Model No.: HL46XSL2

Chapter 3. Disassemble and Assemble

3-1. Remove the Stand

1. Lay down the unit so that back cover faces
upward
2. Remove the Five screws from the back
cover which are indicated with the circles in the
picture above.
3. Remove the stand
10
Back Side
