  • Page 1 APOIP-VAN APO-VANIR-2 1.3 & 2 MEGA PIXEL VANDAL DOME IP CAMERAS User’s Manual...
  • Page 3 Welcome Thank you for purchasing the 1.3 or 2MP Vandal Dome IP Camera. This user’s manual is designed to be a reference tool for the installation and operation of your system. Here you can find information about the corresponding IP camera’s features and functions, as well as a detailed installation method.

  • Page 4: Important Safeguards And Warnings

    Important Safeguards and Warnings 1．Electrical safety  All installation and operation here should conform to your local electrical safety codes.  The power supply shall conform to the requirement in the SELV (Safety Extra Low Voltage) and must make sure that the limited power source is rated 12V DC or 24V AC. Please note: Do not connect two power supplying sources to the device at the same time;...
  • Page 5  Please make sure the CCD (CMOS) component is away from the radiation of the laser beam device. Otherwise it may result in CCD (CMOS) optical component damage.  It is recommended that the grounding studs of the product should be grounded, so to further enhance the reliability of the camera.

  • Page 6: Table Of Contents

    Table of Contents General Introduction ...................... 1 Overview ......................1 Features ......................1 Specifications ....................2 1.3.1 Performance ....................2 Structure ........................5 Dimensions ....................... 5 Port Description....................6 Bidirectional talk ....................8 2.3.1 Device-end to PC-end................. 8 2.3.2 PC-end to the Device-end ................8 Alarm Setup ......................

  • Page 7: General Introduction

     Real-time response to external on-off alarm input. User can setup prerecord time length before alarm trigger incident ( also allows user to pre-record audio Alarm file)  Real-time video detect: motion detect, camera masking, PIR human body Function movement detect. © Copyright Qvis ®. All documentation rights reserved.

  • Page 8: Specifications

    Bit stream statistics, log, and software version. Image Sensor 1/2-inch CMOS 1.3MP:1280(H)*960(V) 1080P: 1920(H)*1080(V) 720P: 1280*720 720P: 1280*720 Pixel D1: 704*576 D1: 704*480 CIF: 352*288 CIF:352*288 Gain Control Manual/Auto White Balance Auto On/Off/BLC/HLC/DWDR © Copyright Qvis ®. All documentation rights reserved.
  • Page 9 Support Micro SD card hot-swap, 32GB Max Support display network storage status Storage Management Wire Network 1-channel wire Ethernet port, 10/100 Base-T Ethernet Network Protocol Standard HTTP, TCP/IP, ARP, IGMP, ICMP, RTSP, RTP,UDP, RTCP, © Copyright Qvis ®. All documentation rights reserved.
  • Page 10 DC 12V and PoE(802.3af) Power 6W MAX Consumption Working C~+60 Temperature Protection Level IP66 & IK10 Working 10%~90% Humidify Φ 151mm * 119mm Dimensions(mm) Weight 1.1Kg (Excluding box) 229g（Excluding box） Installation Installation with the bracket. © Copyright Qvis ®. All documentation rights reserved.

  • Page 11: Structure

    You can refer to the following figures for dimension information. The Unit is mm (see Figure 2- 1 & Figure 2- 2 Figure 2- 1 Dimension illustration 1 Figure 2- 2 Dimension illustration 2 © Copyright Qvis ®. All documentation rights reserved.

  • Page 12: Port Description

    2.2 Port Description The port is shown in Figure 2 – 3 and Figure 2 – 4. Figure 2 - 3 Port 1 Figure 2 - 4 Port 2 © Copyright Qvis ®. All documentation rights reserved.
  • Page 13 Output analog video signal. It can connect VIDEO_OUT to TV monitor to view video. Note: The external connection port above is based on non-IR series which is identical with the external connection port of IR series. © Copyright Qvis ®. All documentation rights reserved.

  • Page 14: Bidirectional Talk

    Note: Please go to the Master Volume interface of the PC to set it first if you want to use the dual-way bidirectional talk. Please select Front MIC mode in the record control interface. (You can select microphone enhanced in ‘Advanced’ interface if the audio is too low.) © Copyright Qvis ®. All documentation rights reserved.

  • Page 15: Alarm Setup

    When the input signal is connected to the 3.3V or is idle, the device collects the logic ‘1’. When the input signal is grounded, the device collects the logic ‘0’. © Copyright Qvis ®. All documentation rights reserved.
  • Page 16 Port ALARM_C and Port ALARM_NO composes an on-off button to provide the alarm output. If the type is NO, this button is normal open. The button becomes off when there is an alarm output. Figure 2 - 7 Alarm output © Copyright Qvis ®. All documentation rights reserved.

  • Page 17: Installation

    Please refer to Figure 3- 1 for device installation space information. You will find that there are an installation position diagram and installation screws in the accessories bag for you to install the device. Figure 3- 1 Device installation 1 © Copyright Qvis ®. All documentation rights reserved.

  • Page 18: Device Installation Steps

    Step 2: Remove the dome camera enclosure using the inner hex wrench from the accessories bag to unfasten the 3 hex screws on the dome camera enclosure and then remove it © Copyright Qvis ®. All documentation rights reserved.
  • Page 19 This is to enhance device reliability.  If you want to install Micro SD card, please refer to Chapter 3.3. © Copyright Qvis ®. All documentation rights reserved.

  • Page 20: Manual Zoom Lens Focus Operation

    PG11 screw thread. Now secure the tunnel in the PG11 screw threaded hole of the device. © Copyright Qvis ®. All documentation rights reserved.

  • Page 21: Cable Connection

    Refer to Step 3 in Chapter 3.2.1, install and connect the cable pin to the device and then follow the proper steps to go on to continue the installation. Important: This series product has the power connection pin and I/O connection pin for you to pull through the signal cable. © Copyright Qvis ®. All documentation rights reserved.

  • Page 22: Micro Sd Card Installation

    Please find the ‘SD’ mark inside the device and adjust the Micro SD card direction according to prompt direction. Insert the card to the slot and then install the Micro SD card (see Figure 2- 2 Figure 2- 2 Micro SD card © Copyright Qvis ®. All documentation rights reserved.

  • Page 23: Quick Configuration Tool

    The factory default user name is admin and password is admin. For security reasons, please modify your password after you first login. For detailed WEB operation, please refer to the Network Camera Web Operation Manual in the resource CD. © Copyright Qvis ®. All documentation rights reserved.
  • Page 24 Or you can select an IP address and then click the Login button to go to the login interface. See Figure 4-4. In Figure 4-4, you can view device IP address, user name, password and port. Please modify the corresponding information to login. © Copyright Qvis ®. All documentation rights reserved.
  • Page 25 After you logged in, the configuration tool main interface is shown as below. See Figure 4-5. Figure 4-5 Main interface For detailed information and operation instructions of the quick configuration tool, please refer to the Quick Configuration Tool User’s Manual included in the resources CD. © Copyright Qvis ®. All documentation rights reserved.

  • Page 26: Web Operation

    2. The login interface is shown as below. See Figure 5-2. 3. Please input your user name and password. 4. Default factory name is admin and password is admin. Note: For security reasons, please modify your password after you first login. © Copyright Qvis ®. All documentation rights reserved.
  • Page 27 If you can’t download the ActiveX file, please check whether you have installed the plug-in to disable the control download. Or you can lower the web browser’s security level. See Figure 5-3. Figure 5-3 IE security level © Copyright Qvis ®. All documentation rights reserved.
  • Page 28 After you logged in, you can see the main window. See Figure 5-4: Figure 5-4 Web monitoring window © Copyright Qvis ®. All documentation rights reserved.

  • Page 29: Faq

    Note  This user’s manual is for reference only. Slight differences may be found in user interface.  All the designs and software here are subject to change without prior written notice. © Copyright Qvis ®. All documentation rights reserved.
  • Page 30 For more information about our IP Cameras and other available cameras, NVRs & accessories, please visit our website: www.adata.co.uk Alternatively scan this QR code with your smart phone to be directed instantly to our website: © Copyright Qvis ®. All documentation rights reserved.
