Qvis HOMECAM1WIFI User Manual

720p home ip cameras
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HOMECAM1
HOMECAM1WIFI
720P HOME IP CAMERAS
User's Manual

Advertisement

Table of Contents
loading

Related Manuals for Qvis HOMECAM1WIFI

Summary of Contents for Qvis HOMECAM1WIFI

  • Page 1 HOMECAM1 HOMECAM1WIFI 720P HOME IP CAMERAS User’s Manual...
  • Page 3 Welcome Thank you for purchasing the 720P Home IP Camera. This user’s manual is designed to be a reference tool for the installation and operation of your system. Here you can find information about the corresponding IP camera’s features and functions, as well as a detailed installation method. Before installation and operation please read the following safeguards and warnings carefully!
  • Page 4 Important Safeguards and Warnings 1．Electrical safety  All installation and operation here should conform to your local electrical safety codes.  The power supply shall conform to the requirement in the SELV (Safety Extra Low Voltage) and must make sure that the limited power source is rated 12V DC or 24V AC. Please note: Do not connect two power supplying sources to the device at the same time;...
  • Page 5  Please make sure the CCD (CMOS) component is away from the radiation of the laser beam device. Otherwise it may result in CCD (CMOS) optical component damage.  It is recommended that the grounding studs of the product should be grounded, so to further enhance the reliability of the camera.

  • Page 6: Table Of Contents

    Table of Contents General Introduction ...................... 1 Overview ......................1 Features ......................1 Specifications ....................2 1.3.1 Performance ....................2 1.3.2 Factory Default Setup ................. 4 Framework ........................11 Device Components ..................11 Dimensions ..................... 13 Bidirectional talk ....................14 2.3.1 Device-end to PC-end................

  • Page 7: General Introduction

     Real-time response to external on-off alarm input. User can setup prerecord time length before alarm trigger incident ( also allows user to pre-record audio Alarm file)  Real-time video detect: motion detect, camera masking, PIR human body Function movement detect. © Copyright Qvis ®. All documentation rights reserved.

  • Page 8: Specifications

    Remote operation interface such as WEB, DSS, PSS. System Status Bit stream statistics, log, and software version. Image Sensor 1/3-inch CMOS Pixel 1280(H)*960(V) Gain Control Fixed/Auto White Balance Manual/Auto On/Off Exposure Mode Manual/Auto © Copyright Qvis ®. All documentation rights reserved.
  • Page 9 1-channel input and 1-channel output (on-off ) Record Priority Manual>Video detect>Schedule SD Card Storage Support Micro SD card hot-swap Storage Support display network storage status Management Wire Network 1-channel wire Ethernet port, 10/100 Base-T Ethernet © Copyright Qvis ®. All documentation rights reserved.

  • Page 10: Factory Default Setup

    Item HOMECAM1 HOMECAM1WIFI Brightness Contrast Saturation Sharpness Anti-flicker Outdoor Exposure Mode Auto Gain Range 0-50 Scene Mode Auto Day/night Mode Auto Mirror Flip Bit stream type General Main Stream Encode mode H.264 © Copyright Qvis ®. All documentation rights reserved.
  • Page 11 Enable Enable Main Stream Encode Mode G.711A Extra Stream Enable Disable Host Name Ethernet Card Wire(default) TCP/IP Mode Static Device MAC address when it is shipped out of the Mac Address factory © Copyright Qvis ®. All documentation rights reserved.
  • Page 12 Domain Name none User none Password **** Update Period 10 minutes IP Filter Trusted sites Disable SMTP Server none Port Anonymity Disable User Name anonymity SMTP(Email) **** Password Sender none Authentication (Encryption © Copyright Qvis ®. All documentation rights reserved.
  • Page 13 Disable WIFI Enable WIFI Null SSID Null Button Disable Real-time Monitor Command Enable Disable Wireless QoS Enable Disable Anti-dither 5 seconds Sensitivity Motion Detect Compensation Disable Light Compensation 10 seconds Light Delay © Copyright Qvis ®. All documentation rights reserved.
  • Page 14 Relay in Alarm 1 Anti-dither 0 second Sensor Type Compensation Disable Light Alarm Compensation Activation 10 seconds Light Delay Record Enable Channel Record Delay Enable Relay out 10 seconds Alarm Delay 10 seconds © Copyright Qvis ®. All documentation rights reserved.
  • Page 15 Relay out Delay 10 seconds Local Storage Enable Storage Position Disable Enable FTP Disable Server IP Port Username anonymous Password Share Remote path Emergency Disable Storage (Local) Record Control Pack Duration 8 minutes © Copyright Qvis ®. All documentation rights reserved.
  • Page 16 00:00:00 of the first Sunday of the month End Time 00:00:00 of the second Monday of the month Disable NTP Server clock.isc.org Port Update Period 10 minutes Auto Reboot Enable. 02:00 Tuesday Auto Auto Delete Old Maintenance Disable Files © Copyright Qvis ®. All documentation rights reserved.

  • Page 17: Framework

    Network indicator light  Wireless network connection - Green light is on. Speaker Output audio signal. Activates motion detection, PIR White light human body movement detection and external alarm. © Copyright Qvis ®. All documentation rights reserved.
  • Page 18 1 minute. Alarm pin I/O port Alarm signal input/output Power port DC12V Input DC 12V power.  Connect to standard Ethernet Network port Ethernet port cable.  Supports PoE function. © Copyright Qvis ®. All documentation rights reserved.

  • Page 19: Dimensions

    2.2 Dimensions Please refer to the following figure for dimension information. The unit is mm (see Figure 2-2). Figure 2-2 © Copyright Qvis ®. All documentation rights reserved.

  • Page 20: Bidirectional Talk

    Note: Please go to the Master Volume interface of the PC to set it first if you want to use the dual-way bidirectional talk. Please select Front MIC mode in the record control interface. (You can select microphone enhanced in ‘Advanced’ interface if the audio is too low.) © Copyright Qvis ®. All documentation rights reserved.

  • Page 21: Alarm Setup

    Please refer to the following figure for alarm output information (see Figure 2-5). Port NO and Port C comprises of an on-off button to provide the alarm output. This button is normally open. The button turns off when there is an alarm output. © Copyright Qvis ®. All documentation rights reserved.
  • Page 22 Figure 2-5 © Copyright Qvis ®. All documentation rights reserved.

  • Page 23: Device Installation

    Step 4: Use the screws from the accessories bag to secure the device firmly. Step 5 Connect the cable and then boot up the device. © Copyright Qvis ®. All documentation rights reserved.
  • Page 24 Step 7: Secure the knob of the bracket to fix the camera. Figure 3-2 NUMBER KEY ITEM NAME Main IP camera body Adjustment screw Screws Mounting plate Screw Bolts Positioning Map Installation Surface © Copyright Qvis ®. All documentation rights reserved.

  • Page 25: Quick Configuration Tool

    The factory default user name is admin and password is admin. For security reasons, please modify your password after you first login. For detailed WEB operation, please refer to the Network Camera Web Operation Manual in the resource CD. © Copyright Qvis ®. All documentation rights reserved.
  • Page 26 Or you can select an IP address and then click the Login button to go to the login interface. See Figure 4-4. In Figure 4-4, you can view device IP address, user name, password and port. Please modify the corresponding information to login. © Copyright Qvis ®. All documentation rights reserved.
  • Page 27 After you logged in, the configuration tool main interface is shown as below. See Figure 4-5. Figure 4-5 Main interface For detailed information and operation instructions of the quick configuration tool, please refer to the Quick Configuration Tool User’s Manual included in the resources CD. © Copyright Qvis ®. All documentation rights reserved.

  • Page 28: Web Operation

    2. The login interface is shown as below. See Figure 5-2. 3. Please input your user name and password. 4. Default factory name is admin and password is admin. Note: For security reasons, please modify your password after you first login. © Copyright Qvis ®. All documentation rights reserved.
  • Page 29 If you can’t download the ActiveX file, please check whether you have installed the plug-in to disable the control download. Or you can lower the web browser’s security level. See Figure 5-3. Figure 5-3 IE security level © Copyright Qvis ®. All documentation rights reserved.
  • Page 30 After you logged in, you can see the main window. See Figure 5-4: Figure 5-4 Web monitoring window © Copyright Qvis ®. All documentation rights reserved.

  • Page 31: Faq

    Please replace with an industrial-grade power adapter if you are using it in a harsh environment. © Copyright Qvis ®. All documentation rights reserved.
  • Page 32 Note  This user’s manual is for reference only. Slight differences may be found in user interface.  All the designs and software here are subject to change without prior written notice. © Copyright Qvis ®. All documentation rights reserved.
  • Page 33 For more information about our IP Cameras and other available cameras, NVRs & accessories, please visit our website: www.adata.co.uk Alternatively scan this QR code with your smart phone to be directed instantly to our website: © Copyright Qvis ®. All documentation rights reserved.
