Page 1
SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. PELLET STOVE Enviro Maxx-1 TECHNICAL MANUAL PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS PELLET-BURNING ROOM HEATER. FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH.
To prevent the possibility of a fire, ensure that the appliance is properly installed by adhering to the installation instructions. An Enviro dealer will be happy to assist you in obtaining information with regards to your local building codes and installation restrictions.
Page 4
If this power cord should become damaged, a replacement power cord must be purchased from the manufacturer or a qualified Enviro dealer. Be careful that the electrical cord is not trapped under the appliance and that it is clear of any hot surfaces or sharp edges. This unit’s maximum power requirement is 432 watts.
Specifications & S imenSionS pecificationS Figure 1: Dimensions of Maxx. Table 1: Maxx Specifications. Testing Standard Frequency Voltage ASTM 1509-04 60 Hz 110 - 120 V Fuel type Current Max Power wood pellets - 6mm (¼”) dia. 3.6 Amps 432 Watts Description Hopper Capacity Consumption on Low...
Installation eciding here to ocate your ellet ppliance 1. Do not install the stove in a bedroom or room where people sleep in. 2. Locate the stove in a large and open room that is centrally located in the house. This will optimize heat circulation.
Installation learanceS to ombuStibleS Back Wall 4" (10cm) These dimensions are minimum clearances but it is 4" (10cm) recommended that you ensure sufficient room for servicing, routine cleaning and maintenance. Side wall to unit 12 inches (30.5 cm) 12" Back wall to unit 4 inches (10 cm) (30.5cm)
Installation ermination equirementS IT IS RECOMMENDED THAT YOUR PELLET STOVE BE INSTALLED BY AN AUTHORIZED DEALER/INSTALLER. Table 2: Use in conjunction with Figure 7 for allowable exterior vent termination locations. Letter Minimum Clearance Description 24 in (61 cm) Above grass, top of plants, wood, or any other combustible materials. 48 in (122 cm) Beside/below any door or window that may be opened.
Installation utSide reSh onnection This Heater must have adequate air for proper combustion in the room that it is installed. A Fresh-air intake is strongly recommended for all installations. Failure to install intake air may result in improper combustion as well as the unit smoking during Outside power failures.
Installation obile nStallation ● Secure the heater to the floor using the four (4) holes in the pedestal. ● Ensure the unit is electrically grounded to the chassis of your home (permanently). ● Do not install in a room people sleep in. ●...
Installation orizontal xhauSt hrough nStallation Vent installation: install vent at clearances specified by the vent manufacturer. A chimney connector shall not pass through an attic or roof space, closet or similar concealed spaces, or a floor, or ceiling. Where passage through a wall or partition of combustible construction is desired, the installation must conform to CAN/CSA-B365 Installation Code for Solid-Fuel-Burning Appliances and Equipment and with all local regulations, including those referring to regional and national.
Page 13
Installation 8. The pipe must extend at least 12” (30 cm) away from the building. If necessary, bring another length of pipe to the outside of the home to connect to the first section. Do not forget to place high temperature silicone around the pipe that passes through the thimble.
Installation recommended - t hrough ertical iSe and orizontal ermination nStallation Termination cap 90°elbow Wall framing A 45° down elbow may be used in place of the Vertical section termination cap (or stainless steel termination of vent pipe hood). Wall strap Horizontal frame for thimble...
Installation utSide ertical nStallationS To accomplish an outside vertical pipe installation, follow the “h ” OrizOntAl xhAust hrOugh nstAllAtiOns section and then finish it by performing the following (refer to Figure 16). 1. Install a tee with clean out on the outside of the house. 2.
Installation nSide ertical nStallationS 1. Place the unit on the hearth pad if a hearth pad is to be used (or on solid material if installed on a carpeted surface) and space the unit in a manner so when the pellet vent is installed vertically, it will be 3”...
Installation earth ount nStallation Damper Removed or Fastened Open Mantel Minimum 200mm (8") from top of stove Clean-out Min 150mm (6") Fresh-air intake should com from chimney. If holes Floor already exist fresh-air Protection intake can be taken through back of the fireplace or Masonry Fireplace Combustible Floor through the ash dump.
Installation lider amper This is used to regulate the airflow through the pellet stove. The slider damper should be set by a trained technician using magnehelic. 1. To install the optional slider damper Exhaust Channel rod remove the left cabinet side panel. Partially back out the two (2) T-20 Torx screws on the back of the each panel and Exhaust Fan...
Troubleshooting DO NOT: ● Service the stove with wet hands. The stove is an electrical appliance, which may pose a shock hazard if handled improperly. Only qualified technicians should deal with possible internal electrical failures. ● Do not remove from the firebox any screws without penetrating oil lubrication. WHAT TO DO IF: 1.
Page 20
Troubleshooting Poor Quality Fuel – Insufficient energy in the fuel to produce enough heat to keep the stove burning Exhaust Temperature Sensor failure. – Bypass sensor located on Exhaust Blower, if stove now operates properly, the unit may require cleaning or a new sensor. Contact your local dealer for service. Check the fuse on the circuit board.
Page 21
Troubleshooting 7. The convection blower will not function normally. Clean all grill openings at the back and below unit . Check the Voltage across the blower wires, It should adjust with the heat output settings. If not contact your local dealer for service. 8.
Wiring Diagram Brown Exhaust Temperature Sensor Brown White Combustion Blue Blower Black White 120V Black Grounded Plug Ignitor Ground Thermostat White Auger Motor Black White Yellow 5 Amp Fuse Vacuum Yellow Switch Black Yellow White Blue Brown Brown White Convection Purple Purple Blower...
Parts List Reference # Description Part # 120ºF (49ºC) Ceramic Fan Temp Sensor EC-001 IEC Power Cord (115V) EC-043 Window Channel Tape - 6ft (1.8m) EC-058 High Limit Temp Sensor 200ºF (93ºC) Manual Reset EF-016 Silicone Hose EF-018 Slider Damper Rod with Knob EF-050 Glass - Large (9”...
Page 24
Parts List Reference # Description Part # Hopper Lid 50-1635 Trivet 50-1636 Top Front with Mount 50-1637 Heat Exchanger Rod 50-1638 Back Grill - Top 50-1639 Back Grill - Bottom 50-1640 Cabinet Side - Left 50-1641 Cabinet Side - Right 50-1642 Louver Assembly 50-1643...
Industries, our commitment to the highest level of quality and customer service is the most important thing we do. Each Enviro stove is built on a tradition of using only the finest materials and is backed by our Exclusive Lifetime Limited Warranty to the original purchaser. With Enviro, you’re not just buying a stove, you’re buying a company with years of unequalled performance and quality.
Page 28
Limited Warranty on this stove. If unsure as to the extent of this Limited Warranty, contact your authorized Enviro dealer before installation. 10. Sherwood Industries Ltd. will not be responsible for inadequate performance caused by environmental conditions.
Page 29
If the stove is used for commercial purposes, it is excluded from the Limited Warranty. 24. No dealer, distributor, or similar person has the authority to represent or warrant Enviro products beyond the terms contained within the Limited Warranty. Sherwood Industries Ltd. assumes no liability for such warranties or representations.
