  • Page 1 APOHDSDI-VAN 1080P HD-SDI ANALOGUE CAMERA User’s Manual V1.0 11 / 2013...
  • Page 3 Welcome Thank you for purchasing our 1080P HD-SDI ANALOGUE CAMERA. This user’s manual is designed to be a reference tool for the installation and operation of your system. Here you can find information about the corresponding analogue camera’s features and functions, as well as a detailed installation method. Before installation and operation please read the following safeguards and warnings carefully!
  • Page 4 Important Safeguards and Warnings 1．Electrical safety  All installation and operation here should conform to your local electrical safety codes.  The power supply shall conform to the requirement in the SELV (Safety Extra Low Voltage) and must make sure that the limited power source is rated 12V DC. Please note: Do not connect two power supplying sources to the device at the same time;...
  • Page 5  Please make sure the CCD (CMOS) component is away from the radiation of the laser beam device. Otherwise it may result in CCD (CMOS) optical component damage.  It is recommended that the grounding studs of the product should be grounded, so to further enhance the reliability of the camera.

  • Page 6: Table Of Contents

    Table of Contents General Introduction ...................... 1 Overview ......................1 Features ......................1 Specifications ....................2 1.3.1 Performance ....................2 Framework ........................3 Installation ........................4 Device Installation ..................... 4 Lens Adjustment ....................7 OSD Button ........................8 OSD Setup Menu ......................9 FAQ ..........................

  • Page 7: General Introduction

    Supports 1080P@25fps, 1080P@30fps, 720P@25fps, 720P@30fps, 720P@50fps, 720P@60fps. Assistant  Supports WDR (Wide Dynamic Range). Function  Supports anti-flicker.  Supports HLC (Highlight Compensation).  Backlight compensation: auto screen split allow backlight compensation to adjust the brightness. © Copyright Qvis ®. All documentation rights reserved.

  • Page 8: Specifications

    10W MAX (12W MAX with ICR switch) Consumption Protective IP66 Level Working -10°C~+60°C Temperature Working ≤95% Humidify Dimensions Φ160×118.5 (Unit: mm) Weight 1.25Kg (without packaging) Support various installation modes （ Enclosure and bracket are Installation optional） © Copyright Qvis ®. All documentation rights reserved.

  • Page 9: Framework

    2 Framework Camera’s dimension and structure information is shown below. The units are in mm. See Figure 2-1 and Figure 2-2: Figure 2-1 Figure 2-2 © Copyright Qvis ®. All documentation rights reserved.

  • Page 10: Installation

    Use the inner hexagonal wrench (provided) to loosen the three inner hexagonal screws in the dome and then remove the device pedestal. See Figure 3-2. With IR light Without IR light Figure 3-2 © Copyright Qvis ®. All documentation rights reserved.
  • Page 11 A. Slightly push in the two sides so you can squeeze the plastic hook to take off the dome enclosure. B. Manually loosen the screws slightly at the two sides of the X-Y-Z module. You can adjust the module tilt rotation angle to somewhere between 15°～90°. © Copyright Qvis ®. All documentation rights reserved.
  • Page 12 Put the dome cover back and then put the three inner hexagon screws into the holes of the device. Use the inner hexagonal wrench to fasten these three screws tightly. See Figure 3-6. © Copyright Qvis ®. All documentation rights reserved.

  • Page 13: Lens Adjustment

    STEP4 Lay the aperture plate on the lens so that it is flat against it. Please note this step is for IR device only. With IR light Without IR light Figure 3-7 © Copyright Qvis ®. All documentation rights reserved.

  • Page 14: Osd Button

    Figure 4-1 Push the button up/down to select the corresponding item and then push the button left/right to adjust the parameter. See Figure 4-2. Left Right Down Figure 4-2 © Copyright Qvis ®. All documentation rights reserved.

  • Page 15: Osd Setup Menu

    Shutter 1/250, 1/120, 1/100, 1/60, 1/50, 1/30, 1/25, 1/15, 1/12, 1/10, 1/8, 1/6, 1/5, 1/4, 1/3, custom Shutter 0~ 300ms Manual Shutter 0~ 300ms Gain Max 0~ 100 Gain Min 0~ 100 © Copyright Qvis ®. All documentation rights reserved.
  • Page 16 Click on Apply when you modified setup. 3DNR 0~ 100 Sharpness 0~ 100 Brightness 0~ 100 Contrast 0~ 100 Image Saturation 0~ 100 1080P@25, 1080P@30, 720P@25, 720P@30, Video 720P@50, 720P@60 Default Except video and language, restore all default. © Copyright Qvis ®. All documentation rights reserved.

  • Page 17: Faq

    Note  This user’s manual is for reference only. Slight differences may be found in user interface.  All the designs and software here are subject to change without prior written notice. © Copyright Qvis ®. All documentation rights reserved.
  • Page 18 For more information about our IP Cameras and other available cameras, NVRs & accessories, please visit our website: www.adata.co.uk Alternatively scan this QR code with your smart phone to be directed instantly to our website: © Copyright Qvis ®. All documentation rights reserved.
