6-3. Get to know your remote control

Introduction
Universal Remote control
The remote control cannot be operated unless the batteries are properly loaded.
When using the remote control, aim it at the remote sensor on the TV.
Function introduction
EN-7
Haier LED HDTV
1 POWER
Press to turn on and off the TV.
TV DVD SETBOX CABLE
To select one of the system modes in which the remote control
2
can be used.
VCR AUD
3 PICTURE
Press repeatedly to cycle through the available picture modes.
4 AUDIO
Press to cycle through different sound settings.
5 INPUT
Show the input source.
6 MUTE
Switches the video sound on or off.
7 VOLUME UP/DOWN
Press to adjust the volume.
8 MENU
Press to open the on-screen menu.
THUMBSTICK (Up/
Allows you to navigate the on-screen menus and adjust the
9
Down/Left/Right)
system settings to your preference.
0 SLEEP button
Press to display the sleep timer option.
A USB
Press to switch input source to USB in.
Selects MTS sound: Mono, Stereo, and SAP in Analog mode.
B MTS/SAP
Change the audio language in DTV mode.
Press to display the guide when you are watching analog or
C GUIDE
digital channels.
D CCD(closed caption)
Select a closed caption.
E HDMI
Press to select a device connected to the HDMI input
F PC
Press to select the computer connected to the VGA input
G Number buttons
Press to change a channel.
Press to select digital channels. For example, to enter "54-3" ,
H
I
RECALL
Press to jump back and forth between two channels.
Press to scan through channels. To scan quickly between the
J CHANNEL UP/DOWN
last two channels, press and hold down either +/-.
K EXIT
Clears all on-screen displays and returns to TV viewing from any menu.
L ENTER
Accesses the highlighted item in the on-screen menu.
M DISPLAY
Press to display the TV status information on the top of the TV screen.
N REC
Press to start the recording process
Control the USB System.
O USB Functions
Backward /Forward Stop
Press once to display a frozen image of the current program,
P FREEZE
but audio continues. Press again to return to the program.
Q CH.LIST
Open the channel list in TV.
R FAV.LIST
Press to open the favorite channel list in TV.
S ARC(Aspect Ratio Control) Press to change the aspect ratio.
Service Manual
Model No.: HL46XSL2
/
Rewind / Fast
/
Play/Pause REPEAT
25
