  • Page 1 APOIP-MD1.3 APOIP-MD2 1.3 & 2 MEGA PIXEL INTERNAL DOME IP CAMERAS User’s Manual...
  • Page 3 Welcome Thank you for purchasing the 1.3 or 2 Mega Pixel Internal Dome IP Cameras. This user’s manual is designed to be a reference tool for the installation and operation of your system. Here you can find information about the corresponding IP camera’s features and functions, as well as a detailed installation method.

  • Page 4: Important Safeguards And Warnings

    Important Safeguards and Warnings 1．Electrical safety  All installation and operation here should conform to your local electrical safety codes.  The power supply shall conform to the requirement in the SELV (Safety Extra Low Voltage) and must make sure that the limited power source is rated 12V DC or 24V AC. Please note: Do not connect two power supplying sources to the device at the same time;...
  • Page 5  Please make sure the CCD (CMOS) component is away from the radiation of the laser beam device. Otherwise it may result in CCD (CMOS) optical component damage.  It is recommended that the grounding studs of the product should be grounded, so to further enhance the reliability of the camera.

  • Page 6: Table Of Contents

    Table of Contents General Introduction ...................... 1 Overview ......................1 Features ......................1 Specifications ....................2 1.3.1 Performance ....................2 Factory Default Setup ..................4 Framework ........................9 Dimensions ....................... 9 Structure ......................10 Installation ........................12 Device Installation ................... 12 SD Card Installation ..................

  • Page 7: General Introduction

     Supports web access.  Allows network camera configuration and management via Ethernet. Network  Supports device management via web or client-end. Management  External power adapter DC12V.  Supports s PoE supply Power © Copyright Qvis ®. All documentation rights reserved.

  • Page 8: Specifications

    Support day/night mode switch. Gain Control Fixed/Auto On/Off White Balance Manual/Auto Manual/Auto Electronic PAL: It ranges from 1/3 to 1/10000 Shutter NTSC: It ranges from 1/4 to 1/10000 Video H.264/JPEG/MJPEG Compression Standard © Copyright Qvis ®. All documentation rights reserved.
  • Page 9 Power 4.5W MAX Consumption Working C ~+60 Temperature Working 10%~90% Humidify Φ110×54 Dimensions(mm) Weight 250g(Excluding box) 400g (Excluding box) Installation Fixed on the wall, ceiling, etc. © Copyright Qvis ®. All documentation rights reserved.

  • Page 10: Factory Default Setup

    Watermark Enable Watermark DigitalCCTV character Enable Enable Bit stream General type Encode mode H.264B Resolution CIF(352*288) PAL: 25 Frame Stream Rate(FPS) NTSC:30 Bit Rate Type Recommende 192-1024Kb/S d Bit Bit Rate 1024 © Copyright Qvis ®. All documentation rights reserved.
  • Page 11 Connection TCP Port 37777 UDP Port 37778 Connection HTTP Port RTSP Port Enable HTTP Disable HTTPs Port Enable Disable PPPoE Username none Password Server Type Disable，CN99 DDNS DDNS Server IP none © Copyright Qvis ®. All documentation rights reserved.
  • Page 12 ‘Device name+SN’. Depends on the device. SNMP Version Enable Enable Bonjour Server Name Device factory SN Multicast 239.255.42.42 Address Multicast Port 36666 Enable Disable Auto Register Server IP 0.0.0.0 Port 7000 Sub-device ID None © Copyright Qvis ®. All documentation rights reserved.
  • Page 13 (Local) Pack Duration 8 minutes Pre-record 5 seconds Disk Full Overwrite Record Mode Auto Device No Device MAC address Language English Local Host Video PAL/NTSC Standard Date and time Date Format Y-M-D © Copyright Qvis ®. All documentation rights reserved.
  • Page 14 00:00:00 of the first Sunday of the month End Time 00:00:00 of the second Monday of the month Disable NTP Server clock.isc.org Port 10 minutes Update Period Auto Reboot Enable Auto Maintenance Auto Delete Disable Old Files © Copyright Qvis ®. All documentation rights reserved.

  • Page 15: Framework

    2 Framework 2.1 Dimensions Please refer to the following figure for the dimension information. The unit is mm. See Figure and Figure 2-3. Figure 2-1 Figure 2-2 © Copyright Qvis ®. All documentation rights reserved.

  • Page 16: Structure

    Figure 2-3 2.2 Structure Please refer to the following figure for detailed information (see Figure 2-4). Figure 2-4 © Copyright Qvis ®. All documentation rights reserved.
  • Page 17 Name X-Y-Z rotation module Device lens Dome camera enclosure Name Function Connect to the DC 12+ power to Power input port input the power. Network data input, output and Network port PoE. © Copyright Qvis ®. All documentation rights reserved.

  • Page 18: Installation

    You need to use the proper tool to open up the side port of the U-cable channel of the dome camera pedestal if you want to draw out the cable from the side port of © Copyright Qvis ®. All documentation rights reserved.
  • Page 19 The device GND cable can effectively enhance the device reliability. The GND hole is near the cable exit of the back of the enclosure. The GND screw specification is M3 (see Figure 3-3). Figure 3-3 © Copyright Qvis ®. All documentation rights reserved.

  • Page 20: Sd Card Installation

    Find the ‘SD CARD’ indicator in the enclosure. Adjust the SD card to the proper direction and then install (see Figure 3-4). Step 3 Please refer to the Step 5 in Chapter 2.1 to complete the installation. Figure 3-4 © Copyright Qvis ®. All documentation rights reserved.

  • Page 21: Quick Configuration Tool

    The factory default user name is admin and password is admin. For security reasons, please modify your password after you first login. For detailed WEB operation, please refer to the Network Camera Web Operation Manual in the resource CD. © Copyright Qvis ®. All documentation rights reserved.
  • Page 22 Or you can select an IP address and then click the Login button to go to the login interface. See Figure 4-4. In Figure 4-4, you can view device IP address, user name, password and port. Please modify the corresponding information to login. © Copyright Qvis ®. All documentation rights reserved.
  • Page 23 After you logged in, the configuration tool main interface is shown as below. See Figure 4-5. Figure 4-5 Main interface For detailed information and operation instructions of the quick configuration tool, please refer to the Quick Configuration Tool User’s Manual included in the resources CD. © Copyright Qvis ®. All documentation rights reserved.

  • Page 24: Web Operation

    2. The login interface is shown as below. See Figure 5-2. 3. Please input your user name and password. 4. Default factory name is admin and password is admin. Note: For security reasons, please modify your password after you first login. © Copyright Qvis ®. All documentation rights reserved.
  • Page 25 If you can’t download the ActiveX file, please check whether you have installed the plug-in to disable the control download. Or you can lower the web browser’s security level. See Figure 5-3. Figure 5-3 IE security level © Copyright Qvis ®. All documentation rights reserved.
  • Page 26 After you logged in, you can see the main window. See Figure 5-4: Figure 5-4 Web monitoring window © Copyright Qvis ®. All documentation rights reserved.

  • Page 27: Faq

    Note  This user’s manual is for reference only. Slight differences may be found in user interface.  All the designs and software here are subject to change without prior written notice. © Copyright Qvis ®. All documentation rights reserved.
  • Page 28 For more information about our IP Cameras and other available cameras, NVRs & accessories, please visit our website: www.adata.co.uk Alternatively scan this QR code with your smart phone to be directed instantly to our website: © Copyright Qvis ®. All documentation rights reserved.
