1-2-2 Unpacking

Unpacking
120V AC model
4
16
7
1. Machine
2. Plastic bag
3. Bottom spacer
4. Machine cover
5. Outer case
6. Bottom right pad
Place the machine on a level surface.
13
17
6
5
Figure 1-2-2
7. Bottom left pad
8. Top right pad
9. Top left pad
10. Toner container K
11. Toner container M
12. Toner container C
1-2-2
10
11
12
9
2
13. Toner container Y
14. Waste toner box
15. Power cord
16. Left spacer
17. Operation guide etc.
