Summary of Contents for Bel Canto PRE3vb
- Page 2 The content of this manual is furnished for information use only, is subject to change without notice, and should not be construed as a commitment by Bel Canto Design Limited. Bel Canto Design Limited assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual.
- Page 3 Explanation of symbols used in this manual or on the TO COMPLETELY DISCONNECT THIS APPARATUS rear/underside of the apparatus: FROM THE AC MAINS, DISCONNECT THE POWER SUPPLY CORD PLUG FROM THE AC RECEPTACLE. The Lightning Flash with arrowhead symbol within an equilateral triangle, is intended to THE MAINS PLUG OF THE POWER SUPPLY CORD alert the user to the presence of uninsulated SHALL REMAIN READILY ACCESSIBLE.
- Page 4 Fit a new 10 amp BS1362 approved fuse into the carrier GROUNDED. and push the carrier back into the plug. Bel Canto Design Ltd. declare that this product is in conformance The conformity of the designated product with the provisions of with the Low Voltage Directive 73/23/EEC and Electromagnetic...
- Page 5 If the packing becomes Bel Canto Design. lost or damaged, please contact your dealer, distributor or Bel Canto before attempting to transport your unit...
- Page 6 Single Ended RCA and Balanced XLR connectors Because the PRE3 runs cool, it can be placed in are available. XLR jacks allow balanced hookup many system locations without compromise. We do using the standard North American pin configuration: not recommend placing weights or other objects directly on the PRE3 .
- Page 7 Front Panel Control Knob: Home Theater Bypass Operation: The control knob is a continuously rotating control Input 5 can be set to a home theater bypass mode with a push-switch function. (htb) that is used to pass the front left/right outputs from a multichannel processor output through the PRE3 to the main L/R power amplifiers.
- Page 8 The PRE3 Remote Control has a comprehensive set of control features that are not available on the front panel. To access all PRE3 control features press the button marked PRE on the remote control. The Main CD controls will still operate in the DAC, PRE and Tuner modes.
- Page 9 The PRE3 must be powered by either the VBS1 or the LNS1. If using the VBS1, please refer to the • VBS1 User’s Guide for connectivity. If using the LNS1, please read the following The LNS1 is designed to power Bel Canto VB equipped products only. Use of any cable other than the •...
- Page 10 VB power interconnect jack to interface with RCA Line out • • either the VBS1 or LNS1 power supplies RCA Record out • XLR Balanced line outputs • RCA Inputs • XLR Balanced line inputs • Bandwidth: DC-200KHz Volume setting for unity gain: 80.0 Signal to Noise Ratio @ 2 Volt RMS: >105 dB A weighted, 20Hz-20kHz...
- Page 11 version 2.0...
