Summary of Contents for Proxim Tsunami MP.11

Page 1 Part Number 72084 Tsunami MP.11 Recommended Antennas Version 2.3...
Page 2: Safety And Regulatory Information
Tsunami MP.11 Recommended Antennas Copyright © 2005 Proxim Wireless Corporation, San Jose, CA. All rights reserved. Covered by one or more of the following U.S. patents: 5,231,634; 5,875,179; 6,006,090; 5,809,060; 6,075,812; 5,077,753. This manual and the software described herein are copyrighted with all rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form by any means without the written permission of Proxim Wireless Corporation.
Page 3: Table Of Contents
Sector Antennas............................13 Panel Antennas ............................19 Parabolic Antennas ............................. 32 RECOMMENDED 2.4 GHZ ANTENNAS ....................33 Omni Antennas............................33 Sector Antennas............................41 Panel Antennas ............................49 Parabolic Antennas ............................. 53 SUPPORT..............................58 Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 4: Introduction
In case you are not certain about the regulations that apply in your country, consult your local Proxim Wireless Corporation Sales Office. Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 5: Antenna Types
In a hilly terrain, an 8 dBi omni-directional antenna can be a better solution than the 10 dBi omni-directional antenna to avoid missing part of the terrain with too narrow a beam. Omni Antenna Horizontal Vertical Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 6 Horizontal and Vertical Parabolic Dish Antennas Parabolic antennas are concave panels or bowls that produce an extremely narrow beam (4 – 25 degrees horizontal / vertical). Parabolic Antenna Horizontal and Vertical Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 7 Antennas with gain less than 8 dBi are not allowed. • Antennas of other makes can be used with the HZB-US5358-11A device (5054-R), but must be of the same type, dimensions, and gain as those listed. Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 8: Recommended 5.8 Ghz Antennas
-40 to +90 degrees C Humidity 95% @ 25 degrees C Lightning protection DC ground Size 78 x 80 x 384 mm Radome color Gray-white Radome material Fiberglass Weight 230 g Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 10 -40 to +90 degrees C Humidity 95% @ 25 degrees C Lightning protection DC ground Size 78 x 80 x 515 mm Radome color Gray-white Radome material Fiberglass Weight 270 gw Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 11 Tsunami MP.11 Recommended Antennas Antenna Patterns 5054-OA-10 H-plane Co-polarization Pattern 5500 MHz 5600 MHz 5700 MHz 5800 MHz V-plane Co-polarization Pattern 5500 MHz 5600 MHz 5700 MHz 5800 MHz Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 12 58 1360 5.7 – 5.8 Stella Doradus 58 2360 5.7 – 5.8 Stella Doradus 58 3360 5.7 – 5.8 Telex 5830 5.725 – 5.85 RadioWaves OMN-H-5-8 5.725 – 5.85 8 (hor pol) Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 13: Sector Antennas
VSWR 2.0 : 1 maximum Nominal Impedance 50 ohms Gain 13.5 dBi HPBW/horizontal 120 degrees HPBW/vertical 6 degrees Polarization Linear, vertical Downtilt 0 degrees Power handling 5W (cw) Connector N-type Female Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 14 Lightning protection DC ground Size 620 x 88 x 70 mm Radome color Gray, white Radome material Weight 590 gw Mechanical tilt +10 .. 0 or 0.. –10 degrees Mechanical Layout Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 16 VSWR 2.0 : 1 maximum Nominal Impedance 50 ohms Gain 16.5 dBi HPBW/horizontal 60 degrees HPBW/vertical 6 degrees Polarization Linear, vertical Downtilt 0 degrees Power handling 5W (cw) Connector N-type Female Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 17 Lightning protection DC ground Size 620 x 88 x 70 mm Radome color Gray, white Radome material Weight 565 gw Mechanical tilt +10 .. 0 or 0.. –10 degrees Antenna Patterns Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 18 Sector Mars MA-WE50-7X 5.15 – 5.875 14.5 MT-484034/NV 5.15 – 5.875 16.5 120 degrees MT-484034/NH 5.15 – 5.875 16.5 (hor pol) RadioWaves SEC-5V-120-14 5.725 – 5.85 RadioWaves SEC-5V-120-16 5.725 – 5.85 Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 19: Panel Antennas
-40 to +80 degrees C Humidity 95% @ 25 degrees C Lightning protection DC ground Size 200 x 200 x 50 mm Radome color Black Radome material ABS, UV resistant Weight 0.825 kgw Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 22 B. Turn the suction cup one quarter to lock it into position. C. Press the window suction cup onto (1) Antenna body the window glass. (2) plastic conical anchor (3) screw (4) window suction cup Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 23 Dimensions 330 x 93 x 21 mm Power handling 20 W (cw) Impedance 50 Ohms Connector Standard N-female Cable ULA-168; 200 cm Cable loss 2 dB *exclusive of cable loss Pattern Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 24 Temperature -40 degrees C up to +75 degrees C Input/RF Interface N-Type (others available) Standard Compliance ETSI EN 302 085 V1.1.2 (2001-02) Range 1, TS 1, 2, 3, 4, 5 Specifications subject to change without notice Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 29 -40 to +80 degrees C Humidity 95% @ 25 degrees C Lightning protection DC ground Size 360 x 360 x 16 mm Weight 1.6 kgw Radome material ABS, UV resistant Radome color white Patterns Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 31 5.25 – 5.85 2-Foot Flat MT-486001/N 5.15 – 5.875 Panel Gabriel DFPD2-52 5.25 – 5.85 Andrew FPA5250D24-N 5.25 – 5.85 28.2 A57A24-U 5.725 – 5.85 26.5 RadioWaves FP2 5-28 5.25 – 5.85 Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 32: Parabolic Antennas
5.25 – 5.85 29.4 P-57C24 3-Foot Radio Waves SP3-5.2 5.25 – 5.85 31.4 Parabolic Radio Waves SPD3-5.2 5.25 – 5.85 31.1 Andrew P3F-52 5.25 – 5.85 33.4 Andrew PX3F-52 5.25 – 5.85 33.4 Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 33: Recommended 2.4 Ghz Antennas
5. Next, feed the antenna cable of the 7 dBi Omni-Directional Base Unit Antenna (item a) through the hole of the mounting bracket. 6. As shown in the following figure, slide the antenna down until its metal base is enclosed by the mounting bracket. Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 34 -40 degrees C (-40 degrees F) to +60 degrees C (+140 degrees F) Wind/survival At least 200 km/h (124 mph) See also “Selecting the Correct Connector Type”. At least 100 km/h (62 mph) with 1.25 cm (0.5 in) ice. Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 35 Tsunami MP.11 Recommended Antennas Pattern Azimuth Plane (Horizontal), 7 dBi Omni-Directional Base Unit Antenna Elevation Plane (Vertical), 7 dBi Omni-Directional Base Unit Antenna Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 36 1. Attach the ferrule of the antenna to the mounting bracket with two U-bolts as shown in the following figure. 2. Next use the remaining two U-bolts to attach the mounting bracket to the mast. Tighten nuts to 9 Nm (7 ft-lbs). Mounting the 10 dBi Antenna Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 37 -40 degrees C (-40 degrees F) to +60 degrees C (+140 degrees F) Wind/survival (mph) At least 240 km/h (150 mph) See also “Selecting the Correct Connector Type”. At least 200 km/h (124 mph) with 1.25 cm (0.5 in) ice. Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 38 Tsunami MP.11 Recommended Antennas Pattern Azimuth Plane (Horizontal), 10 dBi Omni-Directional Base Unit Antenna Elevation Plane (Vertical), 10 dBi Omni-Directional Base Unit Antenna Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 39 Wind/survival At least 200 km/h (124 mph) See also “Selecting the Correct Connector Type” in the Antenna Installation Guide. At least 100 km/h (62 mph) with 1.25 cm (0.5 in) ice. Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 40 Tsunami MP.11 Recommended Antennas Pattern Azimuth Plane (Horizontal), 5 dBi Omni-Directional Antenna Elevation Plane (Vertical), 5 dBi Omni-Directional Antenna Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 41: Sector Antennas
- 40 deg. C to +80 deg. C Humidity 100% @ 25 degrees C Radome color Gray-white Radome material ABS, UV resistant Weight 5.55 kg Dimensions 600 x 88 x 70 mm Pattern Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 43 -40 degrees C (-40 degrees F) to +60 degrees C (+140 degrees F) Wind/survival (mph) At least 200 km/h (124 mph) See also “Selecting the Correct Connector Type”. At least 100 km/h (62 mph) with 1.25 cm (0.5 in) ice. Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 44 Tsunami MP.11 Recommended Antennas Pattern Azimuth Plane (Horizontal), 12 dBi Directional Wide Angle Antenna Elevation Plane (Vertical), 12 dBi Directional Wide Angle Antenna Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 45 Backing Plate and nuts. CAUTION! Always place flat washers between heads (or nuts) and the plastic mounting plate. Avoid over-tightening the nuts and screws to prevent damage to the mounting plate. Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 46 3. Attach the antenna using the intermediate plate, metal backing plate and flat washers. CAUTION! Always use flat washers between the screws and the plastic mounting plate. Avoid over- tightening nuts and screws to prevent damage to the mounting plate. Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 47 -40 degrees C (-40 degrees F) to +60 degrees C (+140 degrees F) Wind/survival At least 200 km/h (124 mph) See also “Selecting the Correct Connector Type”. At least 100 km/h (62 mph) with 1.25 cm (0.5 in) ice. Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 48 Tsunami MP.11 Recommended Antennas Pattern Azimuth Plane (Horizontal), 14 dBi Directional Antenna Elevation Plane (Vertical), 14 dBi Directional Antenna Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 49: Panel Antennas
– 40 degrees C to +80 degrees C Humidity 95% @ 25 degrees C Lightning protection DC ground Radome color Light gray Radome material ABS, UV resistant Weight 0.4 kg Dimensions 200 x 200 x 50 mm Pattern Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 51 C. Press the window suction cup onto 1. Antenna body the window glass. 2. plastic conical anchor Coverage 3. screw 4. window suction cup Note: The bulged side of the antenna must point to the Base Station. Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 52 0 degrees Dimensions 330 x 93 x 21 mm Power handling 20 W (cw) Impedance 50 Ohms Connector N-Jack Cable ULA-168; 200 cm Cable loss 1.3 dB *Exclusive of cable loss Pattern Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 53: Parabolic Antennas
(also France). In countries that adhere to the FCC regulations, use of this antenna is allowed only when operated with specific radio channels that can be set on the Tsunami MP.11. Kit Contents The 24 dBi Directional Parabolic Grid Antenna comes in two boxes with the following contents...
Page 54 Polarity of the antenna must always be the same as the polarity of the antenna on the opposite side of the link! 4. Place the ‘L’ bracket on the back of the antenna. 5. Insert two carriage bolts from the front to attach. Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 55 5. Slide the ‘L’ bracket over the U-bolts and fasten the grid antenna to the U-bolts using the lock washers and nuts. Note: For tilted elevation mounting, use the flat plate washer on the adjustable tilt slot to mount and secure the antenna to the desired elevation angle. Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
Page 56 At least 200 km/h (124 mph) See also “Selecting the Correct Connector Type”. At least 100 km/h (62 mph) with 1.25 cm (0.5 in) ice. Horizontal Pattern Azimuth Plane (Horizontal), 24 dBi Directional Parabolic Grid Antenna Copyright © 2005 Proxim Wireless Corporation. All rights reserved.
