APOHDSDI-MB
1080P HD-SDI ANALOGUE CAMERA
User's Manual
V1.0 11 / 2013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the APOHDSDI-MB and is the answer not in the manual?

Questions and answers

Related Manuals for Qvis APOHDSDI-MB

Summary of Contents for Qvis APOHDSDI-MB

  • Page 1 APOHDSDI-MB 1080P HD-SDI ANALOGUE CAMERA User’s Manual V1.0 11 / 2013...
  • Page 3 Welcome Thank you for purchasing our 1080P HD-SDI ANALOGUE CAMERA. This user’s manual is designed to be a reference tool for the installation and operation of your system. Here you can find information about the corresponding analogue camera’s features and functions, as well as a detailed installation method. Before installation and operation please read the following safeguards and warnings carefully!
  • Page 4 Important Safeguards and Warnings 1．Electrical safety  All installation and operation here should conform to your local electrical safety codes.  The power supply shall conform to the requirement in the SELV (Safety Extra Low Voltage) and must make sure that the limited power source is rated 12V DC. Please note: Do not connect two power supplying sources to the device at the same time;...
  • Page 5  Please make sure the CCD (CMOS) component is away from the radiation of the laser beam device. Otherwise it may result in CCD (CMOS) optical component damage.  It is recommended that the grounding studs of the product should be grounded, so to further enhance the reliability of the camera.

  • Page 6: Table Of Contents

    Table of Contents General Introduction ...................... 1 Overview ......................1 Features ......................1 Specifications ....................2 1.3.1 Performance ....................2 Framework ........................3 Multiple-function Combination Cable..............3 Dimension ......................4 Installation ........................5 Device Installation ..................... 5 Lens Adjustment ....................6 OSD Setup Menu ......................

  • Page 7: General Introduction

    Supports 1080P@25fps, 1080P@30fps, 720P@25fps, 720P@30fps, 720P@50fps, 720P@60fps. Assistant  Supports WDR (Wide Dynamic Range). Function  Supports anti-flicker.  Supports HLC (Highlight Compensation).  Backlight compensation: auto screen split allow backlight compensation to adjust the brightness. © Copyright Qvis ®. All documentation rights reserved.

  • Page 8: Specifications

    Support DC 12V power Power Max: 6W Consumption Protective IP66 Level Working -10°C~+60°C Temperature Working ≤95% Humidify Dimensions 70 X 66 X 160 (Unit: mm) Weight 500g (without packaging) Installation Wall-mount, ceiling © Copyright Qvis ®. All documentation rights reserved.

  • Page 9: Framework

    Send out SDI video stream conforming to the HD-SDI SDI output HD-SDI standard. RS485 port. Control the 485 configuration tool to RS485 RS485 port set image. Power input DC 12V Power port. Input DC 12V. port © Copyright Qvis ®. All documentation rights reserved.

  • Page 10: Dimension

    2.2 Dimension Please refer to the following two figures for dimension information. The unit is mm. See Figure 2-2 and Figure 2-3: Figure 2-2 Dimension illustration 1 Figure 2-3 Dimension illustration 2 © Copyright Qvis ®. All documentation rights reserved.

  • Page 11: Installation

    (wall or ceiling). Device sunshield can be moved either forward or backward. Tighten screw on sunshield after you have fixed the device into place. Connect device’s external wiring. STEP 5: Figure 3-1 Device installation illustration © Copyright Qvis ®. All documentation rights reserved.

  • Page 12: Lens Adjustment

    See Figure 3-2. Step 1: Use screwdriver to loosen adjusting screw. Step 2: Adjust device up/down/left/right according to your need. Step 3: Use screwdriver to tighten adjusting screw. Figure 3-2 Lens adjustment © Copyright Qvis ®. All documentation rights reserved.

  • Page 13: Osd Setup Menu

    Shutter 1/250, 1/120, 1/100, 1/60, 1/50, 1/30, 1/25, 1/15, 1/12, 1/10, 1/8, 1/6, 1/5, 1/4, 1/3, custom Shutter 0~ 300ms Manual Shutter 0~ 300ms Gain Max 0~ 100 Gain Min 0~ 100 © Copyright Qvis ®. All documentation rights reserved.
  • Page 14 Click on Apply when you modified setup. 3DNR 0~ 100 Sharpness 0~ 100 Brightness 0~ 100 Contrast 0~ 100 Image Saturation 0~ 100 1080P@25, 1080P@30, 720P@25, 720P@30, Video 720P@50, 720P@60 Default Except video and language, restore all default. © Copyright Qvis ®. All documentation rights reserved.

  • Page 15: Faq

    Note  This user’s manual is for reference only. Slight differences may be found in user interface.  All the designs and software here are subject to change without prior written notice. © Copyright Qvis ®. All documentation rights reserved.
  • Page 16 For more information about our IP Cameras and other available cameras, NVRs & accessories, please visit our website: www.adata.co.uk Alternatively scan this QR code with your smart phone to be directed instantly to our website: © Copyright Qvis ®. All documentation rights reserved.
