IMPORTANT! - Read Before Heading to the Job Site
The following items are required during the installation of a WPS-DVR. It is recommended that these items
are reviewed before configuring the DVR. Preparing these items in advance will allow for the installation to
be performed smoothly.
All Cameras and display devices that will be connected to the DVR
Network Connection near the location of the DVR
Administrator rights to the computer that will be used to access the DVR
Router Details – Contact the network admin to obtain
•
Admin Rights – Required to setup the network and port forwarding for remote access.
•
Default gateway
•
Net Mask Address
•
DNS Address
•
Static IP to assign to the DVR
Table of Contents
1. CONNECT AND CONFIGURE THE DVR ........................................................................................................ 2
2. CONFIGURE INTERNET EXPLORER FOR FIRST USE ......................................................................................... 3
3. CONFIGURE RESOLUTION AND VIDEO STREAMING ................................................................................... 5
WPS-DVR
Quick Start Guide
Advertisement
Related Manuals for Wirepath WPS-DVR
Summary of Contents for Wirepath WPS-DVR
- Page 1 IMPORTANT! - Read Before Heading to the Job Site The following items are required during the installation of a WPS-DVR. It is recommended that these items are reviewed before configuring the DVR. Preparing these items in advance will allow for the installation to be performed smoothly.
- Page 2 WPS-DVR Quick Start Guide 1. CONNECT AND CONFIGURE THE DVR Router Camera(s) 1.1. CONNECT DEVICES Before powering on the DVR, connect a VGA or composite monitor, cameras, and the mouse. Some models can be connected to a display via HDMI as an alternative to VGA or composite.
- Page 3 WPS-DVR Quick Start Guide 2. CONFIGURE INTERNET EXPLORER FOR FIRST USE 2.1. CONFIGURE THE ROUTER FOR PORT FORWARDING Confirm the port forwarding in the router setup matches the ports you entered in Step 4 of the Initial Setup above (see the Router Setup Application Note found in the manual on the included disc for more information).
- Page 4 WPS-DVR Quick Start Guide G. Select Yes to agree to the license. H. Select Install to install the .cab file. I. Enter the Username and Password for the DVR (see Step 3 in the Initial Setup). Confirm the Control and Data Port settings are populated with the correct port numbers entered in Step 4 of the Initial Setup.
- Page 5 WPS-DVR Quick Start Guide 3. CONFIGURE RESOLUTION AND VIDEO STREAMING A. Select the Device Config icon from the Internet Explorer browser user interface. B. In the Device List, select the appropriate DVR you want to connect to from the list and click on Properties.
- Page 6 WPS-DVR Quick Start Guide Set the Video Stream in the Network tab. Video Stream is the quality of the video viewed remotely through Internet Explorer or on a Smartphone. This does not affect the quality of video being recorded to the DVR. Options include: Record –...
- Page 7 WPS-DVR Quick Start Guide...
- Page 8 120314-1628 © 2012 Wirepath Surveillance...
