Summary of Contents for AVer VB350

  • Page 1 VB350 Conference Camera User Manual...
  • Page 2 FEDERAL COMMUNICATIONS COMMISSION NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 3 © 2023 AVer Information Inc. All rights reserved. | February 24, 2023 All rights of this object belong to AVer Information Inc. Reproduced or transm itted in any form or by any means without the prior written permission of AVer Information Inc. is prohibited. All information or specifications are subject to change without prior notice.
  • Page 4 WARNING  To reduce risk of fire or electric shock, do not expose this appliance to rain or moisture. Warranty will be void if any unauthorized modifications are done to the product.  Do not drop the camera or subject it to physical shock. ...
  • Page 5 Tel: +81 (0) 3 5989 0290 テクニカル・サポート: https://jp.aver.com/technical-support Vietnam Branch Office Công ty TNHH AVer Information (Việt Nam) Tầng 5, 596 Nguyễn Đình Chiểu, P.3, Quận 3, Thành phố Hồ Chí Minh 700000, Việt Nam Tel: +84 (0)28 22 539 211...

  • Page 6: Table Of Contents

    Contents Package Contents ......................1 Optional Accessories ...................... 2 Product Introduction ......................3 Overview ......................... 3 LED Indicator ........................4 Remote Control....................... 5 Connection and Installation ..................... 8 Device Connection......................8 Ethernet Connection ..................... 10 BT Dongle Installation ....................11 Expansion Microphone Installation (Optional) ..............
  • Page 7 Home Position ..................... 34 Sleep Position ..................... 34 Sleep Timer ......................34 On Screen Menu ....................35 Save Preset......................35 Image Settings ......................35 Image Flip ......................35 Image Mirror ......................36 WDR ........................36 Flicker Decrease on IFP / Monitor ............... 36 Frequency ......................
  • Page 8 Keyboard Noise Suppression ................51 Phone In Jack ..................... 51 PTZApp 2 .......................... 52 Install PTZApp 2 ......................52 Use PTZApp 2 with USB Devices ................. 53 Smart Gallery Operation ....................63 EZLive ..........................65 Use AVer EZLive ......................65...

  • Page 9: Package Contents

    Package Contents Remote Control / Power Adaptor & USB 3.0 Type-B to VB350 Unit Power Cord* Type-A Cable (3m) Batteries** USB Type-A to Wall Mount Kit Tripod Screw (x2) QR Code Card Type-C Adapter 1/4”-20 L=7.5mm Drilling Paper * The power cord will vary depending on the standard power outlet of the country where it is sold.

  • Page 10: Optional Accessories

    Optional Accessories Expansion RJ-45 wired Expansion RJ-45 wired HDMI Cable microphone 10m/20m Speakerphone 10m/20m (3m) (Cable is included) (Cable is included) Audio-out Din6 to RS232 Adapter BT Dongle Converter TV VESA Mount Kit *Optional Accessories will vary depending on the country where it is sold.

  • Page 11: Product Introduction

    PTZApp 2 and purchase audio-out converter (TRS female to TRRS male) from AVer. ** BT dongle is an optional item in certain countries. Please contact your local dealer for purchasing. *** Support built-in USB 3.1 (Gen 1) to HDMI adapter technology. Support HDMI out 4K resolution on...

  • Page 12: Led Indicator

    LED Indicator Power on: Blink blue once Start-up: Solid red Power on completely but no USB connection: Solid orange Power and USB cable connected but device is idle or a call on hold: Solid white Video and audio on: Solid blue Calling: Fast blink white or blue depending on original status Video on and audio mute (During a call): Solid red A second calling: Fast blink white, blue, or purple depending on original status...

  • Page 13: Remote Control

    Remote Control Name Function One-click automatic FOV adjustment to fit all participants in screen 1. SmartFrame for one time. Press and hold the button for 1~2 sec to switch from manual to auto framing mode or Off. An icon message (as figure shown) will display on the left upper screen to indicate in SmartFrame status.
  • Page 14 Function Name Press and hold the button for 1~2 sec to switch modes among Audio 2. Audio AI Control tracking, Presentation mode, Audio fence and Off. An icon message (as figure shown) will display on the left upper screen to indicate in Audio AI status. If you don’t want to see the icon display, please go to PTZApp 2 or Web setting, find “On Screen Menu”...
  • Page 15  To start using the Bluetooth function, ensure to power-off the 3. Bluetooth camera and then plug-in the BT dongle to the USB port on the camera. After that, power-on the camera.  Hold it for 1~2 sec to enable Bluetooth pairing with mobile phone. Hold it again to switch to line in function.

  • Page 16: Connection And Installation

    Connection and Installation Device Connection Connect VB350 to PC/laptop with the provided USB 3.0* cable and connect the power cord of VB350 to power wall outlet. [Note] For cable management, you can have each cable go through the cable management slots on the rear-side of VB350.
  • Page 17 7 and MAC OS, a driver to support USB Display function is required for the TV/Monitor connection with VB350. Please use PTZApp 2 to install the driver. On the PTZApp 2, go to the System setup page. In the Install Driver of USB Display field, click the Start button and follow the on-screen instructions to install the driver.

  • Page 18: Ethernet Connection

    Ethernet Connection VB350 supports ethernet connection which allows user to access VB350 from remote site through browser. For Web accessing, please refer to <Make a Connection through the Browser>.

  • Page 19: Bt Dongle Installation

    BT Dongle Installation Use VB350 as mobile phone’s external audio device When using mobile phone to have a video call, users can connect their mobile phones to VB350 via Bluetooth connection to enjoy crystal clear audio quality. Install a BT dongle before powering up the device. Plug it into the USB 2.0 type-A port. Use remote...

  • Page 20: Expansion Microphone Installation (Optional)

    MIC OUT MIC IN 1. The port won’t be used while using with VB350. It doesn’t support daisy chain connection. 2. Connect the provided RJ45 cable to MIC OUT and connect the other side of RJ45 cable to side of...

  • Page 21: Expansion Speakerphone Installation (Optional)

    [Note] Cable is included with optional expansion speakerphone. There are two lengths of cables - 10m and 20m. 1. The port won’t be used while using with VB350. It doesn’t support daisy chain connection. 2. Micro USB port: while upgrading speakerphone FW, please find a micro USB cable and connect to PC.

  • Page 22: Wall Mount Installation

    Wall Mount Installation Attach the Drilling Paper to the wall and mark the two screw holes on the wall. Screw the support screws to the wall. Leave some space between the wall and screws for hanging the camera on the wall later.
  • Page 23 3. Align the mounting holes on the Wall Mount Kit with the two screws on the wall and hang the camera on the wall.

  • Page 24: Tv Vesa Mount Installation (Optional)

    TV VESA Mount Installation (Optional) Package Contents: Fixture x 2 Screw(M5*10) x 2 Silicone washer x 2 Screw(M6*15) x 4 Metal washer x 2 Screw(M6*20) x 4 Washer(M6) x 4 Screw(M8*20) x 4 Washer(M8) x 4 Screw(M8*30) x 4 Fix the screw (M5*10) with silicone washer in suitable holes (1~5). Fixture Silicon washer Screw(M5*10)
  • Page 25 Secure the fixture on the rear side panel of the camera. Don’t screw tight at this stage. You can select among the four screw holes for screwing the fixtures. Place the metal washers on the mount holes of TV. [Note] If users do not need to install the mount rack of TV, just skip step 3 to 5 and go to step 6.
  • Page 26 Place mount rack of TV on top of fixture. Secure the mount rack and fixture on the TV. Please do not screw tight at this stage. Then, adjust the mount rack and fixture to an appropriate position if needed. Finally, tightly screw all screws.
  • Page 27 If users don’t need to install mount rack of TV, then, secure the fixture on the TV. Then, adjust the fixture to an appropriate position if needed. Finally, tightly screw all screws. The device can be mounted on top of the TV or bottom of TV. Both ways of installation are the same and please follow the steps have described above.

  • Page 28: Getting Started

    PTZApp 2, refer to the PTZApp 2 section in this user manual. Make a Connection through the Browser VB350 has an Ethernet port for IP streaming and allows administrators to remotely control and set up the camera via an internet access. Moreover, VB350 also supports RTSP and RTMP functions. For Video Format Settings more details, please refer to page <...
  • Page 29 Click Login, the below non-personal usage data collection page appears. You can optionally check the icon of Allow anonymous usage data to help AVer continuously improve our products and services. Click Done, the main Web screen appears. If you want to disable the usage data collection, on the Web page of the camera, go to System >...
  • Page 30 * For information on how to install and use the PTZApp 2, please refer to the <PTZApp 2> chapter. ** To support IP address changes in groups, user can download AVer IP Finder app. 1. Download the IP Finder from https://www.aver.com/download-center (Headquarters &...

  • Page 31: Web Settings

    Web Settings VB350 supports Ethernet connection; users can enter the IP address into the Web browser to connect to the camera for detail settings. First Time Login To find the IP address of the camera, please refer to the <Make a Connection through the Browser>...

  • Page 32: Live Screen Operation

    Live Screen Operation User can control the camera direction, zoom in/out, and set preset position. [Note]  The system will force the previous login to log out, when there is a second login. If the web page is idle without any request for more than 4 hours, user will be logged out. ...

  • Page 33: Ptz Control

    PTZ Control You can use the PTZ Control page to configure up to 10 preset positions. In live screen, use ▲ , ▼ , ,  and zoom in/out buttons to adjust the camera screen view to desired position. Click Set and then click on a preset number (0~9), if you want to save this position to the selected preset number, click Yes.
  • Page 34 4. To set another preset, repeat the above steps. 5. After setting up the preset positions, you can start performing the function. Click the Load button and then click on the preset numbers, the live screen will move to the preset screen view.

  • Page 35: Camera Settings

    Camera Settings The video icon is to turn on camera live view while doing any settings. Click the icon to show/hide Click the icon to hide people count number & people count number and stream interval. the time interval of enabling IP icon shows the live streaming of the the IP address...

  • Page 36: Tracking Mode

    *The default framing speed is “Middle” speed. “High” speed is more suitable for one person tracking. [Note] VB350 can best frame people in masks or any facial profile up to 5 meters away!
  • Page 37 2 persons, camera will go to preset 1. The priority is preset 1>preset2> preset 3….>preset 9  Overlap beginning & end of each zone Separate preset area setting Overlap preset area setting [Note] VB350 can best frame people in masks or any facial profile up to 5 meters away!

  • Page 38: Camera Moving Speed

     Audio Tracking: After detecting the sound, camera focuses at the speaker and zooms in. The camera moving path will be shown in the screen.  Presentation Mode: This is a combination of preset tracking and audio tracking. Please set up preset areas (preset 1~9.

  • Page 39: Framing Size

    Framing Size Select Setting> Camera> FramingSize > Tight, Medium (default) or Wide.  Tight: It provides a close-up view of meeting participants.  Medium (default): It provides a medium view of meeting participants.  Wide: It provides a wide view of meeting participants. Audio Tracking Idle Interval After enabling the Audio Tracking function, select an idle interval for audio tracking.

  • Page 40: Gesture Control

    Gesture Control Select Setting > Camera > Gesture Control > On or Off (default). Enable gesture control allows user to use hand to control camera for turning on/off tracking function, zooming in/out. Click “?” icon to show gesture control list on screen. [Note] ...

  • Page 41: Audio Fence

    Turn on gesture control function first. When any of the following gestures are showing in front of the camera, it will activate gesture control function. Keep showing the gesture for 2~3 seconds to trigger the camera to act. The following are the corresponding function names and gesture figures.

  • Page 42: Home Position

    Microphone only picks up the sound within viewing angle. Choose a suitable camera viewing area to silence the sound beyond the meeting area. [Note] All the AI tracking functions, pan, tilt, and zoom in/out will be disabled while audio fence is on. Home Position Every time when powering on the camera, it will turn to this position.

  • Page 43: On Screen Menu

    Select Setting > Camera > Save Preset > Off or On (default). Image Settings Image Flip If the VB350 is installed in the upside down position, please enable the "Flip". Select Setting > Image > Image Flip > Off (default) or On.

  • Page 44: Image Mirror

    Image Mirror To mirror the camera image. Select Setting > Image > Image Mirror > Off (default) or On. In back light environment, enable WDR to improve the brightness of image. Select Setting > Image > WDR > Off or On. If user enables this function in a normal light condition, the image will become over exposure and encounter image blur.

  • Page 45: Frequency

    Frequency Select the frequency of the camera. Select Setting > Image > Frequency > 50 HZ or 60 HZ (default). White Balance Select the White Balance setting for various light conditions or color temperature. Select Setting > Image > White Balance > Auto (default) or Manual. Noise Reduction To reduce the noise from the signal.

  • Page 46: Sharpness

    Sharpness Adjust the value of sharpness. Select Setting > Image > Sharpness > Off, Low, Middle (default), or High. Saturation Adjust the value of saturation. Select Setting > Image > Saturation > 1 ~ 9. Low Light Compensation Enable/disable the compensation in low light environment. Select Setting >...

  • Page 47: Enlarge Total Zoom Up To 18X

    Enlarge Total Zoom Up to 18x Enable/Disable enlarge zoom up to 18x. (Default is 15x) Select Setting > Image > Enlarge Total Zoom Up to 18x > Disable (default) or Enable. Video Frame Rate Set up the frame rate value. Select Setting >...

  • Page 48: Video Format Settings

    Video Format Settings IP Stream Resolution Set up the resolution for IP stream. Not supported for USB video stream. Select Video Format > IP Stream Resolution (IP Stream Resolution only, not for adjusting USB video stream) > 4K, 1080P, 720P, 480P or 360P. [Note] RTSP, RTMP will not be available while USB streaming is in use.

  • Page 49: Bit Rate

    Bit Rate Set up the bit rate value. Select Video Format > Bit Rate > Auto, 512 Kbps, 1 Mbps, 2 Mbps, 4 Mbps (default), 8Mbps, 16Mbps or 32 Mbps. For Facebook live broadcasting, it’s suggested to choose less than 4Mbps to ensure smooth streaming. RTSP To use RTSP player connecting to the camera, please enter the RTSP URL which displays on the Web in your application such as VLC, PotPlayer, or Quick Time.

  • Page 50: Rtmp

    Set RTSP Access Password 1. Go to Video Format > RTSP and RTMP, and select On in the RTSP and RTMP field. 2. Optionally set up a password for the RTSP streaming. Input a password and then click Change to save the password.

  • Page 51: Network Settings

    Network Settings Hostname User can set a hostname. The hostname only allows numeric and alphabetic characters. Select Network > Hostname. Click the pencil icon to enter a hostname. DHCP Enable DHCP function. Select Network > DHCP. A message is shown and click Continue to confirm. Static IP Assign a fixed IP address to the camera.

  • Page 52: System Settings

    7 and MAC OS, a driver to support USB Display function is required for the TV/Monitor connection with VB350. Please use PTZApp 2 to install the driver. On the PTZApp 2, go to the System setup page. In the Install driver of USB Display field, click the...

  • Page 53: Firmware Update

    Update the camera’s firmware. Select System > FW Update > Auto Update or Manual Update.  Auto Update: The system will check firmware version from AVer server and request to update.  Manual Update: To update the firmware from specific location.

  • Page 54: Camera Reboot

    Camera Reboot Restart the camera manually. 1. Select System > Camera Reboot > Reboot. 2. Select Continue to reboot the camera. Change Password Change the Web login password. The default password is “aver4321”. 1. Select System > Change Password > Change WEB Access Password. 2.

  • Page 55: Ssl Certificate

    SSL Certificate Import the SSL certificate from specific location. 1. Select System > SSL Certificate > Import. 2. Select the type by clicking “+”. 3. Direct the file location. 4. Select Import. [Notes] Users can disable this function via PTZApp 2. Date Format Select the date format.

  • Page 56: Time Correction Mode

    Time Correction Mode Adjust time by auto or manual. Select System > Time Correction Mode > Auto or Manual.  Auto: The system time will be set by NTP server on the network. Select the pencil icon of NTP Server and enter the URL of NTP server. Select the Time Zone. Select NTP Update to save setting. Select Confirm to start auto time adjustment.

  • Page 57: Allow Providing Of Anonymous Usage Data

    Allow Providing of anonymous usage data You can enable this function to help AVer continuously improve our products and services. Please visit AVer’s privacy policy for more information. https://www.aver.com/privacy Select System > Allow Providing of anonymous usage data > Off or On...

  • Page 58: Noise Suppression

    Noise Suppression It is to reduce ambient noise. Select Audio > Noise Suppression > Off or On (default). When enabling the noise suppression function, please set value of noise suppression (1 ~ 40). Beamforming Microphone Enable/disable the beamforming microphone. Select Audio > Beamforming Microphone > Off or On (default). ...

  • Page 59: Keyboard Noise Suppression

    Line Out function is mainly designed for connecting to HA system. Users have to purchase an audio-out adapter from AVer (TRS female to TRRS male). If Line Out is selected, please don’t connect to external speaker, otherwise the speaker sound will have impact on built-in speaker and microphone performance.

  • Page 60: Ptzapp 2

    PTZApp 2 In PTZApp 2, user can change the IP address setting of VB350, configure the parameters of the camera, set up AI tracking functions and some advanced image and audio settings, pan, tilt, and zoom the camera. Install PTZApp 2 Please go to https://www.aver.com/download-center...

  • Page 61: Use Ptzapp 2 With Usb Devices

    Use PTZApp 2 with USB Devices 1. Run your video application and make a video call. 2. During your video call, you can use the PTZApp 2 to pan, tilt and zoom the camera in/out and enable/disable the true WDR, brightness, and sharpness feature. 3.
  • Page 62 Choose “USB Devices” and connect VB350 to PC/laptop with USB cable When the camera is detected, the product card will show up. Set up IP address. The camera default IP address is 192.168.1.168. Click the pencil icon ( ) to edit IP address.
  • Page 63   Hotkey Control: User can control the camera by using keyboard. This is a general list for all Aver USB Cameras. Backlight control equals to WDR function in VB350 PTZApp Update: Get current PTZApp 2’s version number and do auto update here.
  • Page 64 Usage Data: Should you click the check mark, PTZApp2 will automatically send us the diagnostic  and usage data to help us improve PTZApp2. The collected data is anonymous and cannot identify users. EZManager Pair: Enter THE 4-Code ID and IP to connect to EZManager. ...
  • Page 65 Information: Click the drop-down triangle icon to review the information of camera. To minimize  the information, click the triangle or the bottom area of the information icon. Camera: Click the camera icon to view the camera live view. IP address is displayed as well. Click ...
  • Page 66  Full Screen: PTZApp 2 can switch to full screen mode. Click “ ” icon and video screen will switch to full screen mode. In full screen mode, user can use direction panel to control camera direction. Click “ ” icon to go back to normal screen view. The resolution of full screen mode is 1080p/ 30fps.
  • Page 67  People Count and Stream Interval: Click the icon to show people count number and USB stream interval. Click the icon to hide the stream interval.  Control Panel: To control the camera direction, zoom in and out during your video call.
  • Page 68 Setting: Click “Setting” button to set up parameters of the camera and speakerphone. Click arrow icon to leave the Setting page.  PTZ Control: Use control panel to set up preset positions. Since most of operations are the same as web page, refer to <PTZ Control>...
  • Page 69  I/O Port: Except USB port, user can enable or disable all I/O ports.  BT Pairing: Click Start to pair VB350 with mobile phone via Bluetooth connection. To disconnect Bluetooth connection, please cut if off from mobile phone or use remote control.
  • Page 70 PTZApp 2 Quit & Restore: To quit the application, right-click the icon on the system tray and select “Quit”. If you can’t launch PTZApp 2 right after installation, please right –click the icon and choose “Restore”.

  • Page 71: Smart Gallery Operation

    Smart Gallery Operation You can use the Smart Gallery function to increase the visibility of each participant in the meeting room. When operating Smart Gallery function, please don’t open camera view in any other applications. 1. Connect your camera(s) supported with Smart Gallery function to the computer with USB cable. 2.
  • Page 72 4. Launch VC software (e.g., Zoom, Teams, Skype) and choose AVer USB VCam as the video source to start collaborating. [Note] You will find both “camera model name” and “AVer USB VCam” as video sources in the VC software. Please choose “AVer USB VCam”.

  • Page 73: Ezlive

    EZLive Please go to https://www.aver.com/download-center to download the AVer EZLive software. After downloading, double-click on the file and follow the on-screen instructions to complete the installation. Use AVer EZLive During a video call, EZLive can help user to do: (1) Camera ePTZ (2) Volume control for the speaker connected (3) Capture camera’s still images...
