- Page 1 TECHNICAL DATA & SERVICE MANUAL ARGO HPL/SCL 0.8180.612.01 06/2012 Pagina 1...
-
Page 2: Table Of Contents
Table of contents Page SPECIFICATIONS 1) Unit specifications 2) Major Component specifications OPERATING RANGE DIMENSIONAL DATA REFRIGERANT FLOW DIAGRAMS FUNCTIONS 1) System operation control 2) Cool Mode Operation 3) Heat Mode Operation 4) Auto Mode Operation 5) Dry Mode Operation 6) Fan Mode Operation 7) Auto Fan Speed 8) Forced Mode... -
Page 3: Specifications
SPECIFICATIONS 1) UNIT SPECIFICATIONS UNIT MODEL ARGO HPL/SCL Power source 220 - 240 V 50 Hz PERFORMANCES COOLING HEATING Capacity (air BTU / h 6310 7750 conditioner) 1,85 2,27 Air circulation (high/med/low) 670-540-130 Moisture removal (high speed) Cooling l / h... -
Page 4: Major Component Specifications
2) MAJOR COMPONENT SPECIFICATIONS UNIT MODEL ARGO HPL/SCL CONTROLLER (PCB) Part No. sac dci ODU Controls Microprocessor Control circuit fuse (F1) 6,3x32 - 12,5A SWITCH INDICATOR ASSY Model 384208055 Led color TMR : blu - STB : orange - OPR : green... - Page 5 ARGO HPL/SCL UNIT MODEL Rotary ( Hermetic) COMPRESSOR (CM) Model UG9A090FUAJP Nominal cooling capacity 2770 oil: Freol a68ES-T or SUNICE T-68 Coil resistance (at 20° C) Ω U-V : 2.78 Ω V-W : 2.83 Ω W-U : 2.73 software protection...
-
Page 6: Boperating Range
ARGO HPL/SCL UNIT MODEL CONDENSATE PUMP (PC) Model 291036 Rating 220-240VAC~50Hz Nominal intput 5W - 0,05A Coil resistance (at 20° C) Ω 778 ± 8% FLAP MOTOR (FLP) Type Stepping motor Model MP24GA1 Rating DC 12V Coil resistence (Ambient temp. 25°C) Ω... -
Page 7: Cdimensional Data
DIMENSIONAL DATA Pagina 7... -
Page 8: Drefrigerant Flow Diagrams
REFRIGERANT FLOW DIAGRAM ARGO HPL/SCL Pagina 8... -
Page 9: Efunctions
FUNCTIONS 1 System operation control The units receives the user input (fan speed, flap position etc) through remote controller which sends signal every time a button is pressed and in any case, automatically, every 5 minutes. During operation compressor speed can be subjected to change due to thermal load variations or protection activations but in any case: •... -
Page 10: Auto Mode Operation
4 Auto Mode Operation In Auto Mode, the unit switches automatically between the Auto Cooling and Auto Heating in order to maintain the room temperature (RAT) at the prescribed set point (SPT). The switching between the two modes is according to the above graph and following table COOLING --->... -
Page 11: Dry Mode Operation
5 Dry Mode Operation Dry operation remove moisture from indoor air running, in cooling mode, at a low level without reducing the ambient temperature. This is done cycling ON and OFF the unit according to table below. ROOM DRY LEVEL TEMP ≥... -
Page 12: Forced Mode
8 Forced Mode In this mode the system operates (COOLING or HEATING mode – fixed settings) or is switched off by means of the MODE button on the pcb receiver. The operation modes can be selected pressing the button in a cyclic way (OFF COOL HEAT OFF…). The settings are: COOLING mode SET POINT temperature = 25°C FAN SPEED = HIGH... - Page 13 9.4 Overheat outdoor exchanger During cooling operation as soon as the outdoor coil temperature (OCT) increases, compressor speed is reduced in order to avoid heat exchanger overheating. System stops compressor operation when OCT reaches 65 °C 9.5 Compressor discharge temperature During operation, as soon as the discharge temperature increases, (CDT) compressor speed is reduced in order to avoid overheating of the motor.
-
Page 14: Defrost
10 Defrost The defrost process is controlled by a detection algorithm designed in order to mantain optimal utilization of the heat pump capacity especially during negative outdoor temperature conditions. • Compressor speed fixed • Expansion valve opening fixed • Outdoor fan switched off •... -
Page 15: Night Function
14 NIGHT Function When this setting is active indoor fan speed is automatically reduced in order to allow low noise operation.Temperature control acts in the same way as NORMAL MODE but after 60 minutes of operation the air conditioner modifies automatically the set-point temperature according to the following: •COOLING/DRY: +1°C •HEATING: - 2°C... -
Page 16: Diagnostic
17 Diagnostic With this feature is possible to have a visual signal that a trouble is occurring. This mode is always active and the signalling is made through the display board LEDS . In case of no troubles the LEDS status follows its normal function. The detected troubles are showed to the user/technician using the 3 leds of the receiver For each fault there are different effects upon the operation of the A/C: NOTES... -
Page 17: Address
18 Address Changing the Address of the Air Conditioner In case of more than one air conditioner operating in the same room, it may be necessary to assign an address to each unit in order to avoid operation conflicts. Address is set acting on jumpers located on the unit PCB and on dip-switches of the remote controller. -
Page 18: Manual Unit Control And Led Indicators
19 Manual Unit Control and LED indicators The push button switch and the LED indicators on display panel let the user to control the unit operation without a R/C (Remote Controller). Their operations are provided below. Push Button Switch : Use to cycle the operation mode of the A/C unit among COOL, HEAT and OFF modes, without using the R/C. -
Page 19: Drain Pump
20 Drain pump Pump operates when the unit is running in COOLING and DRY modes. The level detection is done through a float switch connected at the input FS (closed under normal condition, and opened when water overflows). System operation is according to the following chart: 21 Safety thermostat The unit is equipped with a double safety system to prevent overtemperature of the electrical heater... -
Page 20: Felectric Wiring Diagrams
ELECTRIC WIRING DIAGRAMS ARGO HPL/SCL LEGENDA Controller Indicator assy SW-IND-ASSY Indoor fan motor Thermistor TH1-2-3-4-5 Compressor motor safety thermostat Outdoor fan motor automatic thermostat Electric heater Emi filter Capacitor Float switch C1-2 Condensate pump motor Flap motor 4-way valve power relay... -
Page 21: Gtroubleshooting
TROUBLESHOOTING CHECK BEFORE AND AFTER «TROUBLESHOOTING» (A) Check power supply wiring. • Check the power supply wires are correctly connected. (B) Check power supply. • Check that voltage is in specified range (±10% of the rating). • Check that power is being supplied. •... - Page 22 UNIT DOES NOT RUN. 3.1 - THERE IS NO SIGNALING LED ON UNIT Check power supply. Is power being supplied to wall receptacle? The receiver Check fuse on pcb. Is the assy is fuse blown? disconnected or defective Circuit There is a possibility breaker is Power failure Check EMI filter.
- Page 23 UNIT DOES NOT RUN. 3.2 -THERE IS ONE LED ON AT LEAST AND THE UNIT DOES NOT RECEIVES THE REMOTE CONTROL SIGNAL Check the remote Try with controller and Receiver PCB assy another PCB settings for assy may be may be remote address defective...
- Page 24 UNIT DOES NOT RUN. 3.4- THERE IS ONE LED BLINKING AT LEAST TEMPERATURE COMPRESSOR WATER LEVEL ALARM SENSOR DAMAGED OVERCURRENT/ OVERTEMPERATURE OR PFC FAULT Drain the water from Check sensor the service tube connection and There is a possibility of measure its a short circuit resistance...
- Page 25 UNIT DOES NOT RUN OR RUN FOR FEW MINUTES AND NO FAULT IS DISPLAYED Before checking the unit with this test, follow these 4 steps 1) Turn off power supply 2) Wait 1 minute until the receiver leds switch off 3) Turn on power supply 4) Wait until the system starts (about 3 minutes) Pagina 25...
- Page 26 AIR CONDITIONER OPERATES, BUT ABNORMALITIES ARE OBSERVED. Change the Is the remote controller position of the directly under the airflow remote controller of the unit? Is the unit in ECO Set the unit in HI POWER mode mode? Set fan speed in Is the fan motor set in medium or high low speed?
- Page 27 ELECTRICAL HEATER DOES NOT WORK Before checking the unit with this test, follow these 3 steps 1) Switch the unit in FAN HEATER mode and fan on LOW speed for 3 minutes 2) Measure the power or current consumption directly from the power supply line Is the consumption much lower than the declared power input of...
- Page 28 AIR CONDITIONER OPERATES, BUT ABNORMALITIES ARE OBSERVED. 1 - OPERATION DOES NOT SWITCH FROM HEAT TO COOL AND FROM COOL TO HEAT Remote controller Receiver assy Check the connection Check resistance of unit may be defective may be defective of reversing valve coil reversing valve coil UNUSUAL NOISE IS OBSERVED Check that internal...
-
Page 29: Hchecking Electrical Components
CHECKING ELECTRICAL COMPONENTS 1 Measurement of Insulation Resistance The insulation is in good condition if the resistance exceeds 1 Mohm a) Power Supply Wires Clamp the earthed wire of the power supply wires with the lead clip of the insulation resistance tester and measure the resistance by placing a probe on either of the power wires (fig.1). - Page 30 Via Varese, 90 - 21013 Gallarate - Va - Italy Tel. +39 0331 755111 - Fax +39 0331 776240 www.argoclima.it Pagina 30...
