APM2 Rough-In Installation Guide
2.750 in.
(69.85 mm)
1.662 in.
(42.21 mm)
0.594 in.
(15.08 mm)
1.811 in.
(45.99 mm)
Model 264 Pressure Transducer
Figure 4-1.
TOP VIEW
TYP .
1.187 in.
(30.15 mm)
1.624 in.
INSTALLATION WARNING!
(41.25 mm)
SIDE VIEW
Ancillary Product Specifications
#6 SCREW
WIRE CLAMP
3 PLACES
+
+
4.562 in.
(115.87 mm)
5.062 in.
(128.57 mm)
PRESSURE PORTS
Model 264 Pressure Transducer
R0.078 in.
TYP .
(R1.98 mm)
0.312 in.
TYP .
(7.92 mm)
0.385 in.
TYP .
(9.78 mm)
27
