Connecting to Video Sources

1. Power Cord
2. Microphone Cable *
3. Audio Cable Jack/RCA *
4. S-Video Cable *
5. Audio Cable *
Due to the difference in applications for each country, some regions may have different accessories.
N N
ote ote
* Optional accessory
English ... 12
Video output
1 2 5
Audio Output
Power socket
DVD player, Set-top box,
HDTV receiver
3 9 5 6
LAN
3 4 5 6
DVD player, Set-top box,
S-Video output
HDTV receiver
6. VGA to HDTV (RCA) Cable *
7. HDMI Cable *
8. 12V DC Jack *
9. Composite Video Cable *
7 8
+12V Output
