FV2006
Mini Vantal Dome IP Camera
Quick User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FV2006 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AVer FV2006

Summary of Contents for AVer FV2006

  • Page 1 FV2006 Mini Vantal Dome IP Camera Quick User Guide...

  • Page 2: Table Of Contents

    III. IP Assignment ......................8 Finding IP Camera by using “NXU Lite recording software” ..........8 Finding IP Camera by using “AVer IPCam Utility” ............11 Using NON-DHCP Server/Router Network ..............13 Connecting the IP Camera ..................15 COPYRIGHT ........................16 NOTICE ..........................

  • Page 3: Before Installation

    ENGLISH Before Installation Before installation, please be sure to read this quick installation guide and user’s manual carefully to complete the installation. Camera Introduction The following section introduces package contents, hardware installation, factory default reset, and SD card Compatibility List of each type camera. 1.

  • Page 4: Hardware Installation

    Hardware Installation 1. Set the camera Locate cable from bottom a. Use three screws to lock the base of camera on the ceiling or the wall. b. Put back the cover, and turn it tightly to get waterproof.
  • Page 5 ENGLISH Locate cable from side a. Open the conversion ring package in accessory. It includes a conversion ring and two set of screws. b. Use three screws to lock the conversion ring on the ceiling or the wall. c. Use three screws to combine the base of camera with the conversion ring. The cable can pass through the hole on the side of conversion ring.
  • Page 6 2. When removing the dome cover, you can see the Micro SD card slot and the reset button. 3. I/O Interface I/O Connection a. Please connect the GND & DO pin to the external relay (buzzer) device. b. Please connect the GND & DI pin to the external trigger device.

  • Page 7: Factory Default

    ENGLISH Factory Default 1. To recover the default IP address and password, please follow the following steps. 2. Remove power and Ethernet cable and the dome cover. 3. Press and hold the button and connect power and Ethernet cable to the camera again and hold for round 20 seconds for system booting.

  • Page 8: Sd Card Compatibility List

    3. SD card Compatibility List FV2006 is compliant with microSD/SDHC card and to ensure recording quality, and please use memory cards over 2G and Class 4 above (Max. 32G) MicroSD/SDHC card Transcend SDHC class4 16GB Transcend SD class4 16GB Transcend SDHC class4 32GB...

  • Page 9: Monitor Setting

    ENGLISH Monitor Setting 1. Right-click on the desktop. Select “ Properties” 2. Change “Color quality” to “Highest (32-bit)”.

  • Page 10: Ip Assignment

    Finding IP Camera by using “NXU Lite recording software” − Finding IP Camera by using “AVer IPCam Utility” Finding IP Camera by using “NXU Lite recording software” 1. The NXU Lite software is in the attached software CD. Before launching it, please install the software first.
  • Page 11 ENGLISH 3. Click “Setup” button. 4. Click “Add IPCam” button. 5. Select “IP Camera” item.
  • Page 12 6. Enter the IP Camera’s ID and Password (default is admin/admin) and click “Auto Search” to find camera. 7. In Search Result window, click it the IP camera model that user has purchased (Please ignore ONVIF connection item); the camera is in red text that is configurable. User can double-click on the camera is in red text and configure the IP camera’s setting;...

  • Page 13: Finding Ip Camera By Using "Aver Ipcam Utility

    ENGLISH Finding IP Camera by using “AVer IPCam Utility” 1. Use the software, “AVer IPCam Utility” to assign the IP address of the IP camera. The software is in the attached software CD. 2. Run the IPCam Utility 3. Select the proper network adapter and click [Search] to begin searching.
  • Page 14 5. The IE browser will open and direct you to IP camera login page. This requires IPViewer.ocx to run. If the IE ActiveX warning message appears, click to allow running the add-on. [Note] The default IP address is: 192.168.1.168 The default ID and Password are both ”admin”. It is not allowed to enter device name in Chinese and any other special characters (' "...

  • Page 15: Using Non-Dhcp Server/Router Network

    ENGLISH Using NON-DHCP Server/Router Network In Non-DHCP server/router network, the static IP address must be assigned to the device each time when adding another IP camera to the network; the default IP address of the current one must be changed to avoid conflict. Please make sure the Subnet of the PC’s IP address and the IP camera’s IP address are the same.
  • Page 16 A quick way to access remote monitoring is to double-click on a selected IP camera in “Camera Name list” in AVer IPCam Utility. Then, the IE browser will open and connect to IP camera. Then, please key in the default “ID” and “Password”, both of which are “admin”.

  • Page 17: Connecting The Ip Camera

    ENGLISH Connecting the IP Camera Launch the Internet Explorer browser, type the IP address of the IP camera in the address field. It will show the following dialogue box. Key-in the ”ID” and “Password”. The default ”ID” and “Password” are both “admin”. Once connected to the IP camera, the following program interface will appear.

  • Page 18: Copyright

    © 2013 AVer Information Inc. All rights reserved. All rights of this object belong to AVer Information Inc. Reproduced or transmitted in any form or by any means without the prior written permission of AVer Information Inc. is prohibited. All information or specifications are subject to change without prior notice.

  • Page 19: Limited Warranty

    You as the original purchaser. Except for the foregoing, the Product is provided “AS IS.” In no event does AVer warrant that You will be able to operate the Product without problems or interruptions, or that the Product is suitable for your purposes. Your exclusive remedy and the entire liability of AVer under this paragraph shall be, at AVer’s option, the repair or replacement...

  • Page 20: Governing Law And Your Rights

    Governing Law and Your Rights This warranty gives you specific legal rights; You may also have other rights granted under state law. These rights vary from state to state.
