- Page 2 The content of this manual is furnished for information use only, is subject to change without notice, and should not be construed as a commitment by Bel Canto Design Limited. Bel Canto Design Limited assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual.
- Page 3 Explanation of symbols used in this manual or on the TO COMPLETELY DISCONNECT THIS APPARATUS rear/underside of the apparatus: FROM THE AC MAINS, DISCONNECT THE POWER SUPPLY CORD PLUG FROM THE AC RECEPTACLE. The Lightning Flash with arrowhead symbol within an equilateral triangle, is intended to THE MAINS PLUG OF THE POWER SUPPLY CORD alert the user to the presence of uninsulated SHALL REMAIN READILY ACCESSIBLE.
- Page 4 Fit a new 10 amp BS1362 approved fuse into the carrier GROUNDED. and push the carrier back into the plug. Bel Canto Design Ltd. declare that this product is in conformance The conformity of the designated product with the provisions of with the Low Voltage Directive 73/23/EEC and Electromagnetic...
- Page 5 If the packing becomes Bel Canto Design. lost or damaged, please contact your dealer, distributor or Bel Canto before attempting to transport your unit...
- Page 6 Single Ended RCA and input and output are Because the PHONO3 runs cool, it can be placed available. You can place the PHONO3 close to in many system locations without compromise. We the turntable and minimize the length of the low level do not recommend placing weights or other objects interconnect from your cartridge.
- Page 7 Additional capacitance can be added to this by selecting one of the capacitance values by placing The PHONO3VB default gain setting will be for typical the corresponding switch in the DOWN position: 100pF, high output cartridges, from 2mV to 5mV nominal output 220pF or 390pF.
- Page 8 Resistance switch in down(D) position Effective Load Resistance (ohms) 10000 1000 8250 Selected Capacitor(s) 100 pF 220 pF 390pF Total Load Capacitance 150 pF 250 pF 370 pF 540 pF 470 pF 640 pF 760 pF 860 pF...
- Page 9 The PHONO3 must be powered by either the VBS1 or the LNS1. If using the VBS1, please refer to the • VBS1 User’s Guide for connectivity. If using the LNS1, please read the following The LNS1 is designed to power Bel Canto VB equipped products only. Use of any cable other than the •...
- Page 10 Bandwidth: 1Hz-50KHz RIAA Accuracy: 20Hz-20KHz +/- 0.2 dB Signal to Noise Ratio 40 dB gain: >80 dB A weighted, re 5mV RMS in Distortion @ 2 Volt RMS/1kHz: <0.01% Maximum Output Level: 9.5 V RMS Output Impedance: 100 Ohms single ended Input Impedance: 47K Ohms nominal (all Resistor Switches UP) Gain Level Options:...
- Page 11 version 2.0...
