WPS-DVR Quick Start Guide
3. CONFIGURE RESOLUTION AND VIDEO STREAMING
A. Select the Device Config
B. In the Device List, select the appropriate DVR you want to connect to from the list and click on Properties.
Use the Pre-Camera tab to set Record Resolution and Compression - Best REC Resolution – How the DVR
records the video depends on the internal hard drive. Options include:
• CIF = 360x240 (Lowest Resolution, but offers the maximum amount of HDD storage)
• Half D1 (2CIF) = 720x240
• Full D1 (4CIF) = 720x480 (Highest Resolution, but offers the minimum amount of HDD storage)
Compression – Its recommended to keep the default "Normal" setting to the default of Normal as it offers the
least amount of compression and streams video at the highest resolution.
- Use the Camera tab to name the cameras, adjust the record quality, and set the Frames Per Second.
Record Quality – Options are a scale of 1-9. The higher the number, the higher the quality of the recording.
Frames per Second (FPS) – Set the FPS for each camera individually.
Note: The total FPS for all cameras cannot exceed DVRs maximum frame rate for the selected resolution.
5
icon from the Internet Explorer browser user interface.
