L. P. Gas and 230 / 240 V Electric Storage Water Heater Model B 10 / B 14 from 11/2003
Operating instructions
Installation instructions
To be kept in the vehicle!
Comfort on the move
Page 2
Page 6
Boiler EL
230 V ~

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B 10 and is the answer not in the manual?

Questions and answers

Related Manuals for Truma B 10

Summary of Contents for Truma B 10

  • Page 1 Boiler L. P. Gas and 230 / 240 V Electric Storage Water Heater Model B 10 / B 14 from 11/2003 Operating instructions Page 2 Installation instructions Page 6 To be kept in the vehicle! Boiler EL 230 V ~...

  • Page 2: Installation Example

    Boiler L. P. Gas and 230/240 V Electric Storage Water Heater Model B 10 / B 14 from 11/2003 Installation example 1 Truma-Boiler 2 Control panel 3 Safety/drain valve 4 Cowl for combustion air intake and exhaust gas discharge General safety notes –...

  • Page 3: Filling The Truma Boiler With Water

    (e. g. on the wardrobe door)! Ask Truma to send you Boiler stickers, if necessary.

  • Page 4: Maintenance

    DVGW and fulfils the EC gas appliance guidelines (90/396/EEC) as well as the associated EC guidelines. The water tank in the Truma Boiler is of high quality The CE product number is available for EU countries: food-proof stainless steel VA.

  • Page 5: Electrical Operation

    The warranty claim is not valid for damage to the appliance Check the power supply (operation voltage min. 10.5 V). – as a result of not original Truma parts being used in the ap- Check the Boiler fuse (refer to maintenance “Fuses”).

  • Page 6: Installation Instructions

    (D) 92 x 168 mm. or the use of spare parts and accessories that are important to the operation of the system that are not original Truma parts If the distance between outside wall and heater is more than...

  • Page 7: Water Connection

    5. Fasten sealing frame (3) to the cowl body using 4 self-cut- delivery) must be used. ting screws (4). As special accessories Truma supplies the water connectors (12 + 13) and Safety/drain valve (14) with a 10 mm / 3/8" di- ameter hose nipple (please refer to the last page).

  • Page 8: Gas Connection

    Safety/drain valve and water must be established in accordance with the Truma interface pump in accordance to the descriptions (refer to Electrical connection 230 V). Any modi- direction of flow. Fasten the fication made to the Truma components pertaining to this pressure reducer to the floor.

  • Page 9: Function Check

    Connect control panel cable, supply line 230 / 240 V and all users (e. g. on the wardrobe door)! Ask Truma to send you heating element cable as shown in the drawing.
  • Page 10 Boiler L. P. Gas and 230 / 240 V Electric Storage Water Heater Model B 10 / B 14 from 11/2003 When ordering spare-parts, please always specify the fabrication number and year of make...
  • Page 11 Safety/drain valve (400 kPa), 10 mm / 3/8" Cowl extension for wall thicknesses over 35 mm 70131-00 Cowl extension VBO 2 ✂ Boiler L. P. Gas and 230 / 240 V Electric Storage Water Heater Model B 10 / B 14 from 11/2003...
  • Page 12 Facsimile: (03) 95 45 59 66 New Zealand Facsimile: (04) 232 38 78 ✂ Boiler L. P. Gas and 230/240 V Electric Storage Water Heater Model B 10/B 14 from 11/2003 Garantiekarte Händler-Adresse Dealer’s address Guarantee Card Adresse du commerçant...
