2KT/2KV

1-6-2 Remarks on engine PWB replacement

When replacing the engine PWB, remove the EEPROM (U1) from the engine PWB that has been removed
and then reattach it to the new engine PWB.
EEPROM
EEPROM
U1
Engine PWB
Figure 1-6-2
1-6-2
