(4) Direction of installing the principal fan motors
When detaching or refitting the fan motors, be careful of the airflow direction (intake or exhaust).
Intake
Intake
Intake
Container fan motor
(Rating label: Inside)
Left fan motor
(Rating label: Inside)
Figure 1-5-77
1-5-51
Right fan motor
(Rating label: Inside)
Fuser fan motor
(Rating label: Inside)
Intake
2KT/2KV
