  • Page 1 Owner’s Manual...

  • Page 2: Owner's Details

    Owner’s Details Model _________________________________________________________________ Vehicle Identification Number V.I.N. _______________________________________ Owner’s Name __________________________________________________________ Address ________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ Tel. No. _________________________________________________________________ Key Nos: All Doors _____________________________________________________ Water Filler Cap ________________________________________________ Retailer’s Name _________________________________________________________ Address ________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ Tel. No. _________________________________________________________________...
  • Page 3 Quoting ref: BOB www.caravanclub.co.uk Or, if you prefer, send your name and address, quoting ref: BOB to: The Caravan Club, Dept. MS, FREEPOST WD3000, East Grinstead, West Sussex RH19 1BR (no stamp needed) and we’ll send you an Enquiry Pack including an application form.

  • Page 4: Table Of Contents

    On leaving caravan site ....... 3-12 2.2.1 Measurement of nose weight ......2-2 3.3.3 Generators ........... 3-12 2.2.2 The caravan to towing vehicle weight ratio ... 2-2 3.3.4 Overseas connections ......... 3-12 2.2.3 Towing vehicle’s rear suspension ....2-2 3.3.5 Mains unit ............
  • Page 5 Contents 4.9.3 Energy Selection ......... 4-18 4.17 THE ALKO CARAVAN CHASSIS ....4-44 4.9.4 Temperature setting cooling compartment .. 4-20 4.17.1 Chassis members ........4-44 4.9.5 Exchange of the igniter’s battery ....4-20 4.17.2 Drilling or welding of parts or accessories ... 4-44 4.9.6...
  • Page 6 Guidance on Cleaning Portable Water Tanks and the Water System and in Touring Caravans ............5-3 5.1.12 For Containers ..........5-4 5.1.13 For Systems ..........5-4 5.1.14 Caravan Keys (Senator only) ......5-4 FIRE AND SAFETY PRECAUTIONS ... 5-5 5.2.1 Children ............5-5 5.2.2 Fire Extinguishers ..........
  • Page 7 Haynes Publishing? They have been written by John Wickersham whose caravanning articles appear every month in several magazines, including the Members’ Magazine of The Caravan Club. The Caravan Handbook. From Haynes “Glove Box” series, this caravanning handbook offers...

  • Page 8: Introduction

    Several sections are ‘common to all models’ in the range, the specific sections relative to a particular model are clearly indicated. All enquiries regarding your caravan must be addressed in the first instance to the dealer from whom the caravan was first purchased.

  • Page 9: Warranty

    Bailey retailers sell our products of their own choice and not as agents. They are, therefore, unable to bind Bailey Caravans Ltd or make any representation or undertaking whatsoever on behalf of Bailey Caravans Ltd.

  • Page 10: Terms And Conditions

    Bailey Service Centre from Bailey Caravans Limited. No liability will exist with regard to any claims not authorised in this way. 8. Bailey Caravans Limited reserve the right to examine the tourer before any repairs commence or any replacement part fitted.

  • Page 11: Caravan Registration And Identification Scheme (C.r.i.s)

    For security reasons keep it in a safe place. If you sell the caravan please follow the instructions on the Touring Caravan Registration Document. If you do not receive a Touring Caravan Registration Document, lose it, or any of the details recorded are incorrect, please contact:...

  • Page 12: Safety

    2-10 of this handbook. ▲ Never attempt to lift the tow hitch with your hands when hitching the caravan to the tow vehicle or at any other time. Always raise or lower the tow hitch by winding the handle on the jockey wheel.
  • Page 13 Introduction...

  • Page 14: Introduction

    Caravan & Tow Vehicle INTRODUCTION Choosing the right car and caravan combination for safe and stable towing is both an art and a science. It may seem complicated to the newcomer, but a few minutes spent understanding the basic principles, common terms and definitions in use will be worthwhile in ensuring your enjoyment of our product.

  • Page 15: Measurement Of Nose Weight

    Another simple method is to use bathroom scales and a suitable piece of strong timber as a platform to rest the tow hitch on. The timber can be placed vertically between the caravan tow hitch and the bathroom scales. The timber should be of such length that when the caravan tow hitch is lowered onto it, using the jockey wheel, the caravan floor is horizontal.

  • Page 16: Recommended Tow Ball Height

    There are a number of suspension aids available and advice should be sought on which to use and how to fit. It is important to ensure that the caravan is towed either level or slightly nose down. If it is not, then the car’s towbar may be at the wrong height.

  • Page 17: Loading And Distribution Of Weight In The Caravan And Car

    2.2.6 Loading and distribution of weight in the caravan and car Equipment and personal effects should be loaded in the caravan so that any heavy items are low down near the floor and mainly over the axle(s). The remainder should be distributed to give a suitable noseweight at the towing coupling (see illustration).

  • Page 18: Noseweight

    Caravan & Tow Vehicle ▲ Always load the caravan in such a way that maximises towing safety. Incorrect caravan loading and/or overloading of the towing vehicles rear suspension will also result in poor towing stability. The weight should be distributed so that each side...

  • Page 19: Hitching The Caravan To The Tow Vehicle

    Shut and lock the caravan exterior. Gauge the height of the car’s tow ball then raise or lower the height of the caravan’s towing hitch to ensure that it is high enough to pass over it cleanly and not hit the tow ball. Rotating the caravans jockey wheel handle can do this.
  • Page 20 The final positioning should be carried out by manoeuvring the caravan by hand. Carefully release the caravan handbrake. Manoeuvre the caravan by hand to position the caravan’s tow hitch directly over the car’s tow ball. ▲ Always manoeuvre the caravan by pushing /pulling on the grab handles only. Not the body panels.

  • Page 21: Towing

    60 mph on dual carriageways and motorways. 2.3.2 Pulling away Allow more engine speed to produce the power to move the additional weight of the caravan. Let the clutch out smoothly. Avoid wear and tear on the clutch and transmission by taking extra care.

  • Page 22: Mirrors

    Reduce speed in high winds, cross winds, downhill or in poor visibility. High sided vehicles such as lorries or coaches can cause air buffeting, so extra care must be taken when passing or being passed. Give as much space as is possible between your caravan and the high sided vehicle.

  • Page 23: Stabilisers

    Caravan & Tow Vehicle 2.3.9 Stabilisers A stabiliser should never be used to try to improve a caravan/towing vehicle combination that has poor stability as instability may appear at higher speed. However, a good stabiliser can make an acceptable caravan/towing vehicle combination more comfortable and easier to handle.

  • Page 24: Tyre Pressures

    If the caravan is not used for long periods of time (winter months) it is recommended that the wheels/ tyres are removed and stored at normal inflation pressure in a cool, dry place protected from direct sunlight, sources of heat, ozone concentrations and fuel/oil contamination.

  • Page 25: Spare Wheels

    In some instances it may be necessary to raise the caravan using a jack to make it easier to remove the spare wheel from the carrier.

  • Page 26: Unhitching

    If you have no alternative but to pitch on a slope ensure that, for when you leave, you are facing down the slope. It is good practice to chock the wheels of the caravan when parked on a slope even though the caravan brakes are applied.

  • Page 27: Levelling The Caravan

    ▲ Under no circumstances should the corner steadies be used as a jack as they are only a means of stabilising the caravan. Levelling pads or boards should be used under the steadies where the ground is soft or uneven.

  • Page 28: The Water System

    Caravan Service Systems THE WATER SYSTEM 3.1.1 Water Supply All models are supplied with a 12 volt submersible pump, controlled by a pressure switch. The water inlet is located in the off-side exterior wall, protected by a lift up lid.

  • Page 29: Whale Smartflo On Board Pump (Pageant & Senator)

    Caravan Service Systems 3.1.3 Whale Smartflo On Board SENATOR CONFIGURATION Pump (Pageant & Senator) PUMP Operation Valves: Both the manual valves included in this system must be positioned appropriately (fig 1-3) when switching between the three functions of the water system; using...
  • Page 30 WALL container. Keep socket lid shut at all SOCKET times when plug is removed. 10. When the caravan is left unattended CARBON FILTER or water supply has been allowed to empty to prevent the pump running continuously, turn off at isolating switch.

  • Page 31: Troubleshooting (Pageant & Senator)

    Caravan Service Systems 3.1.5 Troubleshooting (Pageant & Senator) FAULT CAUSE SOLUTION Pump doesn’t run No power to pump Check power supply Attach leads/clean corrections Check tap microswitch if present. Fuse has blown Replace fuse do not exceed recommended fuse size.

  • Page 32: Routine Maintenance

    This is located under the chest of drawers at the front of the caravan. Firstly ensure that the drain tap, located on the front offside of the caravan, is shut. To fill, place the carbon filter assembly hose inside a filled water container before inserting the plug in the caravan wall socket.

  • Page 33: Aquasource Direct Mains Water Connection

    ● The system is pressure controlled to 1bar to protect your caravan from flooding and sustaining damage to your water system. (Plumbing connections should be checked at the beginning of every season for frost damage or loose connections).

  • Page 34: Waste (Grey) Water System

    Upon arrival at the caravan site advice should always be sought from the site manager as to where waste (Grey) water is to be disposed of.

  • Page 35: Types Of Gas

    ● Always ensure that the gas system is inspected/maintained every 12 months. ● In the event of a fire ensure all occupants evacuate the caravan via the nearest escape route. ● If it is safe to do so turn off the yellow isolating valve located in the gas box directly below the regulator.

  • Page 36: Changing Gas Cylinders

    This is located in the caravan gas box mounted on the front bulkhead of the caravan between the gas bottles. The gas regulator has a working pressure of 30mbar and is suitable for both propane and butane liquefied petroleum gas.

  • Page 37: Ventilation

    Do not operate any electrical apparatus whatsoever, especially light switches. If the leak is not obvious, the caravan should be evacuated and a competent service engineer consulted. Avoid naked lights when connecting or changing a cylinder. Ensure the gas valve is turned off.

  • Page 38: The Electrical System - 230 Volt

    ▲ Check that any residual current device (earth leakage circuit breaker) in the mains supply to the caravan has been tested within the last month. After connection to site supply, test again.

  • Page 39: On Leaving Caravan Site

    ● replace the cover of the socket outlet at the site supply point. It is dangerous to leave the supply socket or supply flexible cable live. Every 12 months, the caravan electrical installation should be inspected and tested and a report on its condition obtained as prescribed in the Regulations for Electrical Installations, published by the Institute of Electrical Engineers.

  • Page 40: Mains Unit

    It is possible that all of the 230v mains electrical equipment may not be able to be operated simultaneously. A typical UK caravan park mains hook up point provides a maximum output of 16 amps and on some continental sites the available output may be as low as 5 amps. If your loading exceeds the site supply it may trip the parks circuit breaker.

  • Page 41: The Electrical System - 12 Volt

    THE ELECTRICAL SYSTEM – 12 VOLT Your caravan is fitted with a 12 volt charger as standard. This converts the 230 volt AC supply into 12 volt DC. This enables the 12 volt equipment in the caravan to function and charges the caravan leisure battery.

  • Page 42: 12-Volt Control Panel

    Auxiliary Battery storage/mains inlet The battery and 230V mains inlet are located in a special locker mounted in the side of the caravan. The door frame has a cable recess allowing the door to be locked when the mains cable is connected.
  • Page 43 ▲ Car type battery chargers are not suitable for charging a leisure battery and may damage When storing the caravan for long periods of time, we recommend that the 12 volt leisure battery is disconnected and removed, except in the case of Senator models - please see 4.23.3 Tracker alarm winter storage.

  • Page 44: The Truma Ultrastore Water Heater

    Caravan Equipment THE TRUMA ULTRASTORE WATER HEATER Operating Instructions 4.1.1 Filling the Truma Ultrastore with water ● Check that the safety/drain valve in the cold water intake is closed. The yellow lever should be in the horizontal position, position (e).

  • Page 45: Gas Operating Instructions

    Caravan Equipment 4.1.2 Gas operating instructions ▲ Never operate the water heater without water in it! ● Remove exterior cowl cover. ● Open gas cylinder and open quick-acting valve in the gas supply line. ● Select required water temperature at rotary knob (a) infinitely variable from approx. 30 to 70 rotating the inner ring (b).

  • Page 46: Electrical Operating Instructions (230V)

    Caravan Equipment 4.1.4 Electrical operating instructions (230v) Ensure that the water heater is full then switch the isolation switch on. (Usually mounted on the bunk face adjacent to the gas control switch.) ▲ The water temperature cannot be selected, temperature is automatically limited to 70 C.

  • Page 47: Important Operating Notes

    This also applies when the caravan is in storage. ● If the water heater is inadvertently operated empty the caravan will trip out. To reset, turn off 5 and 10 amp trips, turn off RCD consumer unit, then fill with water and turn 5 amp trip back on.

  • Page 48: Technical Data

    Caravan Equipment 4.1.9 Technical Data Water contents: ........10 litres Gas and electrical operation ... approx. 25 mins Water pressure: ....up to max. 2.8 bar Power consumption ........12V Type of gas: ..Liquid Gas (propane or butane) Ignition: ........... 0.17 A Operating Pressure: ......

  • Page 49: The Truma S 3002 El Space Heater

    Caravan Equipment THE TRUMA S 3002 EL SPACE HEATER 4.2.1 Gas Operation Switching on ● Turn on gas cylinder. a = Control knob ● For space heaters fitted with manual piezo ignition b = Integrated control panel for Trumavent fan TEB...

  • Page 50: General Safety Notes

    Caravan Equipment ● Any alteration to the appliance (including exhaust duct and cowl) or the use of spare parts and accessories which are important to the function of the heater and which are not original Truma parts, as well as the non-observance of the installation and operating instructions, will lead to the cancelling of the guarantee and exclusion of liability claims.

  • Page 51: Technical Data

    (b) – see technical data. ▲ The pitch lead for the caravan must be a = ON-OFF Power settings fully unwound prior to use.

  • Page 52: Truma 12V Fan Operation

    Caravan Equipment ▲ Any alteration to the appliance (including exhaust duct and cowl) or the use of spare parts and accessories which are important to the function of the heater and which are not original Truma parts, as well as the non-observance of the installation and operating instructions, will lead to the cancelling of the guarantee and exclusion of liability claims.
  • Page 53 Caravan Equipment greater heat requirement. This means that the air output can be used to the full on this side. By adjusting the air flap (Fig. 1:d) the quantity of air can be increased individually. This means that the air output on the other side is reduced.

  • Page 54: The Country Leisure Cooking Appliances

    Caravan Equipment THE COUNTRY LEISURE COOKING APPLIANCES Operating Instructions Ensure the gas cylinder is turned on. In the event of a gas smell turn off at the cylinder and contact supplier. The use of a gas cooking appliance results in the production of heat and moisture in the room in which it is installed.

  • Page 55: The Midi Oven & Grill (Ranger, Pageant & Senator)

    Caravan Equipment THE MIDI OVEN & GRILL (Ranger, Pageant & Senator) 4.6.1 Grill ▲ Accessible parts may be hot when the grill is used! Young children should be kept away. ▲ The heater deflector below the fascia should be pulled out prior to grill operation.

  • Page 56: Oven

    9. Oven shelf : the oven shelf is designed to allow good circulation at the rear of the oven and is fitted with a raised bar to prevent trays or dishes making contact with the back of the oven. Additional shelves are available through our local caravan retailer. 4.6.3 The Duplex Oven &...

  • Page 57: Temperature Control

    Caravan Equipment 4.6.4 Temperature Control The temperature control in the oven is controlled by a thermostatic gas tap and is variable over the range 130°C to 240°C. Approximate temperatures for the settings on the control knob are shown in the table below.

  • Page 58: Maintenance & Servicing

    Caravan Equipment Most cookery books give details of the shelf positions and gas mark settings for each recipe. If in doubt about a recipe you intend to use, study the recipe carefully then find a similar dish in our guide and use our shelf position and gas mark setting recommendation.

  • Page 59: The Fire Sentry Smoke Alarm

    Erratic noise or low sound from alarm may indicate a defective alarm. Return it for service. ▲ Test smoke alarm operation after caravan has been in storage, before each trip and at least once per week during use.

  • Page 60: Refrigerators

    Your caravan is supplied with winter covers as standard equipment. These covers should be fitted when the outside temperature is below 10°C. ▲ The covers should also be used when the caravan is in storage or is being washed by a high pressure spray. or during very wet weather.

  • Page 61: Energy Selection

    Caravan Equipment 4.9.3 Energy Selection 12V Electrical Operation (DC) ▲ The refrigerator should only be used while the motor is running, otherwise the on-board battery would be discharged within a few hours! 1. Set energy selector switch (A) to 12V.
  • Page 62 Caravan Equipment Set energy selector switch (A) to Gas. Press and hold rotary switch (B). Activate ignition by pressing the button (C) and keep it depressed. Check the inspection glass to see whether there is a flame (the inspection glass is inside the refrigerator at the bottom left).

  • Page 63: Temperature Setting Cooling Compartment

    Caravan Equipment 4.9.4 Temperature setting cooling compartment As already shown, with rotary knob (B) the temperature in the cooling compartment can be regulated as necessary. ▲ The cooling unit’s performance is influenced by ambient temperatures. At ambient temperatures of +15 deg C up to +25 deg C, set the knob B to the middle position.

  • Page 64: Dometic Refrigerator Model Rm 8550L (Pageant & Senator)

    Caravan Equipment 4.10 DOMETIC REFRIGERATOR MODEL RM 8550L (Pageant & Senator) 4.10.1 Cleaning Before starting up the refrigerator, it is recommended to clean it inside and repeat this at regular intervals. Use a soft cloth and lukewarm water with a mild detergent. Then wipe out the appliance with clean water and dry thoroughly.

  • Page 65: Electrical Operation

    Caravan Equipment Explanation: The refrigerator is equipped to operate on mains power, 12V DC or liquid gas. Select the desired power supply by turning the energy selector switch A. The energy selector switch A has four settings: OFF, AC mains voltage, DC (battery), gas (liquid gas).

  • Page 66: Door Locking

    Caravan Equipment Prior to starting the refrigerator in gas mode: ● Open the gas cylinder valve. ● Open the shut-off valve for gas supply to the refrigerator. Appliances with battery igniter: Turn the rotary selector switch A to position Turn the temperature selector B clockwise and push.

  • Page 67: Removable Freezer Compartment

    Caravan Equipment Fixing and releasing the door lock hook when parking the vehicle If the vehicle is parked for a longer period of time, the locking hook may be clamped by means of a lockbar. The door may now be opened by just pulling it without need of pressing the locking button.

  • Page 68: Exchange Of The Igniter's Battery

    Caravan Equipment 4.10.9 Exchange of the igniter’s battery Unlock the battery by depressing and turning the button (C) approximately 90 degrees clockwise. Remove cap and exchange battery (1.5V AAA / R3 / Micro). Observe correct polarity. 4.10.10 Shutting off the refrigerator ●...

  • Page 69: Troubleshooting

    Caravan Equipment 4.10.12 Troubleshooting Before notifying the authorised Service Centre, please check whether: ▲ The instructions in the section “Operating the refrigerator” have been followed. ▲ The refrigerator is level. ▲ It is possible to operate the refrigerator with any available power source.

  • Page 70: Maintenance

    Caravan Equipment 14.101.13 Maintenance ● Works on gas components and electrical installation may only be carried out by authorised personnel. We recommend to contact your Dometic Service Centre. ● EN 1949 stipulates that the appliance’s gas equipment and its associated fume system must be inspected after installation and a certificate issued.

  • Page 71: Thetford Refrigerator Model N97 (Ranger)

    Caravan Equipment 4.11 THETFORD REFRIGERATOR MODEL N97 (Ranger) 4.11.1 Switching on the refrigerator ● Clean the inside of the refrigerator before you switch it on. ● Let the refrigerator cool for at least eight hours before you place food in it for the first time.

  • Page 72: Power With Gas

    Caravan Equipment Open the valve of the gas bottle and the gas taps. Set the gas control button to the maximum position. Set the energy source selector switch (A) to ignite the gas flame. 4.11.4 Power with gas 1 Open the valve of the gas bottle and the gas taps.

  • Page 73: Door Locking Mechanism

    Caravan Equipment 4.11.7 Door locking mechanism The refrigerator door has an automatic locking mechanism. The door locks automatically when you press it shut firmly. The lock releases unnoticed when you open the refrigerator with your hand. This automatic locking mechanism also keeps the refrigerator door shut during driving.

  • Page 74: The Thetford Cassette C-200 Cw / Cwe (Discovery & Ranger)

    The waste holding tank that is accessible from the outside of the caravan is located underneath the toilet and is removed for emptying from the outside of the vehicle through an access door. A rotating pour-out spout, automatic holding tank vent, air release valve, valve blade, carrying handles and hand grip are incorporated in the waste holding tank.
  • Page 75 Caravan Equipment 4-32...

  • Page 76: Operation

    Caravan Equipment vii. Open the water fill door and add 50ml. of Aqua Rinse. This results in a better flush and improves the hygiene of the toilet. Then fill the tank with fresh water using a jerry can or hose. Tank Capacity is 7 litres (fig.7).

  • Page 77: Winterising / Storage

    Caravan Equipment and cover and the outside of the toilet. When the toilet is not going to be used for a long time, leave the cap off the pour-out spout and leave the blade open so the cassette can dry.

  • Page 78: The Thetford Cassette C-250 (Pageant & Senator)

    The removable Waste Holding Tank is located under the toilet bowl and can be removed via a door on the outside of the caravan or camper. The Thetford Cassette Toilet is the solution to the sanitary problem in your caravan or camper! The operating instructions cover Thetford Cassette Toilet models C-250S, C-250CS (models connected to the vehicle’s central water tank) and C-250CWE (model with its own flush-water tank).
  • Page 79 Caravan Equipment Standard C250 Optional features C250 Control panel (with optional features) 4-36...

  • Page 80: Preparing For Use (Standard)

    Your toilet is now ready to use. 4.13.3 Preparing for use with Optional Features Automatic Ventilator: Open the access door on the outside of your caravan and remove the Waste Holding Tank (as described above). Remove the filter housing cover and if no filter is present, place a new filter into the filter housing.

  • Page 81: Using The Toilet With Optional Features

    ▲ If your toilet has its own flush-water tank, please make sure that you do not travel with a flush-water tank that is too full. Do not travel with water in the toilet bowl. Failure to adhere to this notice may result in water damage to your caravan or motor home. 4.13.5 Using the toilet with Optional Features 13.

  • Page 82: Cleaning And Maintenance

    Caravan Equipment 20. Waste Pump-Out System: When activating the control panel this feature automatically lights up. When the Waste Holding Tank Level Indicator illuminates, press the Waste Pump-Out button to pump out the waste from the holding tank into the vehicle’s waste tank. The button will flash while the waste is being pumped and will stop automatically (after approximately 5 minutes) when all waste has been transferred.

  • Page 83: Cleaning And Maintenance For Optional Features

    Close the blade. Open the access door on the outside of your caravan or camper and empty the Waste Holding Tank at an authorized waste dump. Follow the instructions for cleaning and maintenance. To allow the Waste Holding Tank to dry, do not place the cap back on the emptying spout of the tank.

  • Page 84: Al-Ko Secure

    Caravan Equipment 4.14 AL-KO SECURE ● Tighten the locking bolt socket using the wheel ● Align the wheel so that the receiver can be spanner provided (or torque wrench as shown) seen in the centre of the rim opening. DO NOT to wheel torque (ideally 86 Nm).

  • Page 85: Al-Ko Atc Trailer Control System

    ATC operation. This can be checked with the use of a multimeter. 4.15.2 Operating instructions After coupling the caravan correctly to the towing vehicle, connect the 12N and 12S plugs or the 13 pin plug to the towbar. Upon connection, ATC will carry out an initial self test and the LED light on the front fairing will light up RED.

  • Page 86: Omnivent Rooflight Mounted Extraction Fan (Pageant & Senator Only)

    Caravan Equipment 4.16 OMNIVENT ROOFLIGHT MOUNTED EXTRACTION FAN (Pageant & Senator only) 4.16.1 Use Ventilator (only for OMNIVENT 12V) The ventilator is started by the switch marked < o > (extraction or intake) The airflow is adjusted by the black switch: position 1 = 7m /min.

  • Page 87: The Alko Caravan Chassis

    4.17.4 Coupling head The ball couplings are entirely automatic in operation and designed for one hand operation to suit the 50mm international ball recommended by the British Standards Institution, National Caravan Council and the Society of Motor Manufacturers and Traders.

  • Page 88: Operation : Type Ak 160 & Ak 300 Coupling Head

    Having lowered the jockey wheel to the ground, operate the handle as previously described. Lift the coupling clear of the towing ball either manually or by operating the telescopic jockey wheel. ▲ If the nose of the caravan is lifted manually the locking trigger (AK 160) must be engaged first and the handle lifted forward.

  • Page 89: Stabiliser Unit

    ‘up’ position. Please do not use the stabiliser lever as an manoeuvring handle. Please use the handles on the Caravan or fit the AL-KO manoeuvring handle to your jockey wheel (available separately). 1) During opening or closing, the AKS must only be operated by one person.

  • Page 90: Noises Whilst Driving

    Caravan Equipment down by hand force only DO NOT use your foot or an extension bar, this will damage the components (Fig. 6). 3) When opening or closing the stabiliser lever, please ensure your hand does not touch the coupling handle - you may accidentally trap your fingers! (Fig.

  • Page 91: Jockey Wheel

    (fig .8). iii. Jack up one side of the caravan (see Jack Operation Instructions). Remove the inner plastic bung from the backplate to expose the ‘starwheel’ adjuster access (figs. 8 & 9).
  • Page 92 If difficulty is experienced in this operation, try easing the caravan backwards with one hand while engaging the handbrake fully with the other. This manoeuvre should not be attempted on a rearwards facing slope.

  • Page 93: Chassis Lubrication Points

    Caravan Equipment ▲ In order to operate the Al-Ko braking system correctly adequate traction of caravan wheels is required when reversing. Therefore surface conditions that would result in a lack of traction should be avoided. Example: Peas, shingle/loose gravel. ▲ Care should be taken when traversing ramps or other obstacles in order to prevent damage to the caravan under gear.

  • Page 94: Heki 2 Rooflight

    Caravan Equipment 4.19 HEKI 2 ROOFLIGHT Operating Instructions ▲ Before commencing any journey always ensure that the Heki 2 rooflight is fully closed and both handles are securely fastened. 4.19.1 To open in the tilted position a) Press the knob in the toggle catches on either side of the glass and turn through approx. 90 deg.

  • Page 95: Opening The Blinds

    Caravan Equipment 4.19.5 Opening the blinds a) Move blind (end rod with rocker) right to the outside. b) Hold the recessed grip with one hand; with the other hand, press the rocker and move the blind back (do not let it recoil).

  • Page 96: Discovery, Ranger & Pageant Combination Window Blinds

    Caravan Equipment 4.21 DISCOVERY, RANGER & PAGEANT COMBINATION WINDOW BLINDS Operation and Care The cassette contains a sun screen and a fly screen blind. The fly screen is operated by gently pulling down the handle nearest the window. It is designed to be either fully up or fully down.

  • Page 97: Tracker Monitor

    The siren will be triggered if the caravan is towed, moved or lifted onto the back of a trailer. The siren will sound for five minutes unless stopped by the user. The Tracker Monitor sensor must detect movement over a longer period before it will send an alert.

  • Page 98: Status 315 Omni-Directional Television & Fm Radio Antenna (Ranger Only)

    Caravan Equipment 4.23 STATUS 315 OMNI-DIRECTIONAL TELEVISION & FM RADIO ANTENNA (Ranger only) 04-2064/5 Model 5 metres coaxial cable 04-2064/10 Model 10 metres coaxial cable Frequency Range UHF 470-860 MHz VHF 40-230 MHz FM 88 - 108 MHz Amplifier Gain...

  • Page 99: Fault Finding

    Caravan Equipment 4.23.5 Fault Finding The following are some of the key areas we suggest you check which generally solve the most common problems encountered with the operation of the Status antenna. Coaxial Plugs It is critical that all coaxial plugs in the system are fitted correctly. Please check each individual plug ensuring it is wired correctly.

  • Page 100: Status 530 Directional Television & Fm Radio Antenna (Pageant & Senator)

    Caravan Equipment 4.24 STATUS 530 DIRECTIONAL TELEVISION & FM RADIO ANTENNA (Pageant & Senator) Frequency Range UHF 470-860 MHz VHF 40-230 MHz FM 88 - 108 MHz Antenna Forward Gain Amplifier Gain 18 db* Gain Adjustment 15 db ± 1.52 db...

  • Page 101: Fault Finding

    ▲ It is the responsibility of the caravan owner to make sure that the directional aerial is fully retracted before the caravan is moved. Any damage as a result of neglect, i.e. not retracting the aerial, caused by crash damage, vandalism or incorrect operation will NOT be covered by the manufacturers warranty.

  • Page 102: Daewoo Microwave Oven

    Caravan Equipment 4.25 DAEWOO MICROWAVE OVEN 4.25.1 Precautions to avoid possible exposure to excessive microwave energy ▲ Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks.

  • Page 103: Microwave Cooking Utensils

    Caravan Equipment Microwave energy will be turned off automatically when the timer reaches “OFF”. Then food can be taken out of the oven. To prevent the oven from operating with the door open, your microwave oven is fitted with safety door •...

  • Page 104: Cooking Techniques

    Caravan Equipment 4.25.4 Cooking Techniques Stirring Stir foods such as casseroles and vegetables while cooking to distribute heat evenly. Food at the outside of the dish absorbs more energy and heats more quickly, so stir from the outside to the center.

  • Page 105: Care And Cleaning

    Caravan Equipment Plastic - most heat resistant plastic dinnerware may be used for heating food. However polyethylene, melamine, phenol are unsuitable for use in the oven. They become hot in the microwave. Wax paper - use as a cover to avoid spatters.

  • Page 106: Specifications

    Caravan Equipment Q: Why do I have moisture in my microwave oven after cooking? The moisture on the side of your microwave oven is normal. It is caused by steam from cooking food hitting the cool oven surface. Q: Does microwave energy pass through the viewing screen in the door? No.
  • Page 107 Caravan Equipment 4-64...

  • Page 108: General Maintenance

    5.1.1 Exterior The exterior of your caravan is very durable and easy to clean owing to its high gloss properties. To maintain a showroom finish one needs only to wash the caravan regularly with a car shampoo, rinse with cold water and chamois leather off. Do not forget to clean the roof. A good quality non metallic and non-coloured car wax that does not contain white spirit may be applied, which will make washing easier.

  • Page 109: Window Catches And Stays

    5.1.5 Care of your upholstery In the manufacturing of the fabrics used on the soft furnishings of your caravan a silicone coating is applied to help resist dirt and liquids. However if a liquid is spilt the following actions are required: ●...

  • Page 110: Hinges And Catches

    It is therefore important that you carry out the following procedure prior to using the caravan each time, even if you boil or filter all water you use for drinking.

  • Page 111: For Containers

    7. Replace the filter Suitable sterilising chemicals are available from your caravan dealer, accessory shop, chemists or home-brew shops. It is not, however, recommended to use bleach or sodium metabisulphite. This guidance has been prepared with the kind co-operation and assistance of The Environmental Health Department of The Borough Council of King’s Lynn and West Norfolk.

  • Page 112: Fire And Safety Precautions

    A fat pan fire should not have an extinguisher aimed at it but be smothered with a fire blanket. It is advisable not to cook with a fat pan or deep fryer in the enclosed space of a caravan. Extinguishers containing vaporising liquids should not be used by a person inside the caravan or from outside whilst other persons are in the caravan.

  • Page 113: Original Equipment Appliances

    General 5.2.6 Original Equipment Appliances See sections devoted to individual appliances. ▲ Replacement parts for any appliance shall conform to the appliance manufacturer’s specification; and should be fitted by them or an authorised agent. 5.2.7 Portable Appliances ▲ Never use portable cooking or heating equipment, other than electric heaters that are not of the direct radiant type, as it is a fire and asphyxiation hazard.

  • Page 114: Assembling The Bunks

    General ASSEMBLING THE BUNKS...

  • Page 115: Lift Up Bunk

    Release retaining straps on the underside of bunk base. The second half of the bunk base can now be unfolded towards the caravan wall. Turn the turnbuckle catches located on the metal bunk legs to ensure that the bunk cannot be folded by pushing up from below.

  • Page 116: Water System - Fault Finding

    General WATER SYSTEM - FAULT FINDING FAULT - Water not flowing from any tap when operated but pump runs 5.4.1 Cause Cure Freshwater tank empty Check Pump wired in reverse Check wiring, refer to pump manufacturers’ instructions Pump not primed Refer to pump manufacturers’...

  • Page 117: Fault - Water Flows From Hot Tap But Has Reduced Flow From Cold

    General 5.4.4 FAULT - Water flows from hot tap but has reduced flow from cold Cause Cure Cold water pipe kinked preventing flow Check and re-route if necessary Blockage in cold pipe line Disconnect pipes after 1st Y connector and check up to tap Cold tap not connected Refer to installation instructions...

  • Page 118: Fault - Water Heater Difficult To Drain

    General 5.4.8 FAULT - Water heater difficult to drain Cause Cure Hot taps not open preventing air entering Open taps hot system to let water out. Air bleed pipe kinked or blocked. Unkink or unblock pipe. 5-11...

  • Page 119: Room Heater - Fault Finding

    General ROOM HEATER - FAULT FINDING FAULT - Heater will not light 5.5.1 Symptoms Cause Cure Spark visible No gas. Bottle temperature too low Check bottle and taps. See gas supply notes. Regulator malfunction. See gas supply notes. Overgassed. Refer to lighting instructions.

  • Page 120: Brake Fault Finding Chart - Al-Ko

    General BRAKE FAULT FINDING CHART - AL-KO FAULT - Braking is one-sided 5.6.1 Cause Cure Incorrect adjustment at wheel. Adjust as described. Brake cable seized. Free off cable or replace. Brake lining contaminated with grease. Replace brake shoe assemblies. 5.6.2 FAULT - The trailer brakes during mild decelerations Cause Cure...

  • Page 121: Fault - Trailer Brakes Inoperative

    After 45 seconds the alarm system will arm. After a further 5 minute delay the Tracker monitor system will arm. The system will be triggered if the caravan is towed, moved or lifted onto the back of a trailer. The siren will sound for five minutes unless stopped by the user. The Tracker monitor sensor must detect movement over a longer period before it will send an alert.
  • Page 122 Please refer the first question. If Tracker telephones me and I am at home why do I need to check my caravan? I keep it at a secure compound so it must be safe or stolen so why cannot they track it? Tracker can only activate on receipt of the crime reference number and confirmation of theft.
  • Page 123 No, the warning LED indicates that the unit is working and cannot be switched off. I keep dogs in my caravan and the alarm keeps going off, can I switch off the PIR? No, this is not a feature of the system and will always be working.
  • Page 124 General You need to go to your dealer to purchase a replacement remote. He will de-program your old remote from the alarm then it will never work and at the same time re-program the alarm to the replacement remote I only have one Radio Remote. Can I obtain more? Yes, your dealer will be able to sell you additional remotes and program the system for them.
  • Page 125 Index...
  • Page 126 Rooflight Extraction Fan ........4-43 Braking System ..........4-42 Bunks, assembling ..........5-7 Safety ..............1-5 Smoke Alarm ............ 4-16 Caravan and towing vehicle terms ..... 2-1 Space Heater ............. 4-6 Caravan Chassis ..........4-44 Braking adjustment ........4-48 Manoeuvring ..........4-46 Operating instructions ........
  • Page 127 Bailey Caravans, South Liberty Lane, Bristol BS3 2SS www.bailey-caravans.co.uk...

Table of Contents
