Connection Ports

1
2
3
9
10
1.
Mini USB Connector
2.
HDMI Connector
3.
VGA Output Connector
4.
LAN Connector (WXGA)
5.
Audio In 1 Connector (For VGA In 1 Connector)
6.
S-Video Connector
7.
Left/Right RCA Audio Input Connector (For S-Video Connector)
8.
Audio Output Connector
9.
12V Trigger Relay Connector (12V, 250mA)
10.
RS232 Connector
11.
VGA In 1 Connector
12.
VGA In 2 Connector
13.
Audio In 2 Connector (For VGA In 2 Connector)
14.
Composite Video Input Connector
15.
Left/Right RCA Audio Input Connector (For Composite Video Input Connector)
16.
3.5mm Microphone Input Connector
17.
Power Socket
4
5
6
11
12
13
14
7
8
15
16
17
... English
9
