WPS-DVR Quick Start Guide
2. CONFIGURE INTERNET EXPLORER FOR FIRST USE
2.1. CONFIGURE THE ROUTER FOR PORT FORWARDING
Confirm the port forwarding in the router setup matches the ports you entered in Step 4 of
the Initial Setup above (see the Router Setup Application Note found in the manual on
the included disc for more information).
2.2. Complete Internet Explorer Configuration
This DVR supports Internet Explorer (32bit) on a Windows platform. Before opening Internet Explorer to initially set
up the DVR, the PC user must have administrator rights for the PC. Run the Internet Explorer Browser interface as
an administrator.
A. Click on the Start Menu.
B. Find Internet Explorer and right click on the icon.
C. Select Run as Administrator.
D. In the address bar, enter the IP address assigned to the DVR in Step 4 of the
Initial Setup. The PC must be connected to the same network as the DVR. The
address will look similar to: http://###.###.###.###:PP/ie.htm
###.###.###.### is the IP address entered into the DVR in Step 4 of the Initial Setup.
PP is the HTTP port entered into the DVR in Step 4 of the Initial Setup and it must match the HTTP port for-
warding set up in the router in Step 1 above.
/ie.htm is the extension for the DVR and must be included at the end of the IP address.
E. Once connected to the DVR, a yellow dialogue box will appear at the top of the IE window regarding
the add-in. Right click on the yellow box at the top of the page and select Install This Add-on for All Users
on This Computer.
F. The web page will load and launch an Install request to install software. Select Install.
3
