  • Page 1 AMB-BL 1080P WDR BULLET IP CAMERA User’s Manual V1.0 08 / 2013...
  • Page 3 Welcome Thank you for purchasing the 1080P WDR BULLET IP CAMERA. This user’s manual is designed to be a reference tool for the installation and operation of your system. Here you can find information about the corresponding IP camera’s features and functions, as well as a detailed installation method.

  • Page 4: Important Safeguards And Warnings

    Important Safeguards and Warnings 1．Electrical safety  All installation and operation here should conform to your local electrical safety codes.  The power supply shall conform to the requirement in the SELV (Safety Extra Low Voltage) and must make sure that the limited power source is rated 12V DC or 24V AC. Please note: Do not connect two power supplying sources to the device at the same time;...
  • Page 5  Please make sure the CCD (CMOS) component is away from the radiation of the laser beam device. Otherwise it may result in CCD (CMOS) optical component damage.  It is recommended that the grounding studs of the product should be grounded, so to further enhance the reliability of the camera.

  • Page 6: Table Of Contents

    Table of Contents 1 General Introduction ..................1 Overview ....................1 Features ....................1 Specifications ..................2 1.3.1 Performance ................... 2 2 Structure ......................5 Multiple-function Combination Cable ........... 5 Framework and Dimension ..............6 Bidirectional talk ................... 8 2.3.1 Device-end to PC-end ..............8 2.3.2 PC-end to the Device-end ..............

  • Page 7: General Introduction

     Real-time video detect: motion detect, camera masking.  Network camera supports one-channel audio/video data transmission to Network network terminal and then decodes signal. Delay is within 270ms (network Monitor bandwidth support needed) © Copyright Qvis ®. All documentation rights reserved.

  • Page 8: Specifications

    White Balance Off / BLC (default or custom) / WDR (0-100 adjustable) / HLC (0-100 adjustable) Manual/Auto PAL: It ranges from 1/3 to 1/10000 Exposure Mode NTSC: It ranges from 1/4 to 1/10000 © Copyright Qvis ®. All documentation rights reserved.
  • Page 9 Monitor, PTZ control, system setup, file download, log information, Operation maintenance , upgrade, etc. Video Output 1-channel analog video output，BNC port. Reset button Restore Default Setup Support AC24V/DC12V power. (Cannot support these two modes at the same time.) Power © Copyright Qvis ®. All documentation rights reserved.
  • Page 10 Power 7.5Watts Max Consumption Working C~+60 Temperature ≤90% Working Humidify φ104*306.7 Dimensions(m 1250g(Excluding box) Weight Bracket is included in the accessories bag. Installation 20~30m IR Distance Protection IP66 Level © Copyright Qvis ®. All documentation rights reserved.

  • Page 11: Structure

    Output audio signal to the devices such as AUDIO OUT port the sound box. Video output Output analog video signal. It can connect to VIDEO OUT port the TV monitor to view the video. © Copyright Qvis ®. All documentation rights reserved.

  • Page 12: Framework And Dimension

    Please refer to Figure 2-2 for dimension information according to the actual product. The unit is mm. Please also see Figure 2-4. Figure 2-2 Dimension illustration 1 © Copyright Qvis ®. All documentation rights reserved.
  • Page 13 Figure 2-3 Dimension illustration 3 © Copyright Qvis ®. All documentation rights reserved.

  • Page 14: Bidirectional Talk

    (NO/NC.) 4. Set the WEB alarm output. The alarm output 01 is for the alarm output port of the device. It is the No.2 pin of the I/O cable. © Copyright Qvis ®. All documentation rights reserved.
  • Page 15 If the type is NO, this button is normally open. The button becomes on when there is an alarm output. If the type is NC, this button is normally off. The button becomes off when there is an alarm output. © Copyright Qvis ®. All documentation rights reserved.
  • Page 16 Figure 2-6 Alarm output © Copyright Qvis ®. All documentation rights reserved.

  • Page 17: Installation

    Otherwise, it may result in device malfunction.  The rear cover of the device is designed to be waterproof. Please secure four screws firmly after you complete the Micro SD card installation. (Go to next page for diagrams) © Copyright Qvis ®. All documentation rights reserved.

  • Page 18: Lens Adjustment

    The lens cover is designed to be waterproof. Please make sure it is secure after you complete the lens adjustment.  This IP camera product has the default motorised zoom lens. You do not need to adjust manually. Figure 3-3 Lens adjustment © Copyright Qvis ®. All documentation rights reserved.

  • Page 19: Bracket Adjustment

    Important: Please make sure the M4 inner hex screw or M4 inner hex flat tight screws are firm, otherwise it may result in chassis vibration and the camera will not be able to fix to a specified angle. Figure 3-4 Bracket adjustment 1 © Copyright Qvis ®. All documentation rights reserved.

  • Page 20: Quick Configuration Tool

    Network camera default IP address is 192.168.1.108. If there is a router, please set the corresponding gateway and subnet mask. The factory default user name is admin and password is admin. For security reasons, please modify your password after you first login. © Copyright Qvis ®. All documentation rights reserved.
  • Page 21 Or you can select an IP address and then click the Login button to go to the login interface. See Figure 4-4. In Figure 4-4, you can view device IP address, user name, password and port. Please modify the corresponding information to login. © Copyright Qvis ®. All documentation rights reserved.
  • Page 22 If you are using device background upgrade port 3800 to login, other setups are all invalid. Figure 4-4 Login prompt After you logged in, the configuration tool main interface is shown as below. See Figure 4-5. Figure 4-5 Main interface © Copyright Qvis ®. All documentation rights reserved.

  • Page 23: Web Operation

    2. The login interface is shown as below. See Figure 5-2. 3. Please input your user name and password. 4. Default factory name is admin and password is admin. Note: For security reasons, please modify your password after you first login. © Copyright Qvis ®. All documentation rights reserved.
  • Page 24 If you can’t download the ActiveX file, please check whether you have installed the plug-in to disable the control download. Or you can lower the web browser’s security level. See Figure 5-3. Figure 5-3 IE security level © Copyright Qvis ®. All documentation rights reserved.
  • Page 25 After you logged in, you can see the main window. See Figure 5-4: Figure 5-4 Web monitoring window © Copyright Qvis ®. All documentation rights reserved.

  • Page 26: Faq

    Note  This user’s manual is for reference only. Slight differences may be found in user interface.  All the designs and software here are subject to change without prior written notice. © Copyright Qvis ®. All documentation rights reserved.
  • Page 27 For more information about our IP Cameras and other available cameras, NVRs & accessories, please visit our website: www.adata.co.uk Alternatively scan this QR code with your smart phone to be directed instantly to our website: © Copyright Qvis ®. All documentation rights reserved.
