TRIPLETT
Model
9045
True RMS
Digital Multimeter
Instruction Manual

Advertisement

Table of Contents
loading

Related Manuals for Triplett 9045

Summary of Contents for Triplett 9045

  • Page 1 TRIPLETT Model 9045 True RMS Digital Multimeter Instruction Manual...

  • Page 2: Introduction

    10. Warranty 1: INTRODUCTION The Triplett Model 9045 is a 6000 count, autoranging, True RMS, handheld Digi- tal Multimeter with a 61 segment bargraph in its backlit Liquid Crystal Display. At its core is an LSI (Large Scale Integration) integrated circuit which uses dual slope A/D conversion for stability and accuracy.
  • Page 3 2.9 Check the condition of the test leads before making a measurement. Do not use the test leads if there is damaged insulation or exposed metal. Failure to observe this precaution may result in damage to the meter or injury to the user. Triplett Model 9045...
  • Page 4 2.19 Replace fuses only with exact or equivalent fuses. Do not “bridge” fuses out of circuit. Failure to observe this precaution may result in damage to the meter or injury to the user. Triplett Model 9045...
  • Page 5 The meter will not read AC voltage if it is set to DC, nor will it read DC if it is set to AC. For example, if the meter is set to measure DC Volts, it will not measure a dangerous AC voltage, even if the probes are inserted into a household AC wall outlet. Triplett Model 9045...
  • Page 6 2.38 Do not use the meter if it has undergone long-term storage under unfavor- able conditions. Failure to observe this precaution may result in damage to the meter or injury to the user. Triplett Model 9045...
  • Page 7 Chemical leakage from the battery could damage the meter, leading to user injury. 2.46 Do not use the meter if there is evidence of chemical leakage from the battery. Leakage could damage meter and lead to injury of user. Triplett Model 9045...

  • Page 8: International Symbols

    Low Battery Ground See Instruction Manual Fuse Double Insulated Beeper Diode AC or DC Dangerous Voltages Capacitance Triplett Model 9045...

  • Page 9: Product Features

    4.21 Safety Designed to Comply with IEC 1010-1 (CE) 4.22 CAT III / 600V and CAT II / 1000V Rated 4.23 3 Year Warranty 4.24 Includes: Safety Test Leads with Screw-On Alligator Clips, Thermocouple Probe and Adaptor, 9 Volt Battery Triplett Model 9045...
  • Page 10 7.0 x 3.7 x 1.5 inches (L x W x H) 5.9 Weight: 300 grams, 0.7 lbs. (w/ battery, w/o leads) 5.10 Battery: 1 standard 9 volt alkaline battery (Triplett PN: 37-48) 5.11 Battery Life: approx. 100 hours 5.12 Fuse: 800mA / 250 or 600 volt FAST, 5 x 20mm fuse, for uA or mA ranges.
  • Page 11 ± t i g ± . n i 6 µA 0 µA t i g ± 0 6 µA 1µA 0 1 µA t i g ± t i g ± . n i Triplett Model 9045...
  • Page 12 A ± 4µF ± 0 4 µF 4 µF ± 0 4 µF 1µF ± t i s i v i : y t Triplett Model 9045...

  • Page 13: Front Panel And Lcd Display 13

    . r a t i g ± 6: 9045 FRONT PANEL AND LCD DISPLAY 1) LCD Display 2) Test Probe Holders 3) Data HOLD and Backlight Button 4) Rotary FUNCTION Selector Switch 5) Input Jack for Voltage, Resistance, Capacitance,...
  • Page 14 FRONT PANEL OF 9045 Triplett Model 9045...
  • Page 15 REL (sometimes called Delta) mode is activated. is displayed when the Diode Test mode is activated. is displayed when the Continuity Beeper mode is activated. is displayed when the Auto Power Off feature is activated. Triplett Model 9045...
  • Page 16 0 to 30, half the length of the bargraph, indicating that the measured quantity is 1/ 2 of the range setting. This feature is often used for “nulling” or “peaking” adjust- ments, which are easier to visualize on the bargraph, rather than examining the numeric digital reading. Triplett Model 9045...
  • Page 17 7.1.3 The SELECT Button The 9045 has several test functions available on one position of the rotary FUNCTION switch. To access the different functions, the SELECT button is momentarily pressed, repeatedly if necessary, until the desired function is obtained.
  • Page 18 Test, or Continuity modes. 7.1.6 MAX / MIN Mode The 9045 contains a convenient memory that remembers the Maximum and Minimum values measured by the meter. The feature can be used for a few minutes or several hours to memorize the Maximum and Minimum values measured by the meter.
  • Page 19 Hz (Frequency) and Duty (Duty Cycle) can be measured in two different ways on the 9045. The method chosen depends on the type of measurement be- ing made by the user. The Hz / Duty button is used in both methods. See the following sections for specific information on performing the measurements.
  • Page 20 7.2.1.4 If the display indicates overrange, i.e. “OL”, disconnect the test probes from the circuit immediately! The voltage exceeds the measurement range of the 9045. 7.2.1.5 To set the range manually, press the RANGE button, repeatedly if neces- sary, to select the desired range. Observe the position of the decimal point and the annunciators to identify the selected range.
  • Page 21 7.2.2.4 If the display indicates overrange, i.e. “OL”, disconnect the test probes from the circuit immediately! The voltage exceeds the measurement range of the 9045. 7.2.2.5 To set the range manually, press the RANGE button, repeatedly if neces- sary, to select the desired range. Observe the position of the decimal point and the annunciators to identify the selected range.
  • Page 22 7.2.4.1 Connect the black test lead to the COM jack. Connect the red test lead to the 10A jack unless it is known that the input current is less than 600mA or 6000uA. If the current is less than 6000uA or 600mA, connect the red test lead to the uA/mA jack. Triplett Model 9045...
  • Page 23 7.2.4.6 To set the range manually, press the RANGE button, repeatedly if neces- sary, to select the desired range. Observe the position of the decimal point and the annunciators to identify the selected range. Triplett Model 9045...

  • Page 24: Resistance

    7.2.6 Continuity Beeper WARNING!!! Do not apply voltage or current to the meter when the FUNCTION switch is set to 7.2.6.1 Connect the black test lead to the COM jack, and the red test lead to the jack. Triplett Model 9045...

  • Page 25: Diode

    (“OL”). If the display reads “0.000 v” when the leads are connected in either direction to a standard silicon diode, the diode is probably shorted. Note: The reading displayed on the LCD is an accurate indication of the voltage drop of the device or circuit being measured. Triplett Model 9045...

  • Page 26: Capacitance

    10 and 20 seconds to measure. If the display indicates OL, the capacitor is larger than the meter will measure, or it is leaky or shorted. Measurements on capacitors with values less than 10nF are not accurate. Triplett Model 9045...

  • Page 27: Temperature

    7.2.10 Measuring Frequency and Duty Cycle Frequency and Duty Cycle can be measured in several different ways on the Triplett 9045. The method chosen depends on the type of measurement being made. For wideband low level measurements, such as measurements...

  • Page 28: Maintenance

    8: MAINTENANCE Your Triplett Model 9045 DMM is a precision measuring instrument and, when used as described in this manual, should not require maintenance. However, periodic calibration of the meter will insure that it is accurate and per- forming in accordance with its design specifications.
  • Page 29 TRIPLETT PRODUCT RETURN INSTRUCTIONS In the unlikely event that you must return your Triplett equipment for repair, the following steps must be taken. 1) Call 1-800-TRIPLETT to obtain a Return Material Authorization (RMA) number from Customer Service. 2) Enclose a copy of the original sales receipt showing date of purchase.
  • Page 30 8.2.5 Locate the defective fuse and replace with the exact or equivalent type. See meter specifications. 8.2.6 Reassemble case of meter. Reinstall screws. 8.2.7 Verify that the meter operates properly before using it to make measurements. Fuse: 800mA/250V or 600V FAST Fuse: 10A/250V or 600V FAST Triplett Model 9045...

  • Page 31: Accessories

    10A / 250V FAST, 1/4" x 1", Triplett PN 3207-125 10A / 600V FAST, 1/4" x 1", Triplett PN 3207-128 9.3 An optional carrying case is available for the 9045. It’s constructed of Cordura, with a Velcro secured flap, a belt loop on the back, and a padded interior.

  • Page 32: Warranty

    Triplett Corporation may have, including incidental or consequential damages.
