VACUUM MAINTENANCE
Always unplug vacuum from outlet
!
before dismantling any part of machine!
Changing the Dust Bag - Figure 10
To change the dust bag, pull the cover release flap forward
(#5 on page 6) and lift the cover (7) from the dust bag
housing. The cover release flap must remain in a forward
"pulled-out" position to change dust bags and lock them
into place. Squeeze the clamps on both sides of the dust
bag sealing plate, slide the plate (28) from the holder (29)
and push the cap on to seal the bag. Slide the sealing
plate (28) of a new bag into the holder and push it in firm-
ly. Re-insert cover into dust bag housing, push it forward,
then lock it in place by pushing down the cover release
flap. You may find it convenient to store the bag cap inside
the dust bag housing below the dust bag.
Changing the Micro-Hygiene Filter - Figure 11
The micro-hygiene filter (30) needs to be changed when it
becomes extremely dirty or clogged with dust, or after
approximately 20 dust bags have been used. To change
the micro-hygiene filter, pull the cover release flap (#5 on
page 6) forward and lift the cover from the dust bag hous-
ing. Then, slide the filter out at the bottom. To replace, lift
the safety lever (31) and slide the new filter in using the
tracks as guides.
Changing the Exhaust Filter - Figure 12
After 20 bags have been used, change the exhaust filter
(32). To remove the exhaust filter, push the catch (33)
backward and remove the filter cover (34) and exhaust fil-
ter. Insert the new filter and replace the filter cover.
Changing the Brush Roller(s) - Figure 13 (X4),
Figure 13a (X5)
To change the brush roller(s) (35 or 35a), push the but-
ton(s) (36 or 36a), remove the side plate(s) (37 or 37a),
turn the brush(s) clockwise a quarter of a turn, and pull
the old brush roller(s) out. Slide the new brush roller(s)
into the brush housing and turn it until it locks into posi-
tion. While slightly pushing the button(s) (36 or 36a),
press the side plate(s) (37 or 37a) back into the locked
position.
Changing the Sealing Strip - Figure 14 (X4),
Figure 14a (X5)
The sealing strip (39) is located just behind the brush
roller opening. The sealing strip seals the power head to
hard floors to prevent kick-back of debris while vacuum-
ing. To replace a worn sealing strip, push the release but-
ton, remove the side plate (36 and 37 in figure 13 & 13a)
and slide old strip out. Insert the new strip into the slot
and slide into place.
Dust Bags
Part #5093AM
Micro-Hygiene
Filter
Part #5036AM
Exhaust Filter
Part #5143
Brush Roller (X4)
Part #5010AM
Brush & Edge
Rollers (X5)
Part #5290AM
Sealing Strip
Part #5400-1 (X4)
Part #5400-2 (X5)
39
Figure 14a (X5)
Figure 10
Figure 11
Figure 12
Figure 13 (X4)
Figure 13a (X5)
39
Figure 14 (X4)
9
