KTC Compact Cameras
4
I
NSTALLING THE
Depending on the type of housing used, it will probably be necessary to
feed the cables through the housing before connecting them to the
camera. In addition, it may be helpful to install the camera into the
housing before making cable connections.
For installation instructions, refer to the manual for the housing being
used. If you are using a Low-Cost Housing, see the KTA-L installation
instruction manual.
Figure 5. Compact camera installed in Low-Cost Housing
CAUTION:
Do not expose the camera to moisture.
1040206A / December 2002
Installing the Camera into a Housing
C
AMERA INTO A
H
OUSING
9
