Summary of Contents for Qvis APOIP-BL

  • Page 1 APOIP-BL 1080P WDR BULLET IP CAMERA User’s Manual V1.0 08 / 2013...
  • Page 3 Welcome Thank you for purchasing the APOIP-BL 1080P WDR BULLET. This user’s manual is designed to be a reference tool for the installation and operation of your system. Here you can find information about the corresponding IP camera’s features and functions, as well as a detailed installation method.

  • Page 4: Important Safeguards And Warnings

    Important Safeguards and Warnings 1．Electrical safety  All installation and operation here should conform to your local electrical safety codes.  The power supply shall conform to the requirement in the SELV (Safety Extra Low Voltage) and must make sure that the limited power source is rated 12V DC or 24V AC. Please note: Do not connect two power supplying sources to the device at the same time;...
  • Page 5  Please make sure the CCD (CMOS) component is away from the radiation of the laser beam device. Otherwise it may result in CCD (CMOS) optical component damage.  It is recommended that the grounding studs of the product should be grounded, so to further enhance the reliability of the camera.

  • Page 6: Table Of Contents

    Table of Contents General Introduction ...................... 1 Overview ......................1 Features ......................1 Specifications ....................2 1.3.1 Performance ....................2 1.3.2 Factory Default Setup ................. 4 Structure ........................19 Multiple-function Combination Cable............... 19 Framework and Dimension ................20 Bidirectional talk ....................21 2.3.1 Device-end to PC-end................

  • Page 7: General Introduction

    Network  Supports a maximum of 20 connections. Monitor  Adopts the following audio and video transmission protocols: HTTP, TCP, UDP, MULTICAST, RTP/RTCP, RTSP, etc.  Supports web access. © Copyright Qvis ®. All documentation rights reserved.

  • Page 8: Specifications

    PAL: It ranges from 1/3 to 1/10000 NTSC: It ranges from 1/4 to 1/10000 Video H.264/ H.264B/MJPEG Compression Standard PAL: Main stream (1080P@25fps, SXGA@25fps, 1.3M@25fps, Video Frame 720P@25fps, D1@25fps) Rate Extra stream (D1@25fps, CIF@25fps). © Copyright Qvis ®. All documentation rights reserved.
  • Page 9 1-channel analog video output，BNC port. Reset button Restore Default Setup Support AC24V/DC12V power. (Cannot support these two modes at the same Power time.) Power 8W MAX (10W MAX when ICR switch) Consumption Working C~+60 Temperature © Copyright Qvis ®. All documentation rights reserved.

  • Page 10: Factory Default Setup

    Default Setup Brightness Contrast Saturation Sharpness Anti-flicker Outdoor Gain Adjust 0-50 Exposure Auto Mode Auto Iris Scene Mode Auto Day/night Auto Mode Mirror Flip 3D NR General H.264 1080P(1920*1080) 720P(1280*720) PAL:25 NTSC:30 © Copyright Qvis ®. All documentation rights reserved.
  • Page 11 Setup Item Default Setup 3584-8192 Kb/S 8192 Enable Digital CCTV Enable General H.264B PAL:CIF(352*288) NTSC:CIF(352*240) PAL:25 NTSC:30 © Copyright Qvis ®. All documentation rights reserved.
  • Page 12 Setup Item Default Setup 192-1024Kb/S 1024 General 1080P(1920*1080) 720P(1280*720) Better Disable Enable Enable C:\PictureDownload C:\RecordDownload © Copyright Qvis ®. All documentation rights reserved.
  • Page 13 Setup Item Default Setup Enable G.711A Disable G.711A Wire(Default) Static Device MAC address when it is shipped out of the factory IPV4 192.168.1.108 255.255.255.0 192.168.1.1 © Copyright Qvis ®. All documentation rights reserved.
  • Page 14 Setup Item Default Setup 8.8.8.8 8.8.8.8 Enable /Pin devi addr serv 37777 37778 Disable © Copyright Qvis ®. All documentation rights reserved.
  • Page 15 Setup Item Default Setup none Disable，CN99 DDNS none none none **** 10 minutes Disable none © Copyright Qvis ®. All documentation rights reserved.
  • Page 16 Setup Item Default Setup Disable anonymity **** none IPC Message 0 second Disable，interval=60 seconds Disable Disable © Copyright Qvis ®. All documentation rights reserved.
  • Page 17 Setup Item Default Setup Disable Disable public private Enable 239.255.42.42 36666 © Copyright Qvis ®. All documentation rights reserved.
  • Page 18 Setup Item Default Setup Disable 5 seconds Enable 10 seconds Enable 10 seconds Disable Disable Disable Enable © Copyright Qvis ®. All documentation rights reserved.
  • Page 19 Setup Item Default Setup 10 seconds Enable 10 seconds Disable Disable Disable Alarm 1 0 second Enable 10 seconds Enable © Copyright Qvis ®. All documentation rights reserved.
  • Page 20 Setup Item Default Setup 10 seconds Disable Disable Relay output Disable Enable 10 seconds Disable Disable Enable 10 seconds © Copyright Qvis ®. All documentation rights reserved.
  • Page 21 Setup Item Default Setup Disable Disable Enable 10 seconds Disable Disable Enable 10 seconds Enable 10 seconds Disable Enable © Copyright Qvis ®. All documentation rights reserved.
  • Page 22 Setup Item Default Setup 10 seconds Enable 10 seconds Disable anonymity share Disable 8 minutes Pre- 5 seconds reco Disk Overwrite Full © Copyright Qvis ®. All documentation rights reserved.
  • Page 23 Setup Item Default Setup Auto Main stream Stre Device MAC English Y-M-D GMT+08:00 Sync Disable Week 00:00:00 of the first Sunday of the month © Copyright Qvis ®. All documentation rights reserved.
  • Page 24 Setup Item Default Setup 00:00:00 of the second Monday of the month Disable clock.isc.org 10 minutes Enable Disable © Copyright Qvis ®. All documentation rights reserved.

  • Page 25: Structure

    Output audio signal to the devices such as AUDIO OUT port the sound box. Video output Output analog video signal. It can connect to VIDEO OUT port the TV monitor to view the video. © Copyright Qvis ®. All documentation rights reserved.

  • Page 26: Framework And Dimension

    Please refer to Figure 2-2 or Figure 2-3 for dimension information according to the actual product. The unit is mm. Please also see Figure 2-4. Figure 2-2 Dimension illustration 1 © Copyright Qvis ®. All documentation rights reserved.

  • Page 27: Bidirectional Talk

    4. Click Audio button again to stop the bidirectional talk function. Listening Operation At the camera device end, speak via the speaker or the pickup microphone, and then you can get the audio from the earphone or sound box at the pc-end. © Copyright Qvis ®. All documentation rights reserved.

  • Page 28: Pc-End To The Device-End

    (NO/NC.) 4. Set the WEB alarm output. The alarm output 01 is for the alarm output port of the device. It is the No.2 pin of the I/O cable. Figure 2-5 Alarm © Copyright Qvis ®. All documentation rights reserved.
  • Page 29 If the type is NO, this button is normally open. The button becomes on when there is an alarm output. If the type is NC, this button is normally off. The button becomes off when there is an alarm output. Figure 2-7 Alarm output © Copyright Qvis ®. All documentation rights reserved.

  • Page 30: Installation

    Please line up the installation holes of the bottom of the pendant mount bracket to the installation holes on the surface. Then insert the three bolts to the holes of the bottom of the bracket. Finally fasten the device onto the installation surface. Figure 3-1 Device installation 1 © Copyright Qvis ®. All documentation rights reserved.

  • Page 31: Micro Sd Card Installation

    Otherwise, it may result in device malfunction.  The rear cover of the device is designed to be waterproof. Please secure four screws firmly after you complete the Micro SD card installation. (Go to next page for diagrams) © Copyright Qvis ®. All documentation rights reserved.
  • Page 32 Figure 3-3 Micro SD card installation 1 Figure 3-4 Micro SD card installation 2 © Copyright Qvis ®. All documentation rights reserved.

  • Page 33: Lens Adjustment

    Important: Please make sure the M4 inner hex screw or M4 inner hex flat tight screws are firm, otherwise it may result in chassis vibration and the camera will not be able to fix to a specified angle. © Copyright Qvis ®. All documentation rights reserved.
  • Page 34 Figure 3-6 Bracket adjustment 1 © Copyright Qvis ®. All documentation rights reserved.
  • Page 35 Figure 3-7 Bracket adjustment 2 © Copyright Qvis ®. All documentation rights reserved.

  • Page 36: Osd Buttons

    Bottom button: Focus zoon out.  Left button: Far.  Right button: Near.  Middle button: Auto focus. It is to get clear video. Figure 3-8 OSD button 1 Figure 3-9 OSD button 2 © Copyright Qvis ®. All documentation rights reserved.

  • Page 37: Quick Configuration Tool

    The factory default user name is admin and password is admin. For security reasons, please modify your password after you first login. For detailed WEB operation, please refer to the Network Camera Web Operation Manual in the resource CD. © Copyright Qvis ®. All documentation rights reserved.
  • Page 38 Or you can select an IP address and then click the Login button to go to the login interface. See Figure 4-4. In Figure 4-4, you can view device IP address, user name, password and port. Please modify the corresponding information to login. © Copyright Qvis ®. All documentation rights reserved.
  • Page 39 After you logged in, the configuration tool main interface is shown as below. See Figure 4-5. Figure 4-5 Main interface For detailed information and operation instructions of the quick configuration tool, please refer to the Quick Configuration Tool User’s Manual included in the resources CD. © Copyright Qvis ®. All documentation rights reserved.

  • Page 40: Web Operation

    2. The login interface is shown as below. See Figure 5-2. 3. Please input your user name and password. 4. Default factory name is admin and password is admin. Note: For security reasons, please modify your password after you first login. © Copyright Qvis ®. All documentation rights reserved.
  • Page 41 If you can’t download the ActiveX file, please check whether you have installed the plug-in to disable the control download. Or you can lower the web browser’s security level. See Figure 5-3. Figure 5-3 IE security level © Copyright Qvis ®. All documentation rights reserved.
  • Page 42 After you logged in, you can see the main window. See Figure 5-4: Figure 5-4 Web monitoring window © Copyright Qvis ®. All documentation rights reserved.

  • Page 43: Faq

    Note  This user’s manual is for reference only. Slight differences may be found in user interface.  All the designs and software here are subject to change without prior written notice. © Copyright Qvis ®. All documentation rights reserved.
  • Page 44 For more information about our IP Cameras and other available cameras, NVRs & accessories, please visit our website: www.adata.co.uk Alternatively scan this QR code with your smart phone to be directed instantly to our website: © Copyright Qvis ®. All documentation rights reserved.
