APM2 Rough-In Installation Guide
Section 3. APM2 Central Display Rough-In Installation
For the APM2 Central Display to be installed correctly, the rough-in phase of the project must be completed
properly. This section will outline the specific considerations the General Contractor must pay attention to so
that the final wiring and commissioning will go smoothly.
During rough-in installation, the field wiring can be run in the walls and routed between the triple gang
electrical box, the Building Management System (BMS), power supply, earth ground and so on.
3.1 Required Parts to be Supplied by the Installer
The following is a list of parts required and supplied by the installer for the APM2 Central Display:
•
Triple gang-double deep electrical box (RACO 697 or Appleton M3-350), quantity 1
•
Green grounding screw, quantity 1
•
Power (18 AWG recommended) and signal wiring (22 AWG recommended), as needed. Refer to Phoenix
Recommended Cables on page 33.
•
EMT conduit (if required by local code)
•
24 Vac Transformer
3.2 Parts included with Your Order
The following are parts that are included in your order:
•
APM2 Central Display, quantity 1
•
APM2 Faceplate, quantity 1
•
Mounting screws, 6-32 x 1/2 Phillips head, quantity 5
•
Mating Electrical Connectors, Phoenix Contact MC plug kit, 2 green connectors
3.3 Installation Overview
•
Install in a triple gang-double deep electrical box (RACO 697, Appleton M3-350 or equivalent).
•
Secure the triple gang-double deep electrical box to the stud(s) by using the mounting hole in the side of
the electrical box (see figure below for mounting hole location). Drive the mounting screws from the inside
of the electrical box into the wall studs to prevent sharp objects from protruding into the electrical box.
•
Ensure the mounting is level and flush to the wallboard surface.
APM2 Central Display Rough-In Installation
Required Parts to be Supplied by the Installer
MKT-0262 MPC-1748 Rev 02/13
19
