4.2.2 Special hand tools
Name of tool
Piston pin insertion/
extraction tool
Connecting rod
small end bushing
insertion/extraction
tool
Intake and exhaust
valve insertion/
extraction tool
Crankshaft pulley
insertion tool
Illustration
20
20
* Locally manufactured
20
* Locally manufactured
50
20
80
80
75
26
6
-0.1
27
-0.2
M12 x P1.25
68
4. Disassembly and reassembly
Remarks
(Piston pin extractor)
(Extraction of piston pin)
(Insertion of piston pin)
(Extraction)
