Section 4. Ancillary Product Specifications

The following specifications are subject to changes without notice.
NOTE:

4.1 Model 264 Pressure Transducer

Table 1. Model 264 Pressure Transducer (Remote Transducer 0-5 V Output)
Model 264 Pressure Transducer
Performance Data
1
Accuracy RSS (at constant temperature)
Non-linearity (BFSL)
Hysteresis
Non-repeatability
2
Thermal Effects
°
Compensated Range F (
Zero/Span Shift % FS/ ° F (
Maximum Line Pressure
Overpressure
Long-term Stability
Position Effect
Unit is factory calibrated at 0g effect in the
vertical position
Environmental Data
Temperature
3
° °
Operating F ( C)
Storage ° F ( ° C)
Physical Description
Case
Dimensions
Mounting
Electrical Connection
Standard
± 1.0 % FS
± 0.96 % FS
0.10% FS
0.05% FS
°
C) 0 - 150 (-18 - 65)
° C) 0.033 (0.06)
10 psi
Up to 10 psi (range dependent)
0.5% FS / year
Range
To 0.5" WC
To 1.0" WC
0 - +175 (-18 - +79)
-65 - +250 (-54 - +121)
Fire-retardant glass filled polyster (UL94 V-0 Approved)
2.75" (69.85 mm) W x 5.062" (128.57 mm)H x 2.40" (61.07 mm) D
Four screw holes on removable zinc-plated steel base (designed for 2.75"
snap track)
Screw type terminal strip
Ancillary Product Specifications
Model 264 Pressure Transducer
Optional
± 0.4 % FS ± 0.25 % FS
± 0.38 % FS ± 0.22 % FS
0.10% FS 0.10% FS
0.05% FS 0.05% FS
Zero Offset (% FS/G)
0.60
0.50
