  • Page 1 Leica Racer 100...
  • Page 2 Leica Racer 100...
  • Page 3 Leica Racer 100...
  • Page 4 16,17,18 MENU UNIT RESET TRIPOD BEEP ONOFF TIMER 7,8,9...
  • Page 5 EXIT max.

  • Page 6: Table Of Contents

    Operation ............. 8 Measuring ............9 Use of the instrument Functions ............. 9 Appendix ............14 Permitted use • Measuring distances • Computing functions, e. g. areas and volumes • Measuring tilts Leica Racer 100 784117 en Safety Instructions...

  • Page 7: Areas Of Responsibility

    This person is also accountable for the deployment of personnel and for The Leica Racer is designed for use in areas perma- their training and for the safety of the equipment nently habitable by humans, do not use the product when in use.

  • Page 8: Safety Instructions

    Leica Geosystems dealer. Make sure the Leica Racer optics is kept clean and that there is no mechanical damage to the bumpers. Electromagnetic Compatibility CAUTION: (EMC) In using the instrument for distance measure- ments or for positioning moving objects (e.g.

  • Page 9: Laser Classification

    IEC 60825-1:2007 Integrated distancemeter Maximum radiant power: <1mW Emitted wavelength: 620-690nm The Leica Racer produces a visible laser beam which Beam divergence: 0.16 x 0.6 mrad emerges from the front of the instrument. Pulse duration: 1 x 10 It is a Class 2 laser product in accordance with: •...

  • Page 10: Start-Up

    {C}. • For measurements from a corner, open the posi- tioning bracket until it locks in place, then push the positioning bracket lightly to the right to fold it out fully. See figure {D}. Leica Racer 100 784117 en Start-up...

  • Page 11: Menu Functions

    26 Ceiling area 27 Intermediate line 1 Pressing the button for longer in the menu 28 Intermediate line 2 allows you to quit the settings function without 29 Intermediate line 3 saving. 30 Summary line Menu functions Leica Racer 100 784117 en...
  • Page 12 You can switch the beep on or off. the factory settings ( The instrument has a RESET function. When you select the menu function RESET and confirm, the instrument defaults to the factory settings. Leica Racer 100 784117 en Menu functions...

  • Page 13: Operation

    (rear reference). See The instrument switches off automatically figure {H}. after six minutes of inactivity. Press this button for longer the front reference is set permanently. Press this button, the rear reference is set again. Operation Leica Racer 100 784117 en...

  • Page 14: Measuring

    The result is displayed in the summary line. shown in the display as well as the last measured Press the button for longer to calculate the value in the summary line. circumference. Leica Racer 100 784117 en Measuring...
  • Page 15 ° or % depending on the side of the triangle (d3). setting. The result is displayed in the summary line as the Press to measure the inclination and the room corner angle. distance. See figure {J}. Functions Leica Racer 100 784117 en...
  • Page 16 (e.g. with the Pressing the button starts the laser measure- positioning bracket fully folded out and the ment. The display shows required stake out distance instrument placed on a wall). Leica Racer 100 784117 en Functions...
  • Page 17 Keep the instrument as horizontal as possible. Press and hold down this button to trigger continuous measurement, sweep the laser back and forth and up and down over the ideal target point. Functions Leica Racer 100 784117 en...

  • Page 18: Functions

    The result is displayed in the summary line, the partial results in the secondary lines. Pressing the buttons at the same time erases all the values in historical storage. Leica Racer 100 784117 en Functions...

  • Page 19: Appendix

    Cause Remedy Transverse tilt Hold the instrument greater than 10° without any transverse tilt Main tilt direction, Measure angle up to angle too high max. ± 45° (> 45°) Calculation error Repeat procedure Appendix Leica Racer 100 784117 en...

  • Page 20: Technical Data

    45°) rough surfaces. Measuring accuracy between 10 m and 30 m may deteriorate to approx. ± 0.025 mm/m, for distances above 30 m to ± 0.1 mm/m. Leica Racer 100 784117 en Appendix...
  • Page 21 Warranty Use a target plate to increase the measurement range during daylight or if the target has poor reflec- The Leica Racer 100 comes with a two year warranty tion properties. from Leica Geosystems AG. More detailed information can be found at: Target surfaces www.leica-geosystems.com...
  • Page 22 Management and Quality Systems (ISO standard 9001) and Environmental Management Systems (ISO standard 14001). Total Quality Management - Our commitment to total customer satisfaction. Ask your local Leica Geosystems agent for more information about our TQM program. Printed in Switzerland - Copyright Leica Geosystems AG, Heerbrugg, Switzerland 2010 Translation of original text (784117) Pat.
