CLOG REMOVAL

Always unplug vacuum from outlet before removing
!
any clogs!
Clogs in the Airflow Pathway - Figure 15
Most clogs can be removed by accessing the airflow pathway via the orange
colored access door (38) located on the underside of the power head.
However, other clogs may only be removed by accessing the airflow pathway
by disassembling the machine in the opposite sequence of the machine's
original assembly (see assembly, page 6).
Clogs in the Attachment Hose - Figure 16
Blockages in the hose can be cleared by removing the attachment hose (12)
from the machine by squeezing the retaining ring (4) and inserting the oppo-
site end of the hose in the connecting tube (23). Hold the hose upright with
one hand blocking the top end and switch on the machine. If necessary,
quickly lift your hand on and off the end of the hose. If this procedure does not
clear the clog, a straight wire can be inserted into the hose to push out the
clog. Take care not to puncture the hose with the wire.
Clogs in the Attachment Tube (Active Wand) - Figure 17
Remove attachment hose (12) from the attachment tube (16). Then, grip
attachment tube handle (11) and remove tube from the machine. A straight
wire can be inserted into the tube to push out the clog.
Clogs in Entrance to Dust Bag - Figure 18
Remove attachment hose (12) from vacuum cleaner (see figure 16) and remove
front cover (7). Clean out connecting tube (23) and/or entrance to bag (28).
Clogs in the Swivel Neck - Figure 19
Clogs in the swivel neck (20) can be removed by first pressing the housing
release button (8) and lifting off the dust bag housing (6). Lift upward firmly
and evenly to properly remove the dust bag housing. Then, release the foot
pedal (19), lower the swivel neck, check inside the swivel neck channel clos-
est to the foot pedal (see arrow), and clean out pathway.
10
Figure 15
Figure 16
Figure 17
Figure 18
Figure 19
