TECHNICAL DATA & SERVICE MANUAL INDOOR UNIT: AW52AL AW64AL SPLIT SYSTEM AIR CONDITIONER Model No. Product Code No. AW52AL 387030095 AW64AL 387030096 0.8180.463.0 07/05... - Page 2 • Ground the unit following local electrical codes. IMPORTANT! • The Yellow/Green wire cannot be used for any connection Please read before installation different from the ground connection. • Connect all wiring tightly. Loose wiring may cause overheating This air conditioning system meets strict safety and operating at connection points and a possible fire hazard.
-
Page 3: Table Of Contents
Table of Contents Page 1. SPECIFICATIONS 1-1 Unit specifications 1-2 Major Component specifications 1-3 Other Component specifications 2. DIMENSIONAL DATA 3. SOUND LEVEL CHARACTERISTICS 3-1 Sound pressure levels 4. ELECTRICAL DATA 4-1 Electric Wiring Diagrams 5. CONTROL SYSTEM 5-1 Electronic control 5-2 Legend 5-3 PCB 5-4 General Functions... -
Page 4: Specifications
1. SPECIFICATIONS 1-1 Unit Specifications AW52AL 220 - 240V ~ 50Hz Power source 230V - 50 Hz Voltage rating Cooling Heating Performance See catalogue with the requested matching Capacity Air circulation (High) m³/h Features Microprocessor/ I.C. thermostat Controls/Temperature controls Wireless remote control unit... - Page 5 AW64AL 220 - 240V ~ 50Hz Power source 230V - 50 Hz Voltage rating Cooling Heating Performance See catalogue with the requested matching Capacity Air circulation (High) m³/h Features Microprocessor/ I.C. thermostat Controls/Temperature controls Wireless remote control unit Control unit Timer ON/OFF 24 hours 3 and Auto...
-
Page 6: Major Component Specifications
1-2 Major Component Specifications AW52AL Controller PCB Part No. Controls Microprocessor Control circuit fuse 250 V - 3,15 A RC-7 (RC) Remote Control Unit Fan & Fan Motor Cross - flow Type 1…. Ø 92 Q'ty ……. Dia. and lenght RPS18M-2…1... - Page 7 AW64AL Controller PCB Part No. Microprocessor Controls Control circuit fuse 250 V - 3,15 A RC-7 (RC) Remote Control Unit Fan & Fan Motor Cross - flow Type 1…. Ø 92 Q'ty ……. Dia. and lenght RPS30G-2…1 Fan motor model…Q'ty 4…1300 No.
-
Page 8: Other Component Specifications
1-3 Other Component Specifications AW52AL AW64AL NTC-THERMISTOR Thermistor ( Coil sensor ) ΚΩ 10 at 25 °C Resistance NTC-THERMISTOR Thermistor ( Room sensor ) ΚΩ 10 at 25 °C Resistance... -
Page 9: Dimensional Data
2. DIMENSIONAL DATA... -
Page 10: Sound Level Characteristics
3. SOUND LEVEL CHARACTERISTICS AW52AL AW64AL... -
Page 11: Electrical Data
4. ELECTRICAL DATA 4-1 Electric Wiring Diagrams... - Page 47 Via Varese, 90 - 21013 Gallarate - Va - Italy Tel. +39 0331 755111 - Fax +39 0331 776240 www.argoclima.it...
