minimum value of t is specified by word 68 in the IDENTIFY DEVICE parameter list. Table 3-8 defines the minimum value that shall be placed in word 68. ® CompactFlash Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION 3-15...
  • Page 32 1. Device address consists of signals -CS0, -CS1 and -DA(2:0). 2. Data consists of DD(7:0). 3. SanDisk CompactFlash Memory Cards do not assert an -IORDY signal. 4. All signals are shown with the asserted condition facing the top of the page. The negated condition is shown towards the bottom of the page relative to the asserted condition.
  • Page 33 2. This parameter specifies the time from the negation edge of /IORD to the time that the data bus is no longer driven by the device (tri-state). 3. SanDisk CompactFlash Memory Cards do not assert an -IORDY signal. PIO Data Transfers Figure 3-6 defines the relationships between the interface signals for PIO data transfers.

  • Page 34: Card Configuration

    In addition, these registers provide a method for accessing status information about the CompactFlash Card that may be used to arbitrate between multiple interrupt sources on the same interrupt level or to replace status information that appears on dedicated pins in memory cards that have alternate use in I/O cards.

  • Page 35: Attribute Memory Function

    NOTE: The location of the card configuration registers should always be read from the CIS since these locations may vary in future products. No writes should be performed to the CompactFlash Memory Card attribute memory except to the card configuration register addresses. All other attribute memory lo cations are reserved.

  • Page 36: Configuration Option Register (Address 200H In Attribute Memory)

    Soft Reset—Setting this bit to one (1), waiting the minimum reset width time and returning to zero (0) places the CompactFlash Memory Card in the Reset state. Setting this bit to one (1) is equivalent to assertion of the +RESET signal except that the SRESET bit is not cleared. Returning this bit to zero (0) leaves the CompactFlash Memory Card in the same un-configured, Reset state as following power-up and hardware reset.

  • Page 37: Card Configuration And Status Register (Address 202H In Attribute Memory)

    IOis8 The host sets this bit to a one (1) if the CompactFlash Memory Card is to be configured in an 8 bit I/O mode. The CompactFlash Card is always configured for both 8- and 16-bit I/O, so this bit is ignored.

  • Page 38: Socket And Copy Register

    CRdy/-Bsy. RWProt This bit is always zero (0) since the CompactFlash Memory Card does not have a Write Protect switch. When written, this bit acts as a mask for writing the corresponding bit CWProt.

  • Page 39: I/O Function

    3.5.1. I/O Function The I/O transfer to or from the CompactFlash Memory Card can be either 8 or 16 bits. When a 16-bit accessible port is addressed, the signal -IOIS16 is asserted by the CompactFlash Card. Otherwise, the -IOIS16 signal is de-asserted.

  • Page 40: True Ide Mode I/O Transfer Function

    File and Data Register are allowed. In this mode, no Memory or Attribute Registers are accessible to the host. CompactFlash Cards permit 8 bit data accesses if the user issues a Set Feature Command to put the device in 8-bit Mode.

  • Page 41: Ata Drive Register Set Definition And Protocol

    • Memory space. The communication to or from the CompactFlash Memory Card is done using the Task File registers, which provide all the necessary registers for control and status information. The PCMCIA interface connects peripherals to the host using four register mapping methods. Table 4-1 is a detailed description of these methods.

  • Page 42: Contiguous I/O Mapped Addressing

    (even then odd) bytes from the data buffer. Byte accesses to register 9 access only the odd byte of the data. 3. Address lines that are not indicated are ignored by the CompactFlash Memory Card for accessing all the registers in this table.

  • Page 43: Memory Mapped Addressing

    ATA Drive Register Set Definition and Protocol 4.3. Memory Mapped Addressing When the CompactFlash Memory Card registers are accessed via memory references, the registers appear in the common memory space window: 0-2K bytes as shown in Table 4-4. Table 4-4. Memory Mapped Decoding...

  • Page 44: True Ide Mode Addressing

    4.5.1. Data Register (Address—1F0[170];Offset 0, 8, 9) The Data Register is a 16-bit register, and it is used to transfer data blocks between the CompactFlash Memory Card data buffer and the Host. This register overlaps the Error Register. The table below describes the combinations of data register access and is provided to assist in understanding the overlapped Data Register and Error/Feature Register rather than to attempt to define general PCMCIA word and byte access modes and operations.

  • Page 45: Feature Register

    This register contains the number of sectors of data requested to be transferred on a read or write operation between the host and the CompactFlash Memory Card. If the value in this register is zero, a count of 256 sectors is specified.

  • Page 46: Sector Number (Lba 7-0) Register (Address-1F3[173]; Offset 3)

    This bit will have the following meaning. DRV is the drive number. When DRV=0, drive (card) 0 is selected When DRV=1, drive (card) 1 is selected. The CompactFlash Card is set to be Card 0 or 1 using the copy field of the PCMCIA Socket &...

  • Page 47: Status & Alternate Status Registers (Address 1F7[177]&3F6[376]; Offsets 7 & Eh)

    Bit 2 (SW Rst) This bit is set to 1 in order to force the CompactFlash Memory Card to perform an AT Disk controller Soft Reset operation. This does not change the PCMCIA Card Configuration Registers (4.3.2 to 4.3.5) as a hardware Reset does.

  • Page 48: Card (Drive) Address Register (Address 3F7[377]; Offset Fh)

    Address Space when a Floppy Disk Controller is located at the Primary addresses. 2. Do not install a Floppy and a CompactFlash Memory Card in the system at the same time. 3. Implement a socket adapter that can be programmed to (conditionally) tri-state D7 of I/0 address 3F7/377 when a CompactFlash Memory Card is installed and conversely to tri-state D6-D0 of I/O address 3F7/377 when a floppy controller is installed.

  • Page 49: Ata Command Description

    There are three classes (see Table 5-1) of command acceptance, all dependent on the host not issuing commands unless the CompactFlash Card is not busy. (The BUSY bit in the status and alternate status registers is 0.) •...

  • Page 50: Check Power Mode-98H, E5H

    Feature (1) This command checks the power mode. If the CompactFlash Memory Card is in, going to, or recovering from the sleep mode, the CompactFlash Card sets BSY, sets the Sector Count Register to 00h, clears BSY and generates an interrupt.

  • Page 51: Execute Drive Diagnostic-90H

    Sec Cnt (2) Feature (1) This command performs the internal diagnostic tests implemented by the CompactFlash Memory Card. The Diagnostic codes shown in Table 5-4 are returned in the Error Register at the end of the command. Table 5-4. Diagnostic Codes...

  • Page 52: Format Track-50H

    Write Sector(s) command although the information in the buffer is not used by the CompactFlash Card. If LBA=1 then the number of sectors to format is taken from the Sec Cnt register (0=256).
  • Page 53 Reserved 0078H Minimum PIO transfer without flow control 0078H Minimum PIO transfer with IORDY flow control 69-127 0000H Reserved 128-159 0000H Reserved vendor unique bytes 160-255 0000H Reserved ® CompactFlash Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION...

  • Page 54: Word 0: General Configuration

    This field contains the number of sectors per track in the default translation mode. 5.1.5.7. Words 7-8: Number of Sectors per Card This field contains the number of sectors per CompactFlash Memory Card. This double word value is also the first invalid address in LBA translation mode.

  • Page 55: Word 21: Buffer Size

    This field defines the mode for PIO data transfer. 5.1.5.18. Word 52: Single Word DMA Data Transfer Cycle Timing Mode This field states this product does not support any Single Word DMA data transfer mode. ® CompactFlash Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION...

  • Page 56: Word 53: Translation Parameters Valid

    00H, which indicates that R/W Multiple commands are not valid. The only other value returned by the CompactFlash Memory Card in the even byte is a 01H value, which indicates that 1 sector per interrupt, can be transferred in R/W Multiple mode.

  • Page 57: Idle-97H, E3H

    Feature (1) This command causes the CompactFlash Memory Card to set BSY, enter the Idle (Read) mode, clear BSY and generate an interrupt. If the sector count is non-zero, it is interpreted as a timer count with each count being 5 milliseconds and the automatic power down mode is enabled.

  • Page 58: Initialize Drive Parameters-91H

    NOTE: SanDisk recommends NOT using this command in any system because DOS determines the offset to the Boot Record based on the number of heads and sectors per track. If a CompactFlash Memory Card is “Formatted” with one head and sector per track value, the same CompactFlash Card will not operate correctly with DOS configured with another heads and sectors per track value.

  • Page 59: Read Multiple-C4H

    Sector Count Feature (1) NOTE: The current revision of the CompactFlash Memory Card only supports a block count of 1 as indicated in the Identify Drive Information command. This command is provided for compatibility with future products that may support a larger block count.

  • Page 60: Read Long Sector-22H, 23H

    The transfer begins at the sector specified in the Sector Number Register. When this command is issued and after each sector of data (except the last one) has been read by the host, the CompactFlash Memory Card sets BSY, puts the sector of data in the buffer, sets DRQ, clears BSY, and generates an interrupt.

  • Page 61: Read Verify Sector(S)-40H, 41H

    Feature (1) This command is effectively a NOP command to the CompactFlash Memory Card and is provided for compatibility purposes. After this command is executed the Cyl High and Cyl Low as well as the Head number will be 0 and Sec Num will be 1 if LBA=0 and 0 if LBA=1 (i.e., the first block in LBA is 0 while CHS mode the sector number starts...

  • Page 62: Request Sense-03H

    CompactFlash Memory Card Series product. The extended error code is returned to the host in the Error Register. This command must be the next command issued to the CompactFlash Card following the command that returned an error.

  • Page 63: Seek-7Xh

    This command is used by the host to establish or select certain features. Table 5-22 defines all features that are supported. Please note that the 9AH feature is unique to the CompactFlash Memory Card and are not part of the ATA Specification.

  • Page 64: Set Multiple Mode-C6H

    Where “nnn” is a valid mode number in binary, “x” is the mode number in decimal for the associated transfer type, and “d” is ignored. Features 55H and BBH are the default features for the CompactFlash Memory Card; thus, the host does not have to issue this command with these features unless it is necessary for compatibility reasons.

  • Page 65: Set Sleep Mode- 99H, E6H

    Sec Cnt (2) Feature (1) This command causes the CompactFlash Memory Card to set BSY, enter the Sleep mode, clear BSY and generate an interrupt. Recovery from sleep mode is accomplished by simply issuing another command (a reset is permitted but not required).

  • Page 66: Standby Immediate-94H, E0H

    Sec Cnt (2) Feature (1) This command causes the CompactFlash Memory Card to set BSY, enter the Sleep mode (which corresponds to the ATA “Standby” Mode), clear BSY and return the interrupt immediately. Recovery from sleep mode is accomplished by simply issuing another command (a reset is not required).

  • Page 67: Wear Level-F5H

    Feature (1) This command is effectively a NOP command and only implemented for backward compatibility with earlier SanDisk SDP series products. The Sector Count Register will always be returned with an 00H indicating Wear Level is not needed. 5.1.24. Write Buffer—E8H Table 5-30.

  • Page 68: Write Long Sector-32H, 33H

    Sector Count Feature (1) NOTE: The current revision of the CompactFlash Memory Card only supports a block count of 1 as indicated in the Identify Drive Command information. This command is provided for compatibility with future products that may support a larger block count.

  • Page 69: Write Multiple Without Erase-Cdh

    Sector Number Sec Cnt (2) Sector Count Feature (1) SanDisk does not recommend the use of this command in new designs but it is supported as a normal Write Sectors command for backward compatibility reasons. ® CompactFlash Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION...

  • Page 70: Write Sector(S)-30H, 31H

    256 sectors. The transfer begins at the sector specified in the Sector Number Register. When this command is accepted, the CompactFlash Memory Card sets BSY, then sets DRQ and clears BSY, then waits for the host to fill the sector buffer with the data to be written. No interrupt is generated to start the first buffer fill operation. No data should be transferred by the host until BSY has been cleared by the host.

  • Page 71: Write Verify Sector(S)-3Ch

    256 sectors. The transfer begins at the sector specified in the Sector Number Register. When this command is accepted, the CompactFlash Memory Card sets BSY, then sets DRQ and clears BSY, then waits for the host to fill the sector buffer with the data to be written. No interrupt is generated to start the first buffer fill operation. No data should be transferred by the host until BSY has been cleared by the host.
  • Page 72 Write Multiple Write Multiple w/o Erase Write Sector(s) Write Sector(s) w/o Erase Write Verify Sector(s) Invalid Command Code V = valid on this command * See Table 5-2. ® 5-24 CompactFlash Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION...

  • Page 73: Cis Description

    6. CIS Description This section describes the Card Information Structure (CIS) for the CompactFlash Memory Card. Table 6-1. Card Information Structure Attribute Data Description of Contents CIS Function Offset 000h CISTPL_DEVICE Device Info Tuple Tuple Code 002h Link is 4 bytes...
  • Page 74 (Field Bytes 3-4 taken as 0) Link length is 3 byte Link to next tuple and length of info in this tuple Legacy CompactFlash products may report “SunDisk” as the ASCII manufacture string. ® CompactFlash Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION...
  • Page 75 Function Extension tuple Tuple Code 07Ah This tuple has 3 info bytes Link Length 07Ch Disk Function Extension Tuple Type Basic PCMCIA-ATA Extension tuple Extension Tuple Type for Disk 07Eh ® CompactFlash Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION...
  • Page 76 090h CISTPL_CE Configuration Entry Tuple Tuple Code 092h Link to next tuple is 11 bytes. Also Link to next tuple limits size of this tuple to 13 bytes. ® CompactFlash Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION...
  • Page 77 Length in 256 bytes pages (lsb) Length of Mem Space is 2 KB TPCE_MS Length LSB 0A6h Length in 256 bytes pages (msb) Start at 0 on card TPCE_MS Length MSB ® CompactFlash Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION...
  • Page 78 I/O Interface(1), Bvd's and wProt TPCE_IF not used; Ready/-Busy active but Wait not used for memory cycles. B:Battery Volt Detects Used P:Write Protect Used R:Ready/-Busy Used W:Wait Used for Memory Cycles ® CompactFlash Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION...
  • Page 79 15(F) S:Share Logic Active P:Pulse Mode IRQ Supported L:Level Mode IRQ Supported M:Bit Mask of IRQs Present V:Vendor Unique IRQ B:Bus Error IRQ I:IO Check IRQ N:Non-Maskable IRQ ® CompactFlash Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION...
  • Page 80 20 bytes. 0ECh Configuration Index AT Fixed Disk Primary I/O Address TPCE_INDX Configuration Configuration Index for this entry is 2. Interface Byte follows this byte. Default Configuration ® CompactFlash Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION...
  • Page 81 (1F0- 1F7, 3F6-3F7) on A9 through A0 for I/O cycles. IO AddrLines:#lines decoded E:Eight bit only hosts supported S:Sixteen bit hosts supported R:Range Follows ® CompactFlash Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION...
  • Page 82 Link to next tuple is 6 bytes. Also Link to next tuple limits size of this tuple to 8 bytes. 114h Configuration Index AT Fixed Disk Primary I/O 3.3V TPCE_INDX configuration ® 6-10 CompactFlash Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION...
  • Page 83 Vcc Nominal is 5Volts Vcc Nominal Value Ah = 5.0 5h = 1V 12Eh Mantissa Exponent Vcc Nominal is 4.5Volts Vcc Minimum Value 9h = 4.5 5h = 1V ® CompactFlash Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION 6-11...
  • Page 84 Recommended IRQ's any of 0 through 15(F) S:Share Logic Active P:Pulse Mode IRQ Supported L:Level Mode IRQ Supported M:Bit Mask of IRQs Present M=0 so bits 3-0 are single level, binary encoded ® 6-12 CompactFlash Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION...
  • Page 85 Tuple Code 166h 000h No Bytes Following Link Length is 0 Bytes Link to next tuple 168h 0FFh End of Tuple Chain End of CIS Tuple Code ® CompactFlash Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION 6-13...
  • Page 86 CIS Description This page intentionally left blank. ® 6-14 CompactFlash Memory Card Product Manual, Rev. 10.0 © 2002 SANDISK CORPORATION...

  • Page 87: Appendix A. Ordering Information
