‘Times And Thresholds’ Menu - BIANCHI VENDING LEI700 Use And Maintenance Manual

Ton product X T on motoreducer third product [0...25.5 s]
Toff product X T off motoreducer third product [0...25.5 s]
Third E.V. X Number 1^EV [0...8-Cold] 0=E.V. not coupled
to this button
T 3^ E.V. T opening third E.V. [0...99.9 s]
R 3^ E.V. Opening delay 3rd E.V. [0...25.5 s]
T Mixer 3E.V. T Mixer coupled to 3rd E.V. [0...25.5 s]
R Mixer 3^E.V. Mixer delay coupled to 3rd E.V. [0...25.5 s]
T product X T first box coupled to 3rd E.V. [0...25.5 s]
R product X First box delay coupled to 3rd E.V.
[0...25.5 s]
Ton product X T on motoreducer first product [0...25.5 s]
Toff product X T off motoreducer first product [0...25.5 s]
T product X T 2nd box coupled to E.V. [0...25.5 s]
R product X Delay 2nd box coupled to 3rd E.V.
[0...25.5 s]
Ton product X T on motoreducer second product
[0...25.5 s]
Toff product X T off motoreducer second product
[0...25.5 s]
T product X T 3rd box coupled to 3rd E.V. [0...25.5s]
R product X 3rd box delay coupled to 3rd E.V. [0...25.5]
Ton product X T on motoreducer third product [0...25.5s]
Toff product X T off motoreducer third product [0...25.5s]
T Sugar Espresso X T sugar espresso [0...25.5 s]
T Sugar MB T sugar [0...25.5 s] only with MultiBrand
Keyboard
H O MB Water EV sugar [0...25.5 s] only with Multi
2
Brand Keyboard and Instant Distributor.
Double Product 1
E.V. X Number 1^EV [0...8] 0=E.V. not coupled to
this button
T E.V. d.p. T opening- E.V. [0...99.9 s]
R E.V. d.p. Opening delay -E.V. [0...25.5 s]
T Mixer 1E.V. T Mixer coupled to E.V. [0...25.5 s]
R Mixer 1^E.V. Mixer Delay coupled to E.V. [0...25.5 s]
T product X T first box coupled to E.V. [0...99.9s]
R product X First box delay coupled to E.V. [0...25.5 s]
Ton Product X T on motoreducer double product
[0...25.5s]
Toff Product X T off motoreducer double product
[0...25.5s]
Double Product 2
E.V. X Number 1^EV [0...8] 0=E.V. not coupled to
this button
T E.V. d.p. T opening E.V. [0...99.9 s]
R E.V. d.p. Opening delay E.V.
T Mixer 1E.V. T Mixer coupled to E.V. [0...25.5 s]
R Mixer 1^E.V. Mixer delay coupled to E.V. [0...25.5 s]
T product X T firt box coupled to E.V. [0...99.9s]
R product X First box delay coupled to E.V. [0...25.5s]
Ton product X T on motoreducer double product
[0...25.5s]
Toff product X T off motoreducer double product
[0...25.5s]
5.3.5 'Times and Thresholds' Menu
Pump Timeout
Load Timeout
T-out motors slave X
Grinder timeout
Grinder threshold
T. coffee preparation Coffee preparation time [2.9÷23.0 s]. Linked
T. cleaning
S/T Pump Time
Cold cleaning
Timeout Lift x
Attempt
Cabinet x [0-3]
Extra time sector X Additional movement in case of failed passage
Time prel. Ev X
[0...25.5 s]
34
Pump timeout [0÷90 s]
Water load timeout [5÷240 s] Load timeout
linked to the Water Entry EV in DC in case
of A/R distributor or to immersion pump in
case of S/A distributor. Whenever errors are
reset, also this timeout will be reset.
BVM600 spiral motor timeout [0÷25.0 s].
The wording Slave X shows the number of
slave linked to MASTER distributor.
In the management of the spiral distribution
there is an additional internal timeout for
complete distribution. This timeout is equal
to the max motor timeout, i.e. 25.5 s.
Grinder timeout [0÷25.5 s]
Threshold to read grinder current
[5.0÷18.0]
to automatic grinding.
Cleaning water time [0÷25.5 s]
Advanced pump start time for train tank
[0.0 – 5.0 s]
Cold cleaning management [Yes/No] For
models with cool unit only. Before making a
cold drink the hydrauic circuit is cooled with
a cold water cleaning.
Timeout Lift [0÷25.5s ]. Time within which
the lift must complete a selection.
If the cabinet times are equal to 0 this para-
meter will appear that allows to choose the
number of failures after which the spiral goes
to alarm mode.
Default 1.
of the product further to a selection [0.0 ...
1.0s]. X=11 to 68 and corresponds to every
spiral installed in the distributor (priority over
cabinet attempts). If the parameter is set to
0, this function will not be available and the
management logic will change giving the pos-
sibility of managing the cabinet attempts.
If the distributor consists of 5 cabinets, it will
obscure the parameter for cabinets 6-7-8.
Every 0,1 s in empty conditions will corre-
spond to approx. 12 degrees of movement
of a spiral. Default value 0,3 s.
Programming goes from a minimum of 0.0
s to a maximum of 10.0 s and it is possible
only for the actually installed electrovalves
except for espresso coffee electrovalve.
It consists in enabling, for the set time, the
electrovalves involved in the distribution
(except for the espresso coffee electro-
valve) if the time passed from the last
distribution of the relevant electrovavle is
longer than 60s.
