Troubleshooting
a) Motherboard is not turning ON: Check input cables. Make sure you have a
a well tighten wire harness. Measure the un-switched pin (red). You should see
12V (car on) or 0V (car off). NOTE: In P1, P2, P3 modes if V(In) is < 12V, the
M3-ATX-HV will not start.
b) Motherboard is not turning ON (cont): Ensure total system power
consumption does not exceed the M3-ATX-HV specifications.
c) Motherboard is not turning ON (cont). Make sure that the ON/OFF wire
harness from the M3-ATX-HV is connected to the ON/OFF switch of your M/B.
M3-ATX-HV Characteristics
Minimum Input Operating. voltage
Maximum input Operating voltage
Deep-Discharge shutdown threshold
Input current limit (fuse protected)
Max Output Power
Deep Sleep Current Consumption.
Storage and operating temperature
MTBF
Efficiency (Input 9-16V)
Input connectors
Output Connector
*Units starts failing at >125 Celsius. Operating at temperatures above 85C / 185F will drastically reduce
the MTBF.
Maximum Power Characteristics
Output Rail Current (Max)
5V 5A
3.3V 5A
5VSB 1.5A
-12V 0.10A
12V 2-4A (see below)
When operating at <8V or >20V or extreme temperatures, de-rate by 25-50%, ventilation will be required.
12V Rail Output Current (buck/boost converter)
Input (V) 12V out current
6-8V 2A (4A peak)
8-11V 3A (5A peak)
Support and warranty: Standard Hardware Warranty 1Year / US, 2 Year EU
Installation support: 30days via email,
M3-ATX-HV User Guide
6V
34V (clamping will occur at 33-35V)
11.2V
15A
95 Watts (8-16V, see chart below)
0.55mA @ 8V, 0.8mA @ 24V, 0.86mA @ 32V
-55 to +125 degrees Celsius (storage), -40 – 65C (operating)
150,000 hrs @ 50C, 96,000 hrs @65C
>94%, all rails combined, 50% load, V(in)=16V
Fasten 0.25" terminal
ATX Power 20 pin (Molex P/N 39-01-2200)
Current Peak Regulation
(<30 seconds)
7A 1.5%
7A 1.5%
2A 1.5%
0.2A 10%
5A (see below) 2%
Input (V) 12V out current
11-18V 4A (5A peak)
18-34V 3A (5A peak)
