Chapter 6. Operation Instructions

6-1. Get to know your TV

Introduction
Introduction
Controls
This is a simplified representation of the TV front panel, side panel control buttons and side inputs.
TV Side panel controls and connections
Menu display. Press to access the on-screen
1 MENU
menu display.
Press to access the input source mode. Press
repeatedly to change the source to the one
2 INPUT
you want to watch. In the MENU screen, the
INPUT button serves as the ENTER button.
Press to adjust the volume. In the MENU screen,
3 VOL +/-
these buttons serve as left/right buttons.
Press to scan through channels. To scan quickly
through channels, press and hold down either
4 CH +/-
+/- . In the MENU screen, these buttons serve
as up/down buttons.
5 POWER
Press to turn on and off the TV.
Receivers IR signals from the remote control.
6 Remote Sensor
Do not put anything near the sensor, which
may block the remote control signal.
7 Power indicator
EN-5
Haier LED HDTV
Service Manual
Model No.: HL46XSL2
MENU
INPUT
VOL
CH
23
